5307-01-383-0461

Recessed Stud

5307013830461 013830461 0.50013UNC3A2.000T2G500STSCAA 999F0840FINDNO36 3930-0816NO55A

A headless fastener not exceeding twelve inches (304.8 mm) in length, threaded externally on both ends with threads of the same nominal diameter. One end or both ends may have a point. The unthreaded section may have more than one diameter, none of which may be greater than the maximum major thread diameter. It may be thread relieved. Excludes items with taper threads. View more Recessed Stud

Managed by United States

NSN Created on 17 Nov 1993

Data Last Changed
May 2023

NATO Update Count
2

NATO Data Quality

5307-01-383-0461 STUD,RECESSED 5307013830461 013830461 1/1 — 5307-01-383-0461 Photo 1/1

Marketplace 5307-01-383-0461

Need Help?
Request a Quotation from participating marketplace vendors

Updated Every Day

5307-01-383-0461 RQST NE

Restrictions 5307-01-383-0461

5307-01-383-0461 is a Recessed Stud that does not have a nuclear hardened feature, but does have another critical feature or features such as tolerance, fit restriction or application. This item is a US Munitions List or Commerce Control List Item where the Item Manager, Equipment Specialist or Product Specialist must provide special demilitarization instructions. This item is not suspected to be hazardous. This item does not contain a precious metal.

Import and Export 5307-01-383-0461

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 5307-01-383-0461

US Navy (N1HE)
Effective Date:: 1 Nov 1993
Supplementary Receivers:: GG; AMC 1 AMSC G IMC P

Approved Sources 5307-01-383-0461

Part Number
Manufacturer
Status
0.50013UNC3A2.000T2G500STSCAA: 81349 - Military Specifications (Active); Incomplete Standard; RNCC 4 RNVC 1 DAC 3
999F0840FINDNO36: 63857 - Circor Naval Solutions Llc (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC C
3930-0816NO55A: 63857 - Circor Naval Solutions Llc (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC C

Datasheet 5307-01-383-0461

Characteristic
Specifications
FIIG: A051A0
Criticality Code Justification [CRTL]: Zzzw
Departure From Cited Document [ZZZW]: Material Will Be In Accordance With Ships Parts Control Center Activity Hx Quality Control, Manufacturing And Testing Specifications

Management Data 5307-01-383-0461

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Oct 2022: Department of the Navy (DN); EA; Subscribe; 1
Oct 2021: Department of the Navy (DN); EA; Subscribe; 1
Oct 2020: Department of the Navy (DN); EA; Subscribe; 1
Oct 2019: Department of the Navy (DN); EA; Subscribe; 1

Navy

Cognizance:

1H: Consumable material assigned to NAVICP MECH for inventory management
Naval Inventory Control Point, Mechanicsburg

Special Material ID:

X3: Nuclear Reactor Plant (NRP) material under the technical cognizance of the NAVSEA 08 special designed, manufactured and/or treated for use in a NRP or controls thereof. This category includes all other NRP items which are not coded X2 or X4.

Issue, Repair, Requisition Restriction Code:

BL: Submit/refer requisitions to NAVICP MECH. Centralized control for issue of repair parts for specific programs/equipment

Special Material Content:

9: Non-Hazardous or Non-Sensitive Item

NATO Stock Numbers Related to 5307-01-383-0461

5307-99-667-1907 5307-99-894-1234 5307-12-374-2875 5307-99-383-3421 5307-99-837-4378 5307-14-556-6033 5307-99-369-1643 5307-99-743-0656 5307-99-560-5068 5307-12-128-9458 5307-12-333-9239 5307-12-164-8648 5307-99-667-4159 5307-12-357-1434 5307-99-722-8017 5307-99-748-5045 5307-00-207-0211 5307-00-181-6221

Freight Information 5307-01-383-0461

5307-01-383-0461 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 095190. A Sub NMFC of J. It has a NMFC Description of HARDWARE, NOI SUB 9. 5307-01-383-0461 is rated as class 70 when transported by Less-Than Truckload (LTL) freight. 5307-01-383-0461 is rated as class 70 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 49790 which rates the freight between FCL and LCL. 5307-01-383-0461 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5307-01-383-0461 is not classified as a special type of cargo when transported by water. 5307-01-383-0461 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 5307-01-383-0461

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); Packaging Data does not meet current MIL-STD-2073-1E

Storage Environment: Unheated General Purpose

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; --; Over 10lb; Less than 85G; No Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; --; --; --; --; Any Suitable Process

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: No Requirement; No Requirement; No Requirement; Not Applicable; MIL-DTL-117, Type II, Class C, Style 1, Heavy Duty, Waterproof, Greaseproof, Opaque Bag; --

Intermediate Pack Level

Quantity of Unit Packs
Container: ASTM-D5118, Type CF, Class Domestic, Corrugated Fiberboard Box
