5307-00-702-9328
Stepped Stud
5307007029328 007029328 AN161351
A headless fastener not exceeding 12 inches (304.8 mm) in length, threaded externally on both ends on which the nominal diameter of one threaded section is greater than the other. The entire unthreaded portion must be of a single diameter equal to or smaller than the maximum major diameter of the larger threaded end. Includes radial grooves or thread reliefs. Excludes items with tapered threads. View more Stepped Stud
May 2023
3
Marketplace 5307-00-702-9328
Request a Quotation from participating marketplace vendors
Related Documents 5307-00-702-9328 3+ Documents (More...)
NE FedMall Updated Every Day 5307-00-702-9328 RQST NE Updated Every Day 5307-00-702-9328 RQST Updated
Every Day 5307-00-702-9328 RQST NE Related Documents 5307-00-702-9328 2+ Documents ( More... ) https
Stepped Stud 5307007029328 007029328 Documents 5307-00-702-9328 1+ Documents ( More... ) https/
Per AssyUOMTechnical DocumentQuantative ExpressionDepartment of the Navy (DN)NLSuperseded By 5307-00-702-9328
Restrictions 5307-00-702-9328
5307-00-702-9328 is a Stepped Stud that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
End Users 5307-00-702-9328
- US Navy (N9BZ)
- Effective Date:
- 1 Apr 2014
- Supplementary Collaborators:
- HX
- United States of America (ZZ)
Approved Sources 5307-00-702-9328
- Part Number
- Manufacturer
- Status
- AN161351
- Manufacturer
- 88044 - Aeronautical Standards Group (Active)
- Definitive Standard
- Definitive Standard
Datasheet 5307-00-702-9328
- Characteristic
- Specifications
- FIIG
- Specifications
- A051A0
- Material [MATT]
- Steel Comp 8740
- Nominal Thread Size [CQJX]
- 0.375 Inches Nut Thread
- Nominal Thread Size [CQJX]
- 0.438 Inches Stud Thread
- End Item Identification [AGAV]
- Spec Item
- Hardness Rating [CQFM]
- 26.0 Rockwell C Minimum And 32.0 Rockwell C Maximum
- Surface Finish [CSYM]
- 32.0 Microinches Stud Thd
- Surface Finish [CSYM]
- 63.0 Microinches Shank
- Surface Finish [CSYM]
- 32.0 Microinches Nut Thd
- Material Document And Classification [MDCL]
- Ams 6322 Assn Std Single Material Response
- Shank Diameter [AAZE]
- 0.307 Inches Minimum And 0.311 Inches Maximum
- Overall Length [ABHP]
- 2.178 Inches Minimum And 2.198 Inches Maximum
- Thread Pitch Diameters [AAJE]
- +0.3992 To 0.4007 Inches Stud Thread
- Thread Quantity Per Inch [CMLP]
- 14 Stud Thread
- Thread Quantity Per Inch [CMLP]
- 24 Nut Thread
- Thread Class [AAJD]
- 3A Nut Thread
- Thread Direction [AAJF]
- Right-Hand Nut Thread
- Thread Direction [AAJF]
- Right-Hand Stud Thread
- Thread Length [AASA]
- 0.865 Inches Minimum And 0.885 Inches Maximum Stud Thread
- Thread Length [AASA]
- 0.678 Inches Minimum And 0.698 Inches Maximum Nut Thread
DLA Procurement Analysis 5307-00-702-9328
Management Data 5307-00-702-9328
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5307-00-702-9328
Freight Information 5307-00-702-9328
5307-00-702-9328 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 093486. A Sub NMFC of Z. It has a NMFC Description of BOLTS,NUTS OR SCREWS, NOI (SUB 3). 5307-00-702-9328 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 48950 which rates the freight between FCL and LCL. 5307-00-702-9328 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5307-00-702-9328 is not classified as a special type of cargo when transported by water. 5307-00-702-9328 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Contracting Technical Data File (CTDF) 5307-00-702-9328 August 2020
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Y
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
