5306-01-658-5501
Externally Relieved Body Bolt
5306016585501 016585501 AS54509
An externally threaded fastener whose threaded portion is of one nominal diameter, and whose unthreaded portion has been machined or ground in one or more places or over its entire length to a maximum diameter less than the minimum pitch diameter of the thread (excludes undercuts for thread relief). It is No. 10 (0.190 IN.) (5 mm) or larger in size and has a head which is not designed to be held or driven with an inserted driver or designed for rotation by the thumb and fingers. A locking feature may be incorporated in the design of the head or threads. Excludes BOLT, INTERNAL WRENCHING and THUMBSCREW. See also SCREW, EXTERNALLY RELIEVED BODY. View more Externally Relieved Body Bolt
May 2023
4
Marketplace 5306-01-658-5501
Request a Quotation from participating marketplace vendors
Related Documents 5306-01-658-5501 1+ Documents (More...)
RQST NE Updated Every Day 5306-01-658-5501 RQST Updated Every Day 5306-01-658-5501 RQST NE Related Documents
5306-01-658-5501 1+ Documents ( More... ) https//www.nsnlookup.com /fsg-53/fsc-5306/us 5306-01-658-5501
Restrictions 5306-01-658-5501
5306-01-658-5501 is a Externally Relieved Body Bolt that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5306-01-658-5501
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5306-01-658-5501
- National Security Agency (DGX1)
- Effective Date:
- 1 Oct 2016
Approved Sources 5306-01-658-5501
- Part Number
- Manufacturer
- Status
- AS54509
- Manufacturer
- 0U583 - Sae International (Active)
- Primary Buy
- Primary Buy
Datasheet 5306-01-658-5501
- Characteristic
- Specifications
- FIIG
- Specifications
- A003B0
- End Item Identification [AGAV]
- F-35B Liftfan
- Part Name Assigned By Controlling Agency [CXCY]
- Bolt, Close Tolerance - Double Hexagon, Extended Washer Head, Inconel 718, 0.1900-32Unjf-3A
- Special Features [FEAT]
- Next Higher Assembly Is Liftfan Assembly Module
- Thread Quantity Per Inch [CMLP]
- 24
DLA Procurement Analysis 5306-01-658-5501
Management Data 5306-01-658-5501
NATO Stock Numbers Related to 5306-01-658-5501
Freight Information 5306-01-658-5501
5306-01-658-5501 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 093486. A Sub NMFC of Z. It has a NMFC Description of BOLTS,NUTS OR SCREWS, NOI (SUB 3). 5306-01-658-5501 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 48950 which rates the freight between FCL and LCL. 5306-01-658-5501 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 573 for ocean manifesting and military sealift. 5306-01-658-5501 is not classified as a special type of cargo when transported by water. 5306-01-658-5501 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
