5306-00-263-8978
Machine Bolt
5306002638978 002638978 0S1587 035236 0S-1587 0035236 0035236-9 S1587
An externally threaded fastener designed for insertion through holes in assembled parts and normally intended to be tightened or released by torquing a nut. The threaded and unthreaded portions are both of one nominal diameter of 0.190 inch (5 mm) or larger. The head is not designed to be held or driven with an inserted driver or by the thumb and fingers. A locking feature may be incorporated in the design of the head or threads. Head dimensions and sizes of threaded and unthreaded portions shall conform to internationally recognized fastener standards. For items having a grip length portion machined to a tolerance of 0.0015 inch (0.038 mm) or less, BOLT, SHEAR. See also SCREW, CAP, HEXAGON HEAD and SCREW, MACHINE. View more Machine Bolt
July 2025
45
Marketplace 5306-00-263-8978
Request a Quotation from participating marketplace vendors
Related Documents 5306-00-263-8978 5+ Documents (More...)
Bolt5306002638978 002638978 Machine Bolt 5306002638978 002638978,0S1587 Documents 5306-00-263-8978 5
Machine Bolt 5306002638978 002638978,0S1587 Upgrade 5306-00-263-8978Machine Bolt5306002638978 002638978
$1 a day Upgrade your Account Upgrade 5945-00-283-8725Electromagnetic Relay5945002838725 002838725 S1587
Machine Bolt 5306002638978 002638978,0S1587 Upgrade 5306-00-263-8978Machine Bolt5306002638978 002638978
$1 a day Upgrade your Account Upgrade 6625-00-033-3931Special Scale Meter6625000333931 000333931 035236
www.nsnlookup.com /fsg-66/fsc-6625/us 6625-00-033-3931 Special Scale Meter 6625000333931000333931 035236
www.nsnlookup.com /fsg-59/fsc-5945/us 5945-00-283-8725 Electromagnetic Relay 5945002838725002838725 S1587
$1 a day Upgrade your Account Upgrade 5945-00-283 -8725Electromagnetic Relay5945002838725 002838725 S1587
Machine Bolt 5306002638978 002638978,0S1587 Special Scale Meter 6625000333931000333931 035236 https
Restrictions 5306-00-263-8978
5306-00-263-8978 is a Machine Bolt that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5306-00-263-8978
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5306-00-263-8978
- US Army (A919)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- A187
- Supplementary Receivers:
- AZ
- US Coast Guard (C918)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- C004
- US Marine Corps (MC47)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- MC10
- US Navy (N9BZ)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- N9ZD
- Supplementary Collaborators:
- GTHD
- Brazil (YA01)
- Effective Date:
- 1 Dec 2001
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Israel (YD01)
- Effective Date:
- 1 Aug 2016
- Kuwait (YK01)
- Effective Date:
- 1 Feb 2015
- Malaysia (YW01)
- Effective Date:
- 1 Apr 1991
- Australia (ZA01)
- Effective Date:
- 1 Oct 2003
- Canada (ZC01)
- Effective Date:
- 1 Jul 1996
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- France (ZF01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Mar 1999
- Portugal (ZP01)
- Effective Date:
- 1 Jun 1996
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
- Norway (ZT01)
- Effective Date:
- 1 Feb 2007
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 5306-00-263-8978
- Part Number
- Manufacturer
- Status
- 0S1587
- Manufacturer
- 11083 - Caterpillar Inc (Active)
- Primary Buy
- Primary Buy
- 035236
- 89926 - New Holland Construction (Active)
- Secondary Buy
- Secondary Buy
- 0S-1587
- 0141B - Navantia Sa Sme. (Active)
- Secondary Buy
- Secondary Buy
- 0S-1587
- 409BB - Navantia - Propulsion Y Energia (Active)
- Secondary Buy
- Secondary Buy
- 0035236
- 89926 - New Holland Construction (Active)
- Secondary Buy
- Secondary Buy
- 0035236-9
- 89926 - New Holland Construction (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- S1587
- 11083 - Caterpillar Inc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5306-00-263-8978
- Characteristic
- Specifications
- FIIG
- Specifications
- A003B0
- Head Style [AASK]
- Hexagon
- Thread Series Designator [THSD]
- Unc
- Nominal Thread Diameter [AHYM]
- 0.500 Inches
- Thread Quantity Per Inch [CMLP]
- 13
- Thread Class [AAJD]
- 2A
- Thread Direction [AAJF]
- Right-Hand
- Thread Length [AASA]
- 1.375 Inches Minimum
- Fastener Length [AASB]
- 1.750 Inches Nominal
- Material [MATT]
- Steel Overall
- Hardness Rating [CQFM]
- 30.0 Rockwell C Maximum Overall
- Minimum Yield Strength [CQHQ]
- 145000 Pounds Per Square Inch
- Head Height [AASU]
- 0.375 Inches Nominal
- Width Between Flats [AATB]
- 0.750 Inches Nominal
- Features Provided [CBBL]
- Finished Head
Weapon Systems (WSDC) 5306-00-263-8978
DLA Procurement Analysis 5306-00-263-8978
- Last Stock Position:
- 192 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5306-00-263-8978
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- B2
- Material Identification:
- B
- Consumable Repair Parts
- Operational Test:
- No Special Procedures
Similar Supply Items to 5306-00-263-8978
Freight Information 5306-00-263-8978
5306-00-263-8978 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 093486. A Sub NMFC of Z. It has a NMFC Description of BOLTS,NUTS OR SCREWS, NOI (SUB 3). 5306-00-263-8978 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 48950 which rates the freight between FCL and LCL. 5306-00-263-8978 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 573 for ocean manifesting and military sealift. 5306-00-263-8978 is not classified as a special type of cargo when transported by water. 5306-00-263-8978 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5306-00-263-8978
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- --
- --
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- Any Suitable Container
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
Contracting Technical Data File (CTDF) 5306-00-263-8978 February 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- L
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
