5306-00-206-8850
Shoulder Bolt
5306002068850 002068850 01760-0003-01 1760-003-1 J5-1391
An externally threaded fastener whose threaded portion is of one nominal diameter, No. 10 (0.190 IN.) (5 mm) or larger. It has a round unthreaded neck or shank all or part of which is of greater diameter than the threaded portion. The head is not designed to be held or driven with an inserted drivers. A locking feature may be incorporated in the design of the head or threads. For items with a thread diameter smaller than No. 10 (0.190 IN.) (5 mm) and those items with an inserted drive head, use SCREW, SHOULDER. For items which are No. 10 (0.190 IN.) (5 mm) or larger in size and are both shouldered and have an externally relieved body, use BOLT, EXTERNALLY RELIEVED BODY. Excludes THUMBSCREW. View more Shoulder Bolt
May 2023
14
Marketplace 5306-00-206-8850
Request a Quotation from participating marketplace vendors
Related Documents 5306-00-206-8850 5+ Documents (More...)
5306-00-206-8850 1+ Documents ( More... ) https//www.nsnlookup.com /fsg-53/fsc-5306/us 5306-00-206-8850
RQST Updated Every Day 5306-00-206-8850 RQST NE Restrictions 5306-00-206-8850 DEMIL: A | DEMILI
Restrictions 5306-00-206-8850
5306-00-206-8850 is a Shoulder Bolt that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5306-00-206-8850
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5306-00-206-8850
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 5306-00-206-8850
- Part Number
- Manufacturer
- Status
- 01760-0003-01
- Manufacturer
- 93568 - Harsco Corp Bmy-Combat Systems Div (Obsolete)
- Original Design
- Original Design
- 1760-003-1
- 93568 - Harsco Corp Bmy-Combat Systems Div (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- J5-1391
- 38460 - Long-Airdox Co (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5306-00-206-8850
- Characteristic
- Specifications
- FIIG
- Specifications
- A003B0
- Distance From Centerline To Flat [AASY]
- 0.445 Inches Nominal
- Fastener Length [AASB]
- 2.469 Inches Minimum And 2.531 Inches Maximum
- Hardness Rating [CQFM]
- 196.0 Brinell Standard Minimum Overall And 228.0 Brinell Standard Maximum Overall
- Head Diameter [AASL]
- 1.312 Inches Minimum And 1.343 Inches Maximum
- Head Height [AASU]
- 0.250 Inches Minimum And 0.281 Inches Maximum
- Head Style [AASK]
- Dee Chamfer
- Material [MATT]
- Steel Overall
- Nominal Thread Diameter [AHYM]
- 0.750 Inches
- Shoulder Diameter [AATN]
- 0.8753 Inches Minimum First Shoulder And 0.8765 Inches Maximum First Shoulder
- Shoulder Length [AATX]
- 0.703 Inches Minimum First Shoulder And 0.719 Inches Maximum First Shoulder
- Shoulder Shape [CWYB]
- Round First Shoulder
- Surface Treatment Document And Classification [STDC]
- Ms18 Class A,Fscm 71282 Mfr Ref Single Treatment Response Overall
- Surface Treatment [SFTT]
- Cadmium Overall Or Zinc Overall
- Thread Class [AAJD]
- 3A
- Thread Direction [AAJF]
- Right-Hand
- Thread Length [AASA]
- 1.375 Inches Minimum
- Thread Quantity Per Inch [CMLP]
- 16
- Thread Series Designator [THSD]
- Unf
Similar Supply Items to 5306-00-206-8850
Freight Information 5306-00-206-8850
5306-00-206-8850 has freight characteristics.. 5306-00-206-8850 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
