5306-00-206-2657
Eye Bolt
5306002062657 002062657 AN170-16RS
An externally threaded device whose threaded portion is of one nominal diameter, without a head, but with the unthreaded end either bent more than 225 degrees (3.925 radians) or cast, forged, or punched to resemble an eye. See also BOLT, HOOK. Excludes CONNECTOR, ROD END. View more Eye Bolt
May 2023
11
Marketplace 5306-00-206-2657
Request a Quotation from participating marketplace vendors
Related Documents 5306-00-206-2657 3+ Documents (More...)
RQST NE Updated Every Day 5306-00-206-2657 RQST Updated Every Day 5306-00-206-2657 RQST NE Related Documents
5306-00-206-2657 1+ Documents ( More... ) https//www.nsnlookup.com /fsg-53/fsc-5306/us 5306-00-206-2657
Restrictions 5306-00-206-2657
5306-00-206-2657 is a Eye Bolt that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5306-00-206-2657
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5306-00-206-2657
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- France (ZF01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5306-00-206-2657
- Part Number
- Manufacturer
- Status
- AN170-16RS
- Manufacturer
- 88044 - Aeronautical Standards Group (Active)
- Definitive Standard
- Definitive Standard
Datasheet 5306-00-206-2657
- Characteristic
- Specifications
- FIIG
- Specifications
- A003B0
- Eye Inside Diameter [AATK]
- 0.234 Inches Nominal
- Eye Outside Width [CWXM]
- 0.500 Inches Nominal
- Eye Stock Diameter [AATZ]
- 0.188 Inches Nominal
- Material [MATT]
- Steel Overall
- Nominal Thread Diameter [AHYM]
- 0.190 Inches
- Shank Length [AATR]
- 1.375 Inches Nominal
- Overall Length [ABHP]
- 1.906 Inches Nominal
- Surface Treatment [SFTT]
- Cadmium Overall Or Zinc Overall
- Thread Class [AAJD]
- 3A
- Thread Direction [AAJF]
- Right-Hand
- Thread Length [AASA]
- 0.500 Inches Minimum
- Thread Quantity Per Inch [CMLP]
- 32
- Thread Series Designator [THSD]
- Unf
Similar Supply Items to 5306-00-206-2657
Freight Information 5306-00-206-2657
5306-00-206-2657 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 093486. A Sub NMFC of Z. It has a NMFC Description of BOLTS,NUTS OR SCREWS, NOI (SUB 3). 5306-00-206-2657 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 5306-00-206-2657 is rated as class 50 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 48950 which rates the freight between FCL and LCL. 5306-00-206-2657 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 573 for ocean manifesting and military sealift. 5306-00-206-2657 is not classified as a special type of cargo when transported by water. 5306-00-206-2657 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
