5306-00-206-0429
Externally Relieved Body Bolt
5306002060429 002060429 A76116
An externally threaded fastener whose threaded portion is of one nominal diameter, and whose unthreaded portion has been machined or ground in one or more places or over its entire length to a maximum diameter less than the minimum pitch diameter of the thread (excludes undercuts for thread relief). It is No. 10 (0.190 IN.) (5 mm) or larger in size and has a head which is not designed to be held or driven with an inserted driver or designed for rotation by the thumb and fingers. A locking feature may be incorporated in the design of the head or threads. Excludes BOLT, INTERNAL WRENCHING and THUMBSCREW. See also SCREW, EXTERNALLY RELIEVED BODY. View more Externally Relieved Body Bolt
May 2023
5
Marketplace 5306-00-206-0429
Request a Quotation from participating marketplace vendors
Related Documents 5306-00-206-0429 5+ Documents (More...)
A76116 BOLT,EXTERNALLY RELIEVED BODY 1 EA NS Request Quotation Updated Every Day 5306-00-206-0429 RQST
NE Updated Every Day 5306-00-206-0429 RQST Updated Every Day 5306-00-206-0429 RQST NE Related Documents
Restrictions 5306-00-206-0429
5306-00-206-0429 is a Externally Relieved Body Bolt that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5306-00-206-0429
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5306-00-206-0429
- National Security Agency (DGX1)
- Effective Date:
- 1 Jan 2014
- US Navy (N9BZ)
- Effective Date:
- 1 Mar 2014
- Supplementary Collaborators:
- HDKEHX
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5306-00-206-0429
- Part Number
- Manufacturer
- Status
- A76116
- Manufacturer
- 78047 - Capitol Engine Co Inc (Active)
- Primary Buy
- Primary Buy
- A76116
- 0AHP5 - Curtiss-Wright Controls, Inc. (Active)
- Primary Buy
- Primary Buy
Datasheet 5306-00-206-0429
- Characteristic
- Specifications
- FIIG
- Specifications
- A003B0
- Distance From Largest Bearing Surface Of Head To End Of First Diameter [AAWH]
- 0.375 Inches Nominal
- Distance From Largest Bearing Surface Of Head To End Of Second Diameter [AAWJ]
- 2.875 Inches Nominal
- Externally Relieved Body Diameter Quantity [CSNG]
- 2
- Fastener Length [AASB]
- 4.625 Inches Maximum
- First Diameter From Head [AAWC]
- 0.875 Inches Nominal
- Head Height [AASU]
- 0.688 Inches Maximum
- Head Style [AASK]
- Hexagon
- Hole Configuration Style [CRHC]
- Hexagon Longitudinal Hole
- Hole Diameter [AAUB]
- 0.188 Inches Nominal
- Hole Quantity [ASXK]
- 6
- Hole Type [BQDM]
- Drilled
- Material Document And Classification [MDCL]
- Qq-N-286,Cl A Fed Spec Single Material Response Overall
- Material [MATT]
- Nickel Alloy K-500 Overall
- Nominal Thread Diameter [AHYM]
- 0.875 Inches
- Second Diameter From Head [AAWD]
- 0.775 Inches Minimum And 0.781 Inches Maximum
- Width Between Flats [AATB]
- 1.438 Inches Maximum
- Thread Class [AAJD]
- 3A
- Thread Direction [AAJF]
- Right-Hand
- Thread Length [AASA]
- 1.750 Inches Minimum
- Thread Quantity Per Inch [CMLP]
- 14
- Thread Series Designator [THSD]
- Unf
DLA Procurement Analysis 5306-00-206-0429
Management Data 5306-00-206-0429
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5306-00-206-0429
Freight Information 5306-00-206-0429
5306-00-206-0429 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 093486. A Sub NMFC of Z. It has a NMFC Description of BOLTS,NUTS OR SCREWS, NOI (SUB 3). 5306-00-206-0429 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 48950 which rates the freight between FCL and LCL. 5306-00-206-0429 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5306-00-206-0429 is not classified as a special type of cargo when transported by water. 5306-00-206-0429 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Contracting Technical Data File (CTDF) 5306-00-206-0429 February 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
