5306-00-151-0508
Clevis Bolt
5306001510508 001510508 B6812 AN21-21
An externally threaded fastener whose threaded and unthreaded portions are of one nominal diameter and are separated by a narrow circumferential groove. The head is designed to be held or driven with an inserted driver. Excludes BOLT, SHEAR. View more Clevis Bolt
Managed by United States
NSN Created on 1 Jan 1963
Data Last Changed
November 2023
November 2023
NATO Update Count
10
10
NATO Data Quality
Marketplace 5306-00-151-0508
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 5306-00-151-0508 5+ Documents (More...)
B6812 AN21-21 An externally threaded fastener whose threaded and unthreaded portions are of one nominal
Photo 1/6 5306-00-151-0508 Photo 2/6 5306-00-151-0508 Photo 3/6 5306-00-151-0508 Photo 4/6 NSN
B6812 BOLT,CLEVIS 49 EA NS Request Quotation Updated Every Day 5306-00-151-0508 RQST NE Updated Every
Photo 1/6 5306-00-151-0508 Photo 2/6 5306-00-151-0508 Photo 3/6 5306-00-151-0508 Photo 4/6 NSN
B6812 BOLT,CLEVIS 49 EA NS Request Quotation Updated Every Day 5306-00-151-0508 RQST NE Updated Every
B6812 BOLT,MACHINE 12 EA NS Request Quotation Subscribe to View Vendor Details...
/fsg-53/fsc-5306/us 5306-00-151-2841 Machine Bolt 5306001512841 001512841,B6812 B6812 BOLT,MACHINE 116
/fsg-53/fsc-5306/us 5306-00-182-1938 Machine Bolt 5306001821938 001821938,B6812 B6812 BOLT,MACHINE 12
/fsg-53/fsc-5306/us 5306-00-151-2841 Machine Bolt 5306001512841 001512841,B6812 B6812 BOLT,MACHINE 116
/fsg-53/fsc-5306/us 5306-00-182-1938 Machine Bolt 5306001821938 001821938,B6812 B6812 BOLT,MACHINE 12
B6812 BOLT,MACHINE 116 EA NS Request Quotation Subscribe to View Vendor Details...
B6812 BOLT,MACHINE 12 EA NS Request Quotation Subscribe to View Vendor Details...
B6812 BOLT,EYE 116 EA NS Request Quotation Subscribe to View Vendor Details...
B6812 BOLT,MACHINE 12 EA NS Request Quotation Subscribe to View Vendor Details...
B6812 BOLT,EYE 116 EA NS Request Quotation Subscribe to View Vendor Details...
B6812 BOLT,MACHINE 116 EA NS Request Quotation Subscribe to View Vendor Details...
B6812 BOLT,MACHINE 12 EA NS Request Quotation Subscribe to View Vendor Details...
/fsg-53/fsc-5306/us 5306-00-150-9534 Machine Bolt 5306001509534 001509534,B6812 B6812 BOLT,MACHINE 116
B6812 BOLT,MACHINE 12 EA NS Request Quotation Subscribe to View Vendor Details...
/fsg-53/fsc-5306/us 5306-00-150-9534 Machine Bolt 5306001509534 001509534,B6812 B6812 BOLT,MACHINE 116
Restrictions 5306-00-151-0508
5306-00-151-0508 is a Clevis Bolt that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5306-00-151-0508
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5306-00-151-0508
- US Air Force (FXGI)
- Effective Date:
- 1 Jun 2005
- Former MOE Rule:
- FXKZ
- US Navy (N9BZ)
- Effective Date:
- 1 Jun 2005
- Former MOE Rule:
- N9ZD
- Supplementary Collaborators:
- GTKE
- Brazil (YA01)
- Effective Date:
- 1 Aug 2000
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5306-00-151-0508
- Part Number
- Manufacturer
- Status
- AN21-21
- Manufacturer
- 80205 - National Aerospace Standards (Active)
- Primary Buy
- Primary Buy
- B6812
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- AN21-21
- 88044 - Aeronautical Standards Group (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5306-00-151-0508
- Characteristic
- Specifications
- FIIG
- Specifications
- A003B0
- Distance From Head Largest Bearing Surface To Shank Hole Center [CRZS]
- 1.218 Inches Nominal First Hole
- Departure From Cited Document [ZZZW]
- Thread T Per Mil-S-7742 Except Major Dia Is Not To Exceed Max Allow Bolt Shank Dia
- Fastener Length [AASB]
- 1.344 Inches Nominal
- Groove Diameter [AAVZ]
- 0.100 Inches Nominal
- Head Diameter [AASL]
- 0.297 Inches Minimum And 0.328 Inches Maximum
- Head Height [AASU]
- 0.062 Inches Minimum And 0.094 Inches Maximum
- Head Style [AASK]
- Button
- Material Document And Classification [MDCL]
- Mil-S-6049 Mil Spec 1St Material Response Overall Or Mil-S-6050 Mil Spec 2Nd Material Response Overall Or Mil-S-6098 Mil Spec 3Rd Material Response Overall Or Mil-S-5626 Mil Spec 4Th Material Response Overall Or Mil-S-6758 Mil Spec 5Th Material Response Overall Or Mil-S-8695 Mil Spec 6Th Material Response Overall
- Material [MATT]
- Steel Comp 8740 Overall Or Steel Comp 8630 Overall Or Steel Comp 8735 Overall Or Steel Comp 4140 Overall Or Steel Comp 4130 Overall Or Steel Comp 4037 Overall
- Nominal Thread Diameter [AHYM]
- 0.138 Inches
- Internal Drive Style [ABQZ]
- Slot
- Shank Unthreaded Hole Diameter [AAWB]
- 0.038 Inches Minimum First Hole And 0.048 Inches Maximum First Hole
- Single Shear Strength [AAWU]
- 1060 Pounds Per Square Inch
- Surface Treatment Document And Classification [STDC]
- Qq-P-416,Ty 2 Cl 3 Fed Spec All Treatment Responses Overall
- Surface Treatment [SFTT]
- Cadmium Overall And Chromate Overall
- Thread Class [AAJD]
- 3A
- Thread Length [AASA]
- 0.251 Inches Minimum
- Thread Direction [AAJF]
- Right-Hand
- Thread Quantity Per Inch [CMLP]
- 40
- Thread Series Designator [THSD]
- Unf
Weapon Systems (WSDC) 5306-00-151-0508
DLA Procurement Analysis 5306-00-151-0508
- Last Stock Position:
- 111 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5306-00-151-0508
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Department of the Air Force (DF)
- EA
- Subscribe
- EA
- Dec 2021
- Department of the Air Force (DF)
- EA
- Subscribe
- EA
- Nov 2021
- Defense Logistics Agency (DS)
- EA
- Subscribe
- EA
- Oct 2020
- Defense Logistics Agency (DS)
- EA
- Subscribe
- EA
- Oct 2019
- Department of the Air Force (DF)
- EA
- Subscribe
- EA
- Dec 2007
- US Marine Corps (DM)
- EA
- Subscribe
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- US Marine Corps (DM)
- M
- V
- Discontinued W/O Replacement
- V
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Echelon Management:
- I2
- Operational Test:
- No Special Procedures
Similar Supply Items to 5306-00-151-0508
Freight Information 5306-00-151-0508
5306-00-151-0508 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 093486. A Sub NMFC of Z. It has a NMFC Description of BOLTS,NUTS OR SCREWS, NOI (SUB 3). 5306-00-151-0508 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 48950 which rates the freight between FCL and LCL. 5306-00-151-0508 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 573 for ocean manifesting and military sealift. 5306-00-151-0508 is not classified as a special type of cargo when transported by water. 5306-00-151-0508 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5306-00-151-0508
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- Special Requirements – see Specific Instructions or Drawings provided
- No Requirement
- Not Applicable
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- Special Requirements – see Specific Instructions or Drawings provided
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
Procurement History 5306-00-151-0508 6 Records
- Contract
- Date
- CAGE
- Quantity
- Net Price
- Std Price
- CAGE
- SPM5EY12D00172548
- 16 Feb 2017
- Subscribe
- 537
- Subscribe
- Subscribe
- Subscribe
- SPM5EY12D00170941
- 30 Apr 2015
- Subscribe
- 457
- Subscribe
- Subscribe
- Subscribe
- SPM5EY12D00170443
- 31 Jan 2014
- Subscribe
- 20
- Subscribe
- Subscribe
- Subscribe
- SPM5EY12D00170437
- 30 Jan 2014
- Subscribe
- 66
- Subscribe
- Subscribe
- Subscribe
- SPM5EY12D00170423
- 01 Jan 2014
- Subscribe
- 25
- Subscribe
- Subscribe
- Subscribe
- SPM5EY12D00170408
- 02 Dec 2013
- Subscribe
- 20
- Subscribe
- Subscribe
- Subscribe
Contracting Technical Data File (CTDF) 5306-00-151-0508 February 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
