5306-00-109-3317
Internally Relieved Body Bolt
5306001093317 001093317 177588
An externally threaded fastener whose external threaded portion is of one nominal diameter. It has a concentric hole along the longitudinal centerline which may extend a part or the full length of the bolt. The concentric hole along the centerline may be counterbored and/or internally threaded at the head end or the bolt end. The head is designed to be held or driven by an external and/or internal driver. For items having a hole(s) perpendicular to the axis which meet the concentric hole along the longitudinal centerline, see BOLT, FLUID PASSAGE. View more Internally Relieved Body Bolt
May 2023
19
Marketplace 5306-00-109-3317
Request a Quotation from participating marketplace vendors
Related Documents 5306-00-109-3317 5+ Documents (More...)
5306-00-109-3317 RQST Updated Every Day 5306-00-109-3317 RQST NE Related Documents 5306-00-109-3317
Body Bolt 5306001093317 177588 An externally threaded fastener whose external threaded portion is of
https//www.nsnlookup.com /fsg-53/fsc-5306/us 5306-00-109-3317 Internally Relieved Body Bolt 5306001093317
Upgrade your Account Upgrade 5306-00-109-3317Internally Relieved Body Bolt5306001093317 001093317 177588
/www.nsnlookup.com /fsg-59/fsc-5995/us 5995-01-070-8786 Electrical Special Purpose Cable Assembly 177588
your web browser . 5995-01-070-8786Electrical Special Purpose Cable Assembly5995010708786 010708786 177588
Restrictions 5306-00-109-3317
5306-00-109-3317 is a Internally Relieved Body Bolt that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5306-00-109-3317
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5306-00-109-3317
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5306-00-109-3317
- Part Number
- Manufacturer
- Status
- 177588
- Manufacturer
- 98897 - Lockheed Martin Corp (Active)
- Primary Buy
- Primary Buy
Datasheet 5306-00-109-3317
- Characteristic
- Specifications
- FIIG
- Specifications
- A003B0
- Thread Series Designator [THSD]
- Unf
- Nominal Thread Diameter [AHYM]
- 0.875 Inches
- Thread Quantity Per Inch [CMLP]
- 14
- Thread Class [AAJD]
- 3A
- Thread Direction [AAJF]
- Right-Hand
- Thread Length [AASA]
- 1.160 Inches Minimum
- Fastener Length [AASB]
- 2.000 Inches Nominal
- Material [MATT]
- Steel Overall
- Material Document And Classification [MDCL]
- Mil-S-6050 Mil Spec Single Material Response Overall
- Style Designator [STYL]
- Concentric Hole Threaded
- Thread Series [BZRR]
- Unf Concentric Hole
- Nominal Thread Size [CQJX]
- 0.625 Inches Concentric Hole
- Threads Per Inch [AAEL]
- 18 Concentric Hole
- Internal Thread Class [CWWR]
- 3B Head
- Internal Thread Direction [CGMJ]
- Right-Hand Head
- Internal Thread Length [ABXT]
- 1.000 Inches Nominal Concentric Hole
- Head Style [AASK]
- Hexagon
- Head Diameter [AASL]
- 1.312 Inches Nominal
- Head Height [AASU]
- 0.512 Inches Nominal
- Width Between Flats [AATB]
- 1.380 Inches Nominal
- Extended Washer Thickness [AATD]
- 0.100 Inches Nominal
- End Item Identification [AGAV]
- T-33
Similar Supply Items to 5306-00-109-3317
Freight Information 5306-00-109-3317
5306-00-109-3317 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 095190. A Sub NMFC of Z. It has a NMFC Description of HARDWARE, NOI. 5306-00-109-3317 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 5306-00-109-3317 is rated as class 70 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 49790 which rates the freight between FCL and LCL. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5306-00-109-3317 is not classified as a special type of cargo when transported by water. 5306-00-109-3317 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
