5305-01-618-4608
Panel Screw Assembly
5305016184608 016184608 FTD7241-2
A headed, threaded fastening device over which may be assembled; (1) a stand-off; (2) a flanged bushing with washer(s) and/or a shouldered bushing without a flange, or it may have an internally threaded sleeve that is an integral part of the screw; a washer and an externally thread self-locking bushing that is driven by an inserted driver. Attached to panel by threaded bushing or by flaring end of stand-off, or bushing. Used in conjunction with a speed nut, nut plate, or driven into a threaded hole in the item that the panel is fastened to. May be spring loaded. View more Panel Screw Assembly
September 2023
3
Marketplace 5305-01-618-4608
Request a Quotation from participating marketplace vendors
Related Documents 5305-01-618-4608 1+ Documents (More...)
RQST NE Updated Every Day 5305-01-618-4608 RQST Updated Every Day 5305-01-618-4608 RQST NE Related Documents
5305-01-618-4608 1+ Documents ( More... ) https//www.nsnlookup.com /fsg-53/fsc-5305/us 5305-01-618-4608
Restrictions 5305-01-618-4608
5305-01-618-4608 is a Panel Screw Assembly that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5305-01-618-4608
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5305-01-618-4608
- US Army (A919)
- Effective Date:
- 1 Apr 2013
- Supplementary Receivers:
- CT
Approved Sources 5305-01-618-4608
- Part Number
- Manufacturer
- Status
- FTD7241-2
- Manufacturer
- 58794 - Fastener Technology Corp (Active)
- Primary Buy
- Primary Buy
Datasheet 5305-01-618-4608
- Characteristic
- Specifications
- FIIG
- Specifications
- A003B0
- End Item Identification [AGAV]
- 1230-01-614-3412
- Fastener Length [AASB]
- 0.605 Inches Minimum And 0.645 Inches Maximum
- Head Height [AASU]
- 0.168 Inches Minimum And 0.188 Inches Maximum
- Head Style [AASK]
- Hexagon
- Material [MATT]
- Iron Alloy 660 Washer
- Material [MATT]
- Steel Comp 302 Spring
- Material [MATT]
- Steel Comp 303 Or Steel Comp 303Se Or Steel Comp 303 Plus X Sleeve
- Material [MATT]
- Steel Comp 630 Fastener
- Material [MATT]
- Steel Corrosion Resisting Locking Feature
- Nominal Thread Diameter [AHYM]
- 0.1380 Inches
- Internal Drive Style [ABQZ]
- Hexagon
- Material Accommodated Thickness [AGSM]
- 0.605 Inches Nominal
- Material Document And Classification [MDCL]
- 300 Series Cres Per Ams5640,Astm-Aa555 Or Astm-A561 National Std/Spec Single Material Response Sleeve
- Material Document And Classification [MDCL]
- 300 Series Cres Per Ms35338 Mil Spec Single Material Response Locking Feature
- Material Document And Classification [MDCL]
- 17-4 Cres Per Ams5643 National Std/Spec Single Material Response Fastener
- Material Document And Classification [MDCL]
- A286 Cres Per Ams5731,Ams5737/Equiv. National Std/Spec Single Material Response Washer
- Material Document And Classification [MDCL]
- Astm-A313 National Std/Spec Single Material Response Spring
- Part Name Assigned By Controlling Agency [CXCY]
- Captive Screw,Hex Socket Edm Flaring Type,Spring Loaded Self Locking,Fully Retractable
- Thread Series Designator [THSD]
- Unc
- Thread Quantity Per Inch [CMLP]
- 32
- Width Between Flats [AATB]
- 0.303 Inches Minimum And 0.312 Inches Maximum
- Width Across Flats [ASDB]
- 0.156 Inches Nominal
- Specification/Standard Data [ZZZK]
- 58794-Ftd7241 Manufacturers Specification
- Surface Treatment Document And Classification [STDC]
- Ams2700 National Std/Spec Single Treatment Response Overall
- Surface Treatment [SFTT]
- Passivate Overall
- Thread Class [AAJD]
- 3A
- Thread Direction [AAJF]
- Right-Hand
- Thread Length [AASA]
- 0.500 Inches Nominal
Weapon Systems (WSDC) 5305-01-618-4608
DLA Procurement Analysis 5305-01-618-4608
- Last Stock Position:
- 92 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5305-01-618-4608
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Similar Supply Items to 5305-01-618-4608
Freight Information 5305-01-618-4608
5305-01-618-4608 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 096640. A Sub NMFC of X. It has a NMFC Description of SCREWS, IRON OR STEEL. 5305-01-618-4608 is rated as class 70 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 50600 which rates the freight between FCL and LCL. 5305-01-618-4608 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5305-01-618-4608 is not classified as a special type of cargo when transported by water. 5305-01-618-4608 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
