5305-01-389-7967
Panel Screw Assembly
5305013897967 013897967 DRBB7500HS-10-A- FT1600HS10-1-3B DRBB7500HS-10-A-3 7010485-001
A headed, threaded fastening device over which may be assembled; (1) a stand-off; (2) a flanged bushing with washer(s) and/or a shouldered bushing without a flange, or it may have an internally threaded sleeve that is an integral part of the screw; a washer and an externally thread self-locking bushing that is driven by an inserted driver. Attached to panel by threaded bushing or by flaring end of stand-off, or bushing. Used in conjunction with a speed nut, nut plate, or driven into a threaded hole in the item that the panel is fastened to. May be spring loaded. View more Panel Screw Assembly
May 2023
4
Marketplace 5305-01-389-7967
Request a Quotation from participating marketplace vendors
Related Documents 5305-01-389-7967 1+ Documents (More...)
Photo 1/3 NSN 5305-01-389-7967 (Identification) 2/3 NSN 5305-01-389-7967 (Identification) 3/3 -
BUY NE FedMall Updated Every Day 5305-01-389-7967 RQST NE Updated Every Day 5305-01-389-7967 RQST
Restrictions 5305-01-389-7967
5305-01-389-7967 is a Panel Screw Assembly that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5305-01-389-7967
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5305-01-389-7967
- US Air Force (FXGI)
- Effective Date:
- 1 Mar 2006
- Former MOE Rule:
- FXKZ
Approved Sources 5305-01-389-7967
- Part Number
- Manufacturer
- Status
- DRBB7500HS-10-A-
- Manufacturer
- 0HDW7 - Huck International, Inc. (Active)
- Primary Buy
- Primary Buy
- DRBB7500HS-10-A-3
- 0HDW7 - Huck International, Inc. (Active)
- Primary Buy
- Primary Buy
- FT1600HS10-1-3B
- 58794 - Fastener Technology Corp (Active)
- Secondary Buy
- Secondary Buy
- DRBB7500HS-10-A-3
- 97928 - Huck Intl Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 7010485-001
- 12436 - Bae Systems Information And (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5305-01-389-7967
- Characteristic
- Specifications
- FIIG
- Specifications
- A003B0
- Color [HUES]
- Black Fastener
- Color [HUES]
- Black Head
- Fastener Length [AASB]
- 0.537 Inches Nominal
- Features Provided [CBBL]
- Sleeve
- Head Diameter [AASL]
- 0.451 Inches Nominal
- Head Height [AASU]
- 0.590 Inches Nominal
- Head Style [AASK]
- Knurled No. 1
- Material [MATT]
- Aluminum Alloy 6061 Spring
- Material [MATT]
- Aluminum Alloy 6061 Stand-Off
- Material [MATT]
- Steel Comp 302 Fastener Or Steel Comp 304 Fastener Or Steel Comp 305 Fastener Or Steel Comp 316 Fastener Or Steel Comp 384 Fastener
- Nominal Thread Diameter [AHYM]
- 0.190 Inches
- Internal Drive Style [ABQZ]
- Hexagon
- Material Accommodated Thickness [AGSM]
- 0.031 Inches Minimum And 0.062 Inches Maximum
- Thread Series Designator [THSD]
- Unf
- Width Across Flats [ASDB]
- 0.156 Inches Nominal
- Surface Treatment [SFTT]
- Anodize Head
- Surface Treatment [SFTT]
- Anodize Stand-Off
- Surface Treatment [SFTT]
- Oxide Fastener
- Surface Treatment [SFTT]
- Passivate Spring
- Thread Direction [AAJF]
- Right-Hand
- Thread Class [AAJD]
- 3A
- Thread Quantity Per Inch [CMLP]
- 32
DLA Procurement Analysis 5305-01-389-7967
Management Data 5305-01-389-7967
Similar Supply Items to 5305-01-389-7967
Freight Information 5305-01-389-7967
5305-01-389-7967 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 096640. A Sub NMFC of X. It has a NMFC Description of SCREWS, IRON OR STEEL. 5305-01-389-7967 is rated as class 70 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 50600 which rates the freight between FCL and LCL. 5305-01-389-7967 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5305-01-389-7967 is not classified as a special type of cargo when transported by water. 5305-01-389-7967 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
