5305-01-387-0742
Machine Screw
5305013870742 013870742 MS35205-46
An externally threaded fastener whose threaded portion is of one nominal diameter, No 0 (0.060 in./1.5 mm) or larger, designed to be held or driven with either a wrench or an inserted driver or both (excluding internal socket or internal multiple spline types), in sizes below No. 10 (0.190 in./5 mm). No. 10 and larger sizes must have a head designed for any type inserted driver (excluding internal socket or internal multiple spline types), but may also be designed for external wrenching. A locking feature may be incorporated in the design of the head or threads. Excludes BOLT, CLEVIS; BOLT, EXTERNALLY RELIEVED BODY; SCREW, EXTERNALLY RELIEVED BODY; and SCREW, ASSEMBLED WASHER. See also, SCREW, INSTRUMENT; BOLT, MACHINE; BOLT, INTERNAL WRENCHING; and SCREW, CAP SOCKET HEAD. View more Machine Screw
August 2025
1
Marketplace 5305-01-387-0742
Request a Quotation from participating marketplace vendors
Related Documents 5305-01-387-0742 2+ Documents (More...)
5305-01-387-0742 3+ Documents ( More... ) https//www.nsnlookup.com /fsg-53/fsc-5305/us 5305-01-387-0742
/fsg-53/fsc-5305/us 5305-01-387-0742 RQST NE Updated Every Day 5305-01-387-0742 RQST Updated Every Day
Machine Screw 5305013870742 013870742 Upgrade for $1 a day Upgrade your Account Upgrade 5305-01
-387-0742Machine Screw5305013870742 013870742 MS35205 https//www.nsnlookup.com /fsg-53/fsc-5305/us 5305
Restrictions 5305-01-387-0742
5305-01-387-0742 is a Machine Screw that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5305-01-387-0742
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5305-01-387-0742
- France (ZF01)
- Effective Date:
- 1 Feb 1994
Approved Sources 5305-01-387-0742
- Part Number
- Manufacturer
- Status
- MS35205-46
- Manufacturer
- 96906 - Military Standards (Active)
- Definitive Standard
- Definitive Standard
Datasheet 5305-01-387-0742
- Characteristic
- Specifications
- FIIG
- Specifications
- A500D0
- Fastener Length [AASB]
- 0.875 Inches Nominal
- Head Height [AASU]
- 0.115 Inches Nominal
- Head Diameter [AASL]
- 0.322 Inches Nominal
- Head Style [AASK]
- Pan
- Nominal Thread Diameter [AHYM]
- 0.164 Inches
- Internal Drive Style [ABQZ]
- Cross Recess Type 1
- Screw Material [CYAU]
- Steel Comp 1010
- Screw Surface Treatment [CYBA]
- Cadmium
- Thread Quantity Per Inch [CMLP]
- 36
- Thread Series Designator [THSD]
- Unf
- Specification/Standard Data [ZZZK]
- 96906-Ms35205-46 Government Standard
- Thread Direction [AAJF]
- Right-Hand
- Thread Class [AAJD]
- 2A
- Thread Length [AASA]
- 0.875 Inches Nominal
Similar Supply Items to 5305-01-387-0742
Freight Information 5305-01-387-0742
5305-01-387-0742 has freight characteristics.. 5305-01-387-0742 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
