5305-01-353-0294
Socket Head Cap Screw
5305013530294 013530294 NAS1351-10LE30P
An externally threaded fastener whose threaded portion is of one nominal diameter. The head has an internal socket or multiple spline for use with an inserted driver. A locking feature may be incorporated in the design of the head or threads. Excludes items with bevel (conical) heads. See BOLT, INTERNAL WRENCHING. Excludes SCREW, SHOULDER; and SCREW, MACHINE. View more Socket Head Cap Screw
May 2023
4
Marketplace 5305-01-353-0294
Request a Quotation from participating marketplace vendors
Related Documents 5305-01-353-0294 5+ Documents (More...)
Socket Head Cap Screw 5305013530294 Photo 1/3 NSN 5305-01-353-0294 (Identification) 2/3 NSN 5305-01-
353-0294 (Identification) 3/3 - RQST NE Updated Every Day 5305-01-353-0294 RQST Updated Every Day 5305
Restrictions 5305-01-353-0294
5305-01-353-0294 is a Socket Head Cap Screw that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5305-01-353-0294
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5305-01-353-0294
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5305-01-353-0294
- Part Number
- Manufacturer
- Status
- NAS1351-10LE30P
- Manufacturer
- 80205 - National Aerospace Standards (Active)
- Primary Buy
- Primary Buy
Datasheet 5305-01-353-0294
- Characteristic
- Specifications
- FIIG
- Specifications
- A003B0
- Fastener Length [AASB]
- 1.815 Inches Minimum And 1.875 Inches Maximum
- Hardness Rating [CQFM]
- 37.0 Rockwell C Minimum Overall And 45.0 Rockwell C Maximum Overall
- Head Diameter [AASL]
- 0.921 Inches Minimum And 0.937 Inches Maximum
- Head Height [AASU]
- 0.616 Inches Minimum And 0.625 Inches Maximum
- Head Style [AASK]
- Flat Chamfer
- Material [MATT]
- Steel Overall
- Minimum Yield Strength [CQHQ]
- 150000 Pounds Per Square Inch
- Minimum Tensile Strength [CQBC]
- 170000 Pounds Per Square Inch
- Nominal Thread Diameter [AHYM]
- 0.625 Inches
- Internal Drive Style [ABQZ]
- Hexagon
- Thread Series Designator [THSD]
- Unrf
- Width Across Flats [ASDB]
- 0.500 Inches Minimum And 0.505 Inches Maximum
- Surface Treatment Document And Classification [STDC]
- Qq-P-416 Ty 2,Cl 2 Fed Spec Single Treatment Response Overall
- Surface Treatment [SFTT]
- Cadmium Overall And Chromate Overall
- Thread Direction [AAJF]
- Right-Hand
- Thread Class [AAJD]
- 3A
- Thread Length [AASA]
- 1.750 Inches Minimum
- Thread Quantity Per Inch [CMLP]
- 18
Similar Supply Items to 5305-01-353-0294
Freight Information 5305-01-353-0294
5305-01-353-0294 has freight characteristics managed by Canada.. 5305-01-353-0294 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
