5305-01-286-0867
Socket Head Cap Screw
5305012860867 012860867 NAS1221-04E1L
An externally threaded fastener whose threaded portion is of one nominal diameter. The head has an internal socket or multiple spline for use with an inserted driver. A locking feature may be incorporated in the design of the head or threads. Excludes items with bevel (conical) heads. See BOLT, INTERNAL WRENCHING. Excludes SCREW, SHOULDER; and SCREW, MACHINE. View more Socket Head Cap Screw
May 2023
5
Marketplace 5305-01-286-0867
Request a Quotation from participating marketplace vendors
Related Documents 5305-01-286-0867 3+ Documents (More...)
BUY NE FedMall Updated Every Day 5305-01-286-0867 RQST NE Updated Every Day 5305-01-286-0867 RQST
Updated Every Day 5305-01-286-0867 RQST NE Related Documents 5305-01-286-0867 3+ Documents ( More...
Socket Head Cap Screw 5305012860867 Photo 1/3 NSN 5305-01-286-0867 (Identification) 2/3 NSN 5305
-01-286-0867 (Identification) 3/3 - - - Every Day 5305-01-286-0867 RQST NE Related Documents 5305-01-
Socket Head Cap Screw 5305012860867 US) 4. 5305-01-286-0867 Marketplace Restrictions https//www.nsnlookup.com
Restrictions 5305-01-286-0867
5305-01-286-0867 is a Socket Head Cap Screw that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5305-01-286-0867
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5305-01-286-0867
- US Air Force (FXGI)
- Effective Date:
- 1 Aug 2005
- Former MOE Rule:
- FXKZ
Approved Sources 5305-01-286-0867
- Part Number
- Manufacturer
- Status
- NAS1221-04E1L
- Manufacturer
- 80205 - National Aerospace Standards (Active)
- Primary Buy
- Primary Buy
Datasheet 5305-01-286-0867
- Characteristic
- Specifications
- FIIG
- Specifications
- A003B0
- Countersink Angle [CRSQ]
- 99.0 Degrees Minimum And 101.0 Degrees Maximum
- Fastener Length [AASB]
- 0.280 Inches Minimum And 0.310 Inches Maximum
- Hardness Rating [CQFM]
- 39.0 Rockwell C Minimum Fastener And 43.0 Rockwell C Maximum Fastener
- Head Diameter [AASL]
- 0.194 Inches Minimum And 0.225 Inches Maximum
- Head Style [AASK]
- Flat Countersunk
- Material [MATT]
- Iron Alloy 660 Fastener
- Material [MATT]
- Plastic Polyamide Locking Feature
- Minimum Tensile Strength [CQBC]
- 160000 Pounds Per Square Inch
- Nominal Thread Diameter [AHYM]
- 0.112 Inches
- Internal Drive Style [ABQZ]
- High-Torque
- Locking Feature [AAUM]
- Strip Threads Or Pellet Threads Or Patch Threads
- Material Document And Classification [MDCL]
- Ams 5731 Assn Std Single Material Response Fastener Or Ams 5737 Assn Std Single Material Response Fastener
- Thread Quantity Per Inch [CMLP]
- 40
- Thread Series Designator [THSD]
- Unjc
- Specification/Standard Data [ZZZK]
- 80205-Nas1221 Professional/Industrial Association Standard
- Surface Finish [CSYM]
- 32.0 Microinches Grip
- Surface Finish [CSYM]
- 32.0 Microinches Threads
- Surface Treatment Document And Classification [STDC]
- Qq-P-35 Fed Spec Single Treatment Response Fastener
- Surface Treatment [SFTT]
- Passivate Fastener
- Thread Direction [AAJF]
- Right-Hand
- Thread Class [AAJD]
- 3A
- Thread Length [AASA]
- 0.208 Inches Minimum And 0.258 Inches Maximum
Weapon Systems (WSDC) 5305-01-286-0867
DLA Procurement Analysis 5305-01-286-0867
Management Data 5305-01-286-0867
Similar Supply Items to 5305-01-286-0867
Freight Information 5305-01-286-0867
5305-01-286-0867 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 093486. A Sub NMFC of Z. It has a NMFC Description of BOLTS,NUTS OR SCREWS, NOI (SUB 3). 5305-01-286-0867 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 48950 which rates the freight between FCL and LCL. 5305-01-286-0867 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5305-01-286-0867 is not classified as a special type of cargo when transported by water. 5305-01-286-0867 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
