5305-00-998-3250
Tapping Screw
5305009983250 009983250 S1022Z6-10C
A hardened externally threaded fastener whose thread extends to the bearing surface of the head. The thread may be fluted or otherwise designed to cut or form its own mating thread. Excludes SCREW, ASSEMBLED WASHER. View more Tapping Screw
May 2023
9
Marketplace 5305-00-998-3250
Request a Quotation from participating marketplace vendors
Related Documents 5305-00-998-3250 5+ Documents (More...)
5305-00-998-3250 1+ Documents ( More... ) https//www.nsnlookup.com /fsg-53/fsc-5305/us 5305-00-998-3250
) 3/5 NSN 5305-00-998- 3250 (Identification) 4/5 NSN 5305-00-998-3250 (Identification) 5/5 - - - - -
Restrictions 5305-00-998-3250
5305-00-998-3250 is a Tapping Screw that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5305-00-998-3250
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5305-00-998-3250
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5305-00-998-3250
- Part Number
- Manufacturer
- Status
- S1022Z6-10C
- Manufacturer
- 7EK50 - Textron Aviation Inc (Active)
- Primary Buy
- Primary Buy
- S1022Z6-10C
- 71379 - Cessna Aircraft Company (Replaced)
- Original Design
- Original Design
Datasheet 5305-00-998-3250
- Characteristic
- Specifications
- FIIG
- Specifications
- A003B0
- Countersink Angle [CRSQ]
- 99.0 Degrees Minimum And 101.0 Degrees Maximum
- Fastener Length [AASB]
- 0.625 Inches Nominal
- Features Provided [CBBL]
- Casehardened
- Head Diameter [AASL]
- 0.257 Inches Minimum And 0.279 Inches Maximum
- Head Style [AASK]
- Flat Countersunk
- Material [MATT]
- Steel Comp 1010 Overall
- Nonmachine Nominal Thread Diameter [CTYF]
- 0.138 Inches
- Nonmachine Thread Style [CRGF]
- Dog Type (Type B Or C)
- Internal Drive Style [ABQZ]
- Cross Recess Type 1
- Surface Treatment [SFTT]
- Chromium Overall
Similar Supply Items to 5305-00-998-3250
Freight Information 5305-00-998-3250
5305-00-998-3250 has freight characteristics managed by the Southwestern Power Administration.It has a National Motor Freight Classification (NMFC) of 093486. A Sub NMFC of Z. It has a NMFC Description of BOLTS,NUTS OR SCREWS, NOI (SUB 3). 5305-00-998-3250 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 5305-00-998-3250 is rated as class 50 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 48950 which rates the freight between FCL and LCL. 5305-00-998-3250 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5305-00-998-3250 is not classified as a special type of cargo when transported by water. 5305-00-998-3250 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
