5305-00-984-7351

Machine Screw

5305009847351 009847351 18289ADX MS35191-275 FFS92 18289 402512801 CSA46415 10114781

An externally threaded fastener whose threaded portion is of one nominal diameter, No 0 (0.060 in./1.5 mm) or larger, designed to be held or driven with either a wrench or an inserted driver or both (excluding internal socket or internal multiple spline types), in sizes below No. 10 (0.190 in./5 mm). No. 10 and larger sizes must have a head designed for any type inserted driver (excluding internal socket or internal multiple spline types), but may also be designed for external wrenching. A locking feature may be incorporated in the design of the head or threads. Excludes BOLT, CLEVIS; BOLT, EXTERNALLY RELIEVED BODY; SCREW, EXTERNALLY RELIEVED BODY; and SCREW, ASSEMBLED WASHER. See also, SCREW, INSTRUMENT; BOLT, MACHINE; BOLT, INTERNAL WRENCHING; and SCREW, CAP SOCKET HEAD. View more Machine Screw

Managed by United States

NSN Created on 1 Jan 1962

Data Last Changed
July 2025

NATO Update Count
63

NATO Data Quality

5305-00-984-7351 SCREW,MACHINE 5305009847351 009847351 1/3 — 5305-00-984-7351 Photo 1/3

AASK Style A39 for 5305-00-984-7351 2/3 — NSN 5305-00-984-7351 (Identification) 2/3

ABQZ Style B1 for 5305-00-984-7351 3/3 — NSN 5305-00-984-7351 (Identification) 3/3

Marketplace 5305-00-984-7351

Need Help?
Request a Quotation from participating marketplace vendors

Subscribe to View Vendor Details...

MS35191-275 SCREW,MACHINE 1000 HD NS

Subscribe to View Vendor Details...

MS35191-275 SCREW,MACHINE 40 HD NS

Subscribe to View Vendor Details...

MS35191-275 SCREW,MACHINE 5 HD NS

Subscribe to View Vendor Details...

MS35191-275 SCREW,MACHINE 96 HD NS

Subscribe to View Vendor Details...

MS35191-275 SCREW,MACHINE 485 HD NS

Subscribe to View Vendor Details...

MS35191-275 SCREW,MACHINE 118 HD NS

Subscribe to View Vendor Details...

MS35191-275 SCREW,MACHINE 93 HD NS

Subscribe to View Vendor Details...

MS35191-275 SCREW,MACHINE 400 HD NS

Subscribe to View Vendor Details...

MS35191-275 SCREW,MACHINE 200 HD NS

Subscribe to View Vendor Details...

MS35191-275 SCREW,MACHINE 32 HD NS

Subscribe to View Vendor Details...

MS35191-275 SCREW,MACHINE 1 HD NS

Updated Every Day

5305-00-984-7351 RQST NE

Updated Every Day

5305-00-984-7351 RQST

Updated Every Day

5305-00-984-7351 RQST NE

Restrictions 5305-00-984-7351

5305-00-984-7351 is a Machine Screw that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.

Import and Export 5305-00-984-7351

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 5305-00-984-7351

US Army (A919)
Effective Date:: 1 Apr 2006
Former MOE Rule:: A187
Supplementary Receivers:: AZBFBD; AMC 1 AMSC G IMC Z IMCACTY CD

US Coast Guard (C918)
Effective Date:: 1 Apr 2006
Former MOE Rule:: C004
Supplementary Receivers:: XH; AMC 1 AMSC G

US Air Force (FXGI)
Effective Date:: 1 Apr 2006
Former MOE Rule:: FXKZ; AMC 1 AMSC G IMC Z IMCACTY SX

NASA (G860)
Effective Date:: 1 Apr 1991; AMC 0 AMSC 0 AAC C

US Marine Corps (MC47)
Effective Date:: 1 Apr 2006
Former MOE Rule:: MC10; AMC 1 AMSC G IMC Z IMCACTY PA

US Navy (N9BZ)
Effective Date:: 1 Apr 2006
Former MOE Rule:: NIZD
Supplementary Collaborators:: GTKEJFHD; AMC 1 AMSC G IMC Z IMCACTY GH

Austria (WB01)
Effective Date:: 1 Feb 2005

Finland (WF01)
Effective Date:: 1 Apr 2009

Lithuania (WI01)
Effective Date:: 1 Feb 2001

Poland (WP01)
Effective Date:: 1 Nov 2006

Czech Republic (WZ01)
Effective Date:: 1 Mar 2010

MOE Rule:: X002
Effective Date:: 1 Apr 1991

Brazil (YA01)
Effective Date:: 1 Oct 2001

Spain (YB01)
Effective Date:: 1 Apr 1991

Columbia (YC01)
Effective Date:: 1 Jul 2015

Singapore (YJ01)
Effective Date:: 1 Apr 1991

Morocco (YP01)
Effective Date:: 1 Feb 2012

Malaysia (YW01)
Effective Date:: 1 Mar 1997

Australia (ZA01)
Effective Date:: 1 Apr 1991

Canada (ZC01)
Effective Date:: 1 Apr 1991

New Zealand (ZE01)
Effective Date:: 1 Apr 2008

France (ZF01)
Effective Date:: 1 Apr 1991

Germany (ZG01)
Effective Date:: 1 Apr 1991

Republic of Korea (ZH01)
Effective Date:: 1 Apr 1991

United Kingdom (ZK01)
Effective Date:: 1 Apr 1991

Portugal (ZP01)
Effective Date:: 1 Apr 1991

Italy (ZR01)
Effective Date:: 1 Apr 1991

Denmark (ZS01)
Effective Date:: 1 Apr 1991

Norway (ZT01)
Effective Date:: 1 Apr 1991

Greece (ZU01)
Effective Date:: 1 Apr 1991

Turkey (ZW01)
Effective Date:: 1 Aug 1993

Approved Sources 5305-00-984-7351

Part Number
Manufacturer
Status
MS35191-275: 96906 - Military Standards (Active); Definitive Standard; RNCC 2 RNVC 2 DAC E
18289ADX: 1VN02 - Airdale Express Llc (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 4
18289: 73734 - Federal Screw Products Inc. (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 4
402512801: S5686 - Israel Military Industries Ltd (Replaced); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 1
5305009847351: SCY13 - E.C.A Etablissement (Replaced); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 9
CSA46415: 82254 - Curtis Dyna-Fog, Ltd. (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
10114781: A486G - Nimikkeistokeskus Ncb Finland (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9
402512801: 1919A - Imi Systems Ltd (Active); Advisory Reference; RNCC C RNVC 1 DAC 1
FFS92: 81348 - Federal Specifications Promulgated (Active); Transferred; RNCC E RNVC 8 DAC 3

Datasheet 5305-00-984-7351

Characteristic
Specifications
FIIG: A500D0
Countersink Angle [CRSQ]: 80.0 Degrees Minimum And 82.0 Degrees Maximum
Fastener Length [AASB]: 0.875 Inches Nominal
Head Diameter [AASL]: 0.340 Inches Minimum And 0.385 Inches Maximum
Head Style [AASK]: Flat Countersunk
Minimum Tensile Strength [CQBC]: 55000 Pounds Per Square Inch
Nominal Thread Diameter [AHYM]: 0.190 Inches
Internal Drive Style [ABQZ]: Cross Recess Type 1
Screw Material Document And Classification [CYAW]: 66 Fed Std All Material Responses
Screw Material [CYAU]: Steel Comp 1010 Or Steel Comp 1011 Or Steel Comp 1013
Screw Surface Treatment Document And Classification [CYBE]: Qq-P-416 Ty 2 Cl 3 Fed Spec Single Treatment Response
Screw Surface Treatment [CYBA]: Cadmium And Chromate
Thread Class [AAJD]: 2A
Thread Direction [AAJF]: Right-Hand
Thread Length [AASA]: 0.813 Inches Minimum And 0.875 Inches Maximum
Thread Series Designator [THSD]: Unf
Thread Quantity Per Inch [CMLP]: 32

Weapon Systems (WSDC) 5305-00-984-7351

Subscribe
View WSDC

Subscribe to View Weapon System Codes...

Subscribe
View Data

DLA Procurement Analysis 5305-00-984-7351

Last Stock Position:: 10700 In Stock
DLA Administrative Lead Time:: Subscribe
DLA Production Lead Time:: Subscribe

Subscribe to View DLA Inventory and Forecast...

Management Data 5305-00-984-7351

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Oct 2022: US Marine Corps (DM); HD; Subscribe; 1
Dec 2021: Department of the Army (DA); HD; Subscribe; 1
Oct 2021: US Marine Corps (DM); HD; Subscribe; 1
Dec 2020: Defense Logistics Agency (DS); HD; Subscribe; 1
Oct 2019: Department of the Air Force (DF); HD; Subscribe; 1

Army

Materiel Category and Inventory Manager:

T: Industrial Supplies (DLA/GSA Items)

Appropriation and Budget Activity:

2: Stock Fund Secondary Items

Management Inventory Segment:

2: Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.

Weapons System / End Item / Homogeneous Group:

00: DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item

Accounting Requirements:

X: Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.

Navy

Cognizance:

9B: Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg

Marine Corps

Stores Account:

1: Stock Fund Account Item

Combat Essentiality:

5: Critical Repair Part to a Combat Essential End Item

Echelon Management:

B2

Operational Test:

: No Special Procedures

Physical Category:

1: Bin

Similar Supply Items to 5305-00-984-7351

Freight Information 5305-00-984-7351

5305-00-984-7351 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 093486. A Sub NMFC of Z. It has a NMFC Description of BOLTS,NUTS OR SCREWS, NOI (SUB 3). 5305-00-984-7351 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 48950 which rates the freight between FCL and LCL. 5305-00-984-7351 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5305-00-984-7351 is not classified as a special type of cargo when transported by water. 5305-00-984-7351 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 5305-00-984-7351

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); --

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; Plated/Coated Item; 2lb or less, one dimension 2" or less, other dimensions less than 24"; Above 110G; No Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; --; --; --; Physical Protection; Any Suitable Process

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: No Requirement; No Requirement; No Requirement; Not Applicable; PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box; No special marking

Intermediate Pack Level

Quantity of Unit Packs
Container: PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box

Contracting Technical Data File (CTDF) 5305-00-984-7351 October 2020

Criticality and Quality

Critical Item Code:: X
Flight Safety:
Life Support:
Certified Samples:
Serialization:
First Article Test (FAT):
Certificate of Quality Compliance:
Production Lot Testing:
Special Testing:
Qualified Products List (QPL):

Commercial Properties

Government Furnished Material:
Government Furnished Tooling:
Government Furnished Property:
Price Evaluation Code:
Diminshing Manufacturing Sources:
Warranty:
Commerical Off The Shelf (COTS):
End Item Application:
Auctioning Candidate:
Source of Procurement:
Contract Option:

Restrictions

Boeing Rights Guard:
Export Controlled:
Controlled Technical Data Package (TDP):
Restricted Technical Data Package (TDP):
Contains Classified Material
Weapons System Indicator Code (WSIC):: F

Packaging Requirements

Packaging Determination Table:
Packaging Review Code:: N
Special Packaging Instruction Number (SPIN):
Special Packaging Instruction Number Revision:
Special Packaging Instruction Number Date:
Pallet Reference Number Required:

Subscribe
View CTDF

Subscribe to View CTDF Details...
