5305-00-682-5972
Setscrew
5305006825972 006825972 FFS103TYPE3STYLE4 1885HX 730-990120-811 83-56 003-07941-070 5/16-18UNC-3AX3/8LG 109A2-X-24 MS51021-70
An externally threaded device whose threaded portion is of one nominal diameter with or without a head and having a cup, cone, or other type of machined point designed to prevent or restrict relative movement of parts and designed to be driven with either a wrench or inserted driver. A locking feature may be incorporated in the design of the head or threads. View more Setscrew
Managed by United States
NSN Created on 1 Jan 1963
Data Last Changed
November 2023
November 2023
NATO Update Count
40
40
NATO Data Quality
Marketplace 5305-00-682-5972
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 5305-00-682-5972 5+ Documents (More...)
FFS103TYPE3STYLE4 1885HX 730-990120-811 83-56 003-07941-070 5/16-18UNC-3AX3/8LG 109A2-X-24 MS51021-70
(Identification) 1/3 NSN 5305-00-682-5972 (Identification) 2/3 NSN 5305-00-682-5972 (Identification
MS51021-70 SETSCREW 90 PG NS Request Quotation Updated Every Day 5305-00-682-5972 RQST NE Updated Every
(Identification) 1/3 NSN 5305-00-682-5972 (Identification) 2/3 NSN 5305-00-682-5972 (Identification
MS51021-70 SETSCREW 90 PG NS Request Quotation Updated Every Day 5305-00-682-5972 RQST NE Updated Every
MS51021-70 SETSCREW 474 EA NS Request Quotation Subscribe to View Vendor Details... 8356 SETSCREW 99
FFS103TYPE3STYLE4 SETSCREW 1 EA NS Request Quotation Subscribe to View Vendor Details... 8356 SETSCREW
MS51021-70 SETSCREW 95 EA NS Request Quotation 8356 SETSCREW 24 EA NS Request Quotation Subscribe to
FFS103TYPE3STYLE4 SETSCREW 1 EA NS Request Quotation Subscribe to View Vendor Details... 8356 SETSCREW
MS51021-70 SETSCREW 95 EA NS Request Quotation 8356 SETSCREW 24 EA NS Request Quotation Subscribe to
FFS103TYPE3STYLE4 SETSCREW 1 EA NS Request Quotation Subscribe to View Vendor Details...
SETSCREW 1 EA NS Request Quotation Updated Every Day 125735 RQST NE Updated Every FFS103TYPE3STYLE4
/fsg-53/fsc-5305/us 5305-00-638-8757 Setscrew 5305006388757 006388757 FFS103TYPE3STYLE4 SETSCREW 1 EA
SETSCREW 1 EA NS Request Quotation Updated Every Day 125735 RQST NE Updated Every FFS103TYPE3STYLE4
/fsg-53/fsc-5305/us 5305-00-638-8757 Setscrew 5305006388757 006388757 FFS103TYPE3STYLE4 SETSCREW 1 EA
FFS103TYPE3STYLE4 SETSCREW 1 EA NS Request Quotation Updated Every Day 5305-00-057-1341 RQST NE Updated
SETSCREW 1 EA NS Request Quotation Updated Every Day 125735 RQST NE Updated Every FFS103TYPE3STYLE4
SETSCREW 1 EA NS Request Quotation Updated Every Day 125735 RQST NE Updated Every FFS103TYPE3STYLE4 https
SETSCREW 1 EA NS Request Quotation Updated Every Day 125735 RQST NE Updated Every FFS103TYPE3STYLE4
SETSCREW 1 EA NS Request Quotation Updated Every Day 125735 RQST NE Updated Every FFS103TYPE3STYLE4 https
FFS103TYPE3STYLE4 SETSCREW 1 EA NS Request Quotation Updated Every Day 5305-00-576-5488 RQST NE Updated
SETSCREW 1 EA NS Request Quotation Updated Every Day 125735 RQST NE Updated Every FFS103TYPE3STYLE4
SETSCREW 1 EA NS Request Quotation Updated Every Day 125735 RQST NE Updated Every FFS103TYPE3STYLE4
SETSCREW 1 EA NS Request Quotation Updated Every Day 125735 RQST NE Updated Every FFS103TYPE3STYLE4
SETSCREW 1 EA NS Request Quotation Updated Every Day 125735 RQST NE Updated Every FFS103TYPE3STYLE4
Restrictions 5305-00-682-5972
5305-00-682-5972 is a Setscrew that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5305-00-682-5972
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5305-00-682-5972
- US Army (A919)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- A187
- Supplementary Receivers:
- AJCLAZ
- US Coast Guard (C918)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- C004
- US Air Force (FXGI)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- FXKZ
- NASA (G800)
- Effective Date:
- 1 Apr 1991
- US Marine Corps (MC47)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- MC10
- US Navy (N9BZ)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- NIZD
- Supplementary Collaborators:
- GTKEJVHXHSHD
- MOE Rule:
- S911
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- S006
- Lithuania (WI01)
- Effective Date:
- 1 Feb 2001
- Brazil (YA01)
- Effective Date:
- 1 Dec 2001
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Kuwait (YK01)
- Effective Date:
- 1 Jan 2015
- Saudi Arabia (YS01)
- Effective Date:
- 1 Feb 2015
- Malaysia (YW01)
- Effective Date:
- 1 Jan 1998
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- United Kingdom (ZK01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
- Greece (ZU01)
- Effective Date:
- 1 Jun 2005
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 5305-00-682-5972
- Part Number
- Manufacturer
- Status
- MS51021-70
- Manufacturer
- 80205 - National Aerospace Standards (Active)
- Primary Buy
- Primary Buy
- FFS103TYPE3STYLE4
- 81348 - Federal Specifications Promulgated (Active)
- Incomplete Standard
- Incomplete Standard
- MS51021-70
- 96906 - Military Standards (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 730-990120-811
- 38753 - Cmc Electronics Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 1885HX
- 45152 - Oshkosh Corp (Active)
- Advisory Reference
- Advisory Reference
- 730-990120-811
- 90073 - Cmc Electronics Inc (Active)
- Advisory Reference
- Advisory Reference
- 83-56
- 10988 - Cnh Industrial America Llc (Active)
- Advisory Reference
- Advisory Reference
- 003-07941-070
- 26916 - Northrop Grumman Systems Corporation (Active)
- Advisory Reference
- Advisory Reference
- 5/16-18UNC-3AX3/8LG
- 81349 - Military Specifications (Active)
- Advisory Reference
- Advisory Reference
- 109A2-X-24
- 88032 - Curtiss-Wright Electro-Mechanical (Replaced)
- Advisory Reference
- Advisory Reference
Datasheet 5305-00-682-5972
- Characteristic
- Specifications
- FIIG
- Specifications
- A003B0
- Fastener Length [AASB]
- 0.375 Inches Nominal
- Head Style [AASK]
- Headless (Setscrew)
- Material [MATT]
- Steel Comp 302 Overall Or Steel Comp 303 Overall Or Steel Comp 304 Overall Or Steel Comp 316 Overall
- Nominal Thread Diameter [AHYM]
- 0.312 Inches
- Internal Drive Style [ABQZ]
- Hexagon
- Material Document And Classification [MDCL]
- 66 Fed Std All Material Responses Overall
- Point Style [ABQJ]
- Cup
- Width Across Flats [ASDB]
- 0.156 Inches Nominal
- Surface Treatment Document And Classification [STDC]
- Qq-P-35 Fed Spec Single Treatment Response Overall
- Surface Treatment [SFTT]
- Passivate Overall
- Thread Direction [AAJF]
- Right-Hand
- Thread Class [AAJD]
- 3A
- Thread Length [AASA]
- 0.375 Inches Maximum
- Thread Quantity Per Inch [CMLP]
- 18
- Thread Series Designator [THSD]
- Unc
Weapon Systems (WSDC) 5305-00-682-5972
DLA Procurement Analysis 5305-00-682-5972
- Last Stock Position:
- 4200 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5305-00-682-5972
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- SX
- SICA RESIDUAL MMAC-OC-ALC
- Price Validation Code:
- V
- The current standard price has been validated.
The item has been analyzed in conjunction with the Zero Overpricing Program and is in the accepted price range.
The item was procured under open competition and under the competitive arena the price is considered fair and reasonable.
ZOP or Standard price challenges are permissible but must be supported by adequate justification.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- B2
- Operational Test:
- No Special Procedures
NATO Stock Numbers Related to 5305-00-682-5972
5305-99-941-1702 5305-99-051-7320 5305-12-183-2648 5305-21-843-5713 5305-12-323-3472 5305-99-136-5917 5305-99-479-6518 5305-99-171-1422 5305-34-041-0729 5305-99-528-0948 5305-17-123-3010 5305-99-128-3099 5305-25-122-3884 5305-13-800-0628 5305-99-128-6493 5305-99-110-7998 5305-21-886-2639 5305-12-159-1482
Freight Information 5305-00-682-5972
5305-00-682-5972 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 093486. A Sub NMFC of Z. It has a NMFC Description of BOLTS,NUTS OR SCREWS, NOI (SUB 3). 5305-00-682-5972 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 48950 which rates the freight between FCL and LCL. 5305-00-682-5972 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5305-00-682-5972 is not classified as a special type of cargo when transported by water. 5305-00-682-5972 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5305-00-682-5972
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
Contracting Technical Data File (CTDF) 5305-00-682-5972 October 2020
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
