5305-00-639-0967
Tapping Screw
5305006390967 006390967 FFS107
A hardened externally threaded fastener whose thread extends to the bearing surface of the head. The thread may be fluted or otherwise designed to cut or form its own mating thread. Excludes SCREW, ASSEMBLED WASHER. View more Tapping Screw
June 2023
5
Marketplace 5305-00-639-0967
Request a Quotation from participating marketplace vendors
Related Documents 5305-00-639-0967 5+ Documents (More...)
FFS107 SCREW,TAPPING 7 EA NS Request Quotation Updated Every Day 5305-00-639-0967 RQST NE Updated Every
Day 5305-00-639-0967 RQST Updated Every Day 5305-00-639-0967 RQST NE Related Documents 5305-00-639-0967
Restrictions 5305-00-639-0967
5305-00-639-0967 is a Tapping Screw that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5305-00-639-0967
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5305-00-639-0967
- NASA (G760)
- Effective Date:
- 1 Apr 1991
Approved Sources 5305-00-639-0967
- Part Number
- Manufacturer
- Status
- FFS107
- Manufacturer
- 81348 - Federal Specifications Promulgated (Active)
- Incomplete Standard
- Incomplete Standard
Datasheet 5305-00-639-0967
- Characteristic
- Specifications
- FIIG
- Specifications
- A003B0
- Countersink Angle [CRSQ]
- 80.0 Degrees Minimum And 82.0 Degrees Maximum
- Fastener Length [AASB]
- 0.500 Inches Nominal
- Features Provided [CBBL]
- Casehardened
- Head Diameter [AASL]
- 0.195 Inches Minimum And 0.225 Inches Maximum
- Head Style [AASK]
- Flat Countersunk
- Material [MATT]
- Steel Overall
- Nondefinitive Spec/Std Data [ZZZT]
- A Type
- Nonmachine Nominal Thread Diameter [CTYF]
- 0.112 Inches
- Nonmachine Thread Style [CRGF]
- Gimlet Point (Type A, Ab Or Ba)
- Internal Drive Style [ABQZ]
- Slot
- Special Features [FEAT]
- Head Style,Flat Slotted
Similar Supply Items to 5305-00-639-0967
Freight Information 5305-00-639-0967
5305-00-639-0967 has freight characteristics.. 5305-00-639-0967 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
