5305-00-488-4363
Socket Head Cap Screw
5305004884363 004884363 67487
An externally threaded fastener whose threaded portion is of one nominal diameter. The head has an internal socket or multiple spline for use with an inserted driver. A locking feature may be incorporated in the design of the head or threads. Excludes items with bevel (conical) heads. See BOLT, INTERNAL WRENCHING. Excludes SCREW, SHOULDER; and SCREW, MACHINE. View more Socket Head Cap Screw
Managed by United States
NSN Created on 28 May 1970
Data Last Changed
November 2023
November 2023
NATO Update Count
8
8
NATO Data Quality
Marketplace 5305-00-488-4363
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 5305-00-488-4363 5+ Documents (More...)
Photo 1/3 NSN 5305-00-488-4363 (Identification) 2/3 NSN 5305-00-488-4363 (Identification) 3/3 -
NS Request Quotation 67487 SCREW 12 EA NS Request Quotation Updated Every Day 5305-00-488-4363 RQST
NE Updated Every Day 5305-00-488-4363 RQST Updated Every Day 5305-00-488-4363 RQST NE Related Documents
NS Request Quotation 67487 SCREW 12 EA NS Request Quotation Updated Every Day 5305-00-488-4363 RQST
NE Updated Every Day 5305-00-488-4363 RQST Updated Every Day 5305-00-488-4363 RQST NE Related Documents
https//www.nsnlookup.com /fsg-59/fsc-5930/us 5930-01-442-8846 Rotary Switch 5930014428846014428846,W-67487
-442-8846 5+ Documents ( More... ) https//www.nsnlookup.com Rotary Switch 5930014428846014428846,W-67487
A switch actuated by a definite angular https//www.nsnlookup.com /fsg-53/fsc-5305/us 5305-00-488-4363
-442-8846 5+ Documents ( More... ) https//www.nsnlookup.com Rotary Switch 5930014428846014428846,W-67487
A switch actuated by a definite angular https//www.nsnlookup.com /fsg-53/fsc-5305/us 5305-00-488-4363
a day Upgrade your Account Upgrade 5340-00-104-2556Nonmetallic Bumper5340001042556 001042556 6420-67487
Quotation from participating marketplace vendors Request Subscribe to View Vendor Details... 6420-67487
a day Upgrade your Account Upgrade 5340-00-104-2556Nonmetallic Bumper5340001042556 001042556 6420-67487
Quotation from participating marketplace vendors Request Subscribe to View Vendor Details... 6420-67487
a day Upgrade your Account Upgrade 5340-00-104-2556Nonmetallic Bumper5340001042556 001042556 6420-67487
enable JavaScript in your web browser . 3820-21-802-5388Paving Breaker Chisel3820218025388 218025388 67487
3820/ca 3820-21-802-5388 Paving Breaker Chisel 3820218025388218025388 NumberManufacturerStatus6420-67487
Oil Pan 2815007882834 007882834,67487 PACKING OIL PAN 3 EA NS Request Quotation Updated Every Day 67487
3820/ca 3820-21-802-5388 Paving Breaker Chisel 3820218025388218025388 NumberManufacturerStatus6420-67487
Oil Pan 2815007882834 007882834,67487 PACKING OIL PAN 3 EA NS Request Quotation Updated Every Day 67487
PACKING OIL PAN 3 EA NS Request Quotation Updated Every Day 67487 RQST NE Updated Every Day 2815-00-
PACKING OIL PAN 3 EA NS Request Quotation Updated Every Day 67487 RQST NE Updated Every Day 2815-00-
a day Upgrade your Account Upgrade 5340-00-104-2556Nonmetallic Bumper5340001042556 001042556 6420-67487
PACKING OIL PAN 3 EA NS Request Quotation Updated Every Day 67487 RQST NE Updated Every Day 2815-00-
a day Upgrade your Account Upgrade 5340-00-104-2556Nonmetallic Bumper5340001042556 001042556 6420-67487
Restrictions 5305-00-488-4363
5305-00-488-4363 is a Socket Head Cap Screw that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5305-00-488-4363
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5305-00-488-4363
- US Army (A919)
- Effective Date:
- 1 Sep 2005
- Former MOE Rule:
- A187
- US Air Force (FXGI)
- Effective Date:
- 1 Sep 2005
- Former MOE Rule:
- FXKZ
- US Navy (N9BZ)
- Effective Date:
- 1 Sep 2005
- Former MOE Rule:
- N9ZD
- Supplementary Collaborators:
- GTKEHD
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Jun 2005
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 5305-00-488-4363
- Part Number
- Manufacturer
- Status
- 67487
- Manufacturer
- 93835 - Parker-Hannifin Corp (Active)
- Primary Buy
- Primary Buy
Datasheet 5305-00-488-4363
- Characteristic
- Specifications
- FIIG
- Specifications
- A003B0
- Distance From Head Largest Bearing Surface To Shank Hole Center [CRZS]
- 0.825 Inches Nominal First Hole
- Fastener Length [AASB]
- 0.880 Inches Nominal
- Hardness Rating [CQFM]
- 36.0 Rockwell C Minimum Overall And 45.0 Rockwell C Maximum Overall
- Head Diameter [AASL]
- 0.250 Inches Minimum And 0.262 Inches Maximum
- Head Height [AASU]
- 0.063 Inches Minimum And 0.073 Inches Maximum
- Head Style [AASK]
- Button
- Material [MATT]
- Steel Overall
- Minimum Yield Strength [CQHQ]
- 130000 Pounds Per Square Inch
- Minimum Tensile Strength [CQBC]
- 160000 Pounds Per Square Inch
- Nominal Thread Diameter [AHYM]
- 0.138 Inches
- Internal Drive Style [ABQZ]
- Hexagon
- Material Document And Classification [MDCL]
- 66 Fed Std Single Material Response Overall
- Shank Unthreaded Hole Diameter [AAWB]
- 0.040 Inches Nominal First Hole
- Width Across Flats [ASDB]
- 0.078 Inches Nominal
- Thread Class [AAJD]
- 3A
- Thread Direction [AAJF]
- Right-Hand
- Thread Length [AASA]
- 0.530 Inches Minimum
- Thread Quantity Per Inch [CMLP]
- 40
- Thread Series Designator [THSD]
- Unf
Weapon Systems (WSDC) 5305-00-488-4363
DLA Procurement Analysis 5305-00-488-4363
- Last Stock Position:
- 147 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5305-00-488-4363
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- SX
- SICA RESIDUAL MMAC-OC-ALC
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5305-00-488-4363
Freight Information 5305-00-488-4363
5305-00-488-4363 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 096640. A Sub NMFC of X. It has a NMFC Description of SCREWS, IRON OR STEEL. 5305-00-488-4363 is rated as class 70 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 50600 which rates the freight between FCL and LCL. 5305-00-488-4363 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5305-00-488-4363 is not classified as a special type of cargo when transported by water. 5305-00-488-4363 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5305-00-488-4363
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- Any Suitable Container
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
