5305-00-482-4381
Externally Relieved Body Screw
5305004824381 004824381 001621
An externally threaded fastener whose threaded portion is of one nominal diameter, and whose unthreaded portion has been machined or ground in one or more places or over its entire length to a maximum diameter less than the minimum pitch diameter of the thread (excludes undercut for thread relief). It is No. 0 (0.060 IN.) (1.5 mm) or larger, and is designed to be held or driven with either a wrench or inserted driver (excluding internal socket and multiple spline types) or both in sizes below No. 10 (0.190 IN.) (5 mm) and larger sizes must have a head designed for any type inserted driver (excluding internal socket and multiple spline types) but may also be designed for external wrenching. A locking feature may be incorporated in the design of the head or threads. See also BOLT, EXTERNALLY RELIEVED BODY and BOLT, INTERNAL WRENCHING. View more Externally Relieved Body Screw
May 2023
4
Marketplace 5305-00-482-4381
Request a Quotation from participating marketplace vendors
Related Documents 5305-00-482-4381 5+ Documents (More...)
RQST NE Updated Every Day 5305-00-482-4381 RQST Updated Every Day 5305-00-482-4381 RQST NE Related
-00-482-4381 Externally Relieved Body Screw 5305004824381 001621 An externally threaded fastener whose
001621 482-4381 Externally Relieved Body Screw 5305004824381 Semiconductor Device5961010458241 010458241
Externally Relieved Body Screw 5305004824381 5305-00-482-4381 Externally Relieved Body Screw 5305004824381
Film Pack Adapter6760121247017 121247017 001621 https//www.nsnlookup.com /fsg-53/fsc-5305/us 5305-00
Relieved Body Screw5305004824381 004824381 001621 482-4381 Externally Relieved Body Screw 5305004824381
Every Day 5315-33-103-1536 RQST NE Restrictions https//www.nsnlookup.com /fsg-53/fsc-5305/us 5305-00-482-4381
Externally Relieved Body Screw 5305004824381 Semiconductor Device5961010458241 010458241 001621
is a Externally Relieved Body Screw Similar Supply Items to 9999-99-146-9590 5305-01-546-8546 5305-00-482-4381
Restrictions 5305-00-482-4381
5305-00-482-4381 is a Externally Relieved Body Screw that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5305-00-482-4381
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5305-00-482-4381
- US Air Force (FXGI)
- Effective Date:
- 1 Mar 2006
- Former MOE Rule:
- FXKZ
- US Navy (N9BZ)
- Effective Date:
- 1 Mar 2014
- Supplementary Collaborators:
- HDKEHX
- Republic of Korea (ZH01)
- Effective Date:
- 1 May 2004
- Greece (ZU01)
- Effective Date:
- 1 Apr 2008
Approved Sources 5305-00-482-4381
- Part Number
- Manufacturer
- Status
- 001621
- Manufacturer
- K6111 - Qioptiq Ltd (Active)
- Primary Buy
- Primary Buy
Datasheet 5305-00-482-4381
- Characteristic
- Specifications
- FIIG
- Specifications
- A003B0
- Distance From Largest Bearing Surface Of Head To End Of First Diameter [AAWH]
- 0.470 Inches Minimum And 0.530 Inches Maximum
- Externally Relieved Body Diameter Quantity [CSNG]
- 1
- Fastener Length [AASB]
- 0.855 Inches Minimum And 0.885 Inches Maximum
- First Diameter From Head [AAWC]
- 0.119 Inches Minimum And 0.121 Inches Maximum
- Head Diameter [AASL]
- 0.295 Inches Minimum And 0.325 Inches Maximum
- Head Height [AASU]
- 0.050 Inches Nominal
- Head Style [AASK]
- Fillister
- Material [MATT]
- Steel Corrosion Resisting Overall
- Nominal Thread Diameter [AHYM]
- 0.164 Inches
- Internal Drive Style [ABQZ]
- Slot
- Material Document And Classification [MDCL]
- Astm A582 Assn Std Single Material Response Overall Or B.S.970 En58 Fscm K6111 Mfr Ref Single Material Response Overall
- Special Features [FEAT]
- Color Black
- Surface Treatment Document And Classification [STDC]
- P.I.S.2015 Fscm K6111 Mfr Ref Single Treatment Response Overall
- Surface Treatment [SFTT]
- Dichromate Sodium Overall
- Thread Class [AAJD]
- 2A
- Thread Direction [AAJF]
- Right-Hand
- Thread Length [AASA]
- 0.355 Inches Minimum And 0.385 Inches Maximum
- Thread Quantity Per Inch [CMLP]
- 32
- Thread Series Designator [THSD]
- Unc
Weapon Systems (WSDC) 5305-00-482-4381
DLA Procurement Analysis 5305-00-482-4381
Management Data 5305-00-482-4381
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5305-00-482-4381
Freight Information 5305-00-482-4381
5305-00-482-4381 has freight characteristics managed by the Southwestern Power Administration.It has a National Motor Freight Classification (NMFC) of 093486. A Sub NMFC of Z. It has a NMFC Description of BOLTS,NUTS OR SCREWS, NOI (SUB 3). 5305-00-482-4381 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 48950 which rates the freight between FCL and LCL. 5305-00-482-4381 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5305-00-482-4381 is not classified as a special type of cargo when transported by water. 5305-00-482-4381 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
