5305-00-411-7723
Socket Head Cap Screw
5305004117723 004117723 FFS86 81706676-1 NAS1352C08H6 A01406-406 5305PL0728681
An externally threaded fastener whose threaded portion is of one nominal diameter. The head has an internal socket or multiple spline for use with an inserted driver. A locking feature may be incorporated in the design of the head or threads. Excludes items with bevel (conical) heads. See BOLT, INTERNAL WRENCHING. Excludes SCREW, SHOULDER; and SCREW, MACHINE. View more Socket Head Cap Screw
Managed by United States
NSN Created on 5 Sep 1969
Data Last Changed
November 2023
November 2023
NATO Update Count
42
42
NATO Data Quality
Marketplace 5305-00-411-7723
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
FF-S86 SCREW,CAP,SOCKET HEAD 175 EA NS
FFS86 SCREW,CAP,SOCKET HEAD 57 EA NS
NAS1352C08H6 SCREW,CAP,SOCKET HEAD 20609 EA NS
FFS86 SCREW,CAP,SOCKET HEAD 150 EA NS
FF-S-86 SCREW,CAP,SOCKET HEAD 18 EA NS
NAS1352C08H6 SCREW,CAP,SOCKET HEAD 139 EA NS
Updated Every Day 5305-00-411-7723 RQST NE
Updated Every Day 5305-00-411-7723 RQST
Updated Every Day 5305-00-411-7723 RQST NE
Related Documents 5305-00-411-7723 5+ Documents (More...)
FFS86 NAS1352C08H6 81706676-1 A01406-406 5305PL0728681 An externally threaded fastener whose threaded
Photo 1/4 NSN 5305-00-411-7723 (Identification) 2/4 NSN 5305-00-411-7723 (Identification) 3/4 NSN
FFS86 SCREW,CAP,SOCKET HEAD 12 EA NS Request Quotation NAS1352C08H6 SCREW,CAP,SOCKET HEAD 22 EA NS Request
Photo 1/4 NSN 5305-00-411-7723 (Identification) 2/4 NSN 5305-00-411-7723 (Identification) 3/4 NSN
FFS86 SCREW,CAP,SOCKET HEAD 12 EA NS Request Quotation NAS1352C08H6 SCREW,CAP,SOCKET HEAD 22 EA NS Request
NAS1352C08H6 SCREW,CAP,SOCKET HEAD 2 EA NS Request Quotation Subscribe to View Vendor Details...
FFS86 SCREW,CAP,SOCKET HEAD 1 EA NS Request Quotation Subscribe to View Vendor Details...
NAS1352C08H6 SCREW,CAP,SOCKET HEAD 118 EA NS Request Quotation NAS1352C08H6 SCREW,CAP,SOCKET HEAD 118
FFS86 SCREW,CAP,SOCKET HEAD 1 EA NS Request Quotation Subscribe to View Vendor Details...
NAS1352C08H6 SCREW,CAP,SOCKET HEAD 118 EA NS Request Quotation NAS1352C08H6 SCREW,CAP,SOCKET HEAD 118
$1 a day Upgrade your Account Upgrade 5305-01-439-5928Socket Head Cap Screw5305014395928 014395928 FFS86
,TY4,(.5-13UNC-2AXLLG) FFS86,TY4,(.5-1 3UNC-2AX1LG) An externally threaded fastener whose threaded portion
https//www.nsnlookup.com /fsg-53/fsc-5305/us 5305-01-439-5928 Socket Head Cap Screw 5305014395928 FFS86
,TY4,(.5-13UNC-2AXLLG) FFS86,TY4,(.5-1 3UNC-2AX1LG) An externally threaded fastener whose threaded portion
https//www.nsnlookup.com /fsg-53/fsc-5305/us 5305-01-439-5928 Socket Head Cap Screw 5305014395928 FFS86
Upgrade your Account Upgrade 5305-01-633-7249Drive Screw5305016337249 016337249 803-4384538 PC NO.42 FFS86
,TYV17/8-9UNC-3AX4.250LG 803-4384538 PC NO.42L1 FFS86,TYV17/8-9UNC-3AX4.250LGL1 A hardened cylindrical
) Incomplete Standard RNCC 4 RNVC 1 DAC E FFS86 https//www.nsnlookup.com /fsg-53/fsc-5305/us 5305-01
,TYV17/8-9UNC-3AX4.250LG 803-4384538 PC NO.42L1 FFS86,TYV17/8-9UNC-3AX4.250LGL1 A hardened cylindrical
) Incomplete Standard RNCC 4 RNVC 1 DAC E FFS86 https//www.nsnlookup.com /fsg-53/fsc-5305/us 5305-01
$1 a day Upgrade your Account Upgrade 5305-01-400-3267Socket Head Cap Screw5305014003267 014003267 FFS86
16UNRC-3AX1.25 751-7072201-88 751-7072202-88 585-6406777-144 211064549 0.375-16UNRC-3AX1.250L NICU FFS86
https//www.nsnlookup.com /fsg-53/fsc-5305/us 5305-01-400-3267 Socket Head Cap Screw 5305014003267 FFS86
16UNRC-3AX1.25 751-7072201-88 751-7072202-88 585-6406777-144 211064549 0.375-16UNRC-3AX1.250L NICU FFS86
https//www.nsnlookup.com /fsg-53/fsc-5305/us 5305-01-400-3267 Socket Head Cap Screw 5305014003267 FFS86
Restrictions 5305-00-411-7723
5305-00-411-7723 is a Socket Head Cap Screw that is an aviation critical safety item or flight safety critical aircraft part. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5305-00-411-7723
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5305-00-411-7723
- US Army (A919)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- A187
- Supplementary Receivers:
- BFCT
- US Air Force (FXGI)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- FXKZ
- US Navy (N9BZ)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- N9ZD
- Supplementary Collaborators:
- GTKEHD
- Poland (WP01)
- Effective Date:
- 1 Aug 2006
- Bulgaria (WU01)
- Effective Date:
- 1 Sep 2002
- Brazil (YA01)
- Effective Date:
- 1 Aug 2000
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Malaysia (YW01)
- Effective Date:
- 1 Aug 1997
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Belgium (ZB01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- France (ZF01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Nov 1994
- United Kingdom (ZK01)
- Effective Date:
- 1 Jul 1999
- Netherlands (ZN01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Jan 2000
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
- Norway (ZT01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 2008
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 5305-00-411-7723
- Part Number
- Manufacturer
- Status
- NAS1352C08H6
- Manufacturer
- 80205 - National Aerospace Standards (Active)
- Primary Buy
- Primary Buy
- FFS86
- 81348 - Federal Specifications Promulgated (Active)
- Incomplete Standard
- Incomplete Standard
- 81706676-1
- K4358 - Safran Electrical & Power Uk Limited (Active)
- Secondary Buy
- Secondary Buy
- NAS1352C08H6
- A0126 - Leonardo Spa Helicopters Division - (Active)
- Secondary Buy
- Secondary Buy
- NAS1352C08H6
- 62206 - B & B Specialties Inc (Active)
- Secondary Buy
- Secondary Buy
- NAS1352C08H6
- 6F810 - Ideal Fasteners, Inc. (Active)
- Secondary Buy
- Secondary Buy
- NAS1352C08H6
- 1EM77 - B & B Specialties Inc (Active)
- Secondary Buy
- Secondary Buy
- A01406-406
- 84697 - Haartz-Mason Inc. (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- A01406-406
- 94697 - Moog Inc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 5305PL0728681
- 9009H - Jednolity Indeks Materialowy - (Active)
- NATO Reference
- NATO Reference
Datasheet 5305-00-411-7723
- Characteristic
- Specifications
- FIIG
- Specifications
- A003B0
- Criticality Code Justification [CRTL]
- Feat
- Fastener Length [AASB]
- 0.359 Inches Minimum And 0.391 Inches Maximum
- Hardness Rating [CQFM]
- 80.0 Rockwell B Minimum Overall
- Head Diameter [AASL]
- 0.262 Inches Minimum And 0.270 Inches Maximum
- Head Height [AASU]
- 0.159 Inches Minimum And 0.164 Inches Maximum
- Head Style [AASK]
- Flat Chamfer
- Hole Configuration Style [CRHC]
- Round Internal Hexagon
- Hole Diameter [AAUB]
- 0.047 Inches Nominal
- Hole Quantity [ASXK]
- 6
- Hole Type [BQDM]
- Drilled
- Material [MATT]
- Steel Comp 302 Or Steel Comp 303 Or Steel Comp 304 Or Steel Comp 305 Or Steel Comp 316 Or Nickel Alloy Overall
- Minimum Tensile Strength [CQBC]
- 80000 Pounds Per Square Inch
- Minimum Yield Strength [CQHQ]
- 30000 Pounds Per Square Inch
- Nominal Thread Diameter [AHYM]
- 0.164 Inches
- Nondefinitive Spec/Std Data [ZZZT]
- 6 Type
- Internal Drive Style [ABQZ]
- Hexagon
- Special Features [FEAT]
- Item Does Not Have A Nuclear Hardened Feature But Does Have Other Critical Features Such As Tolerance,Fit Restrictions Or Application
- Width Across Flats [ASDB]
- 0.141 Inches Minimum And 0.143 Inches Maximum
- Surface Treatment Document And Classification [STDC]
- Qq-P-35 Fed Spec Single Treatment Response Overall
- Surface Treatment [SFTT]
- Passivate Overall
- Thread Class [AAJD]
- 3A
- Thread Direction [AAJF]
- Right-Hand
- Thread Length [AASA]
- 0.359 Inches Minimum And 0.391 Inches Maximum
- Thread Quantity Per Inch [CMLP]
- 32
- Thread Series Designator [THSD]
- Unrc
Weapon Systems (WSDC) 5305-00-411-7723
DLA Procurement Analysis 5305-00-411-7723
- Last Stock Position:
- 3310 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5305-00-411-7723
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- CC
- Other Aircraft Categories
Multi-Application Aviation Spares
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5305-00-411-7723
Freight Information 5305-00-411-7723
5305-00-411-7723 has freight characteristics managed by Germany.It has a National Motor Freight Classification (NMFC) of 093486. A Sub NMFC of Z. It has a NMFC Description of BOLTS,NUTS OR SCREWS, NOI (SUB 3). 5305-00-411-7723 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 48950 which rates the freight between FCL and LCL. 5305-00-411-7723 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5305-00-411-7723 is not classified as a special type of cargo when transported by water. 5305-00-411-7723 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5305-00-411-7723
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
Procurement History 5305-00-411-7723 9 Records
- Contract
- Date
- CAGE
- Quantity
- Net Price
- Std Price
- CAGE
- SPE4A719V0247
- 23 Oct 2018
- Subscribe
- 941
- Subscribe
- Subscribe
- Subscribe
- SPE4A718PD759
- 13 Aug 2018
- Subscribe
- 6276
- Subscribe
- Subscribe
- Subscribe
- SPM5EY12D00011445
- 03 Oct 2013
- Subscribe
- 907
- Subscribe
- Subscribe
- Subscribe
- SPM5EY12D00011446
- 03 Oct 2013
- Subscribe
- 10584
- Subscribe
- Subscribe
- Subscribe
- SPM5EY12D00011307
- 31 Jul 2013
- Subscribe
- 1667
- Subscribe
- Subscribe
- Subscribe
- SPM5EY12D00010998
- 25 Mar 2013
- Subscribe
- 2355
- Subscribe
- Subscribe
- Subscribe
- SPM5EY12D00010997
- 25 Mar 2013
- Subscribe
- 6
- Subscribe
- Subscribe
- Subscribe
- SPM5EY12D00010906
- 19 Feb 2013
- Subscribe
- 1435
- Subscribe
- Subscribe
- Subscribe
- SPM5EY12D00010905
- 19 Feb 2013
- Subscribe
- 13
- Subscribe
- Subscribe
- Subscribe
Contracting Technical Data File (CTDF) 5305-00-411-7723 February 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Y
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
