5305-00-281-4531
Setscrew
5305002814531 002814531 SC1004 7002872 SC1004CA
An externally threaded device whose threaded portion is of one nominal diameter with or without a head and having a cup, cone, or other type of machined point designed to prevent or restrict relative movement of parts and designed to be driven with either a wrench or inserted driver. A locking feature may be incorporated in the design of the head or threads. View more Setscrew
May 2023
4
Marketplace 5305-00-281-4531
Request a Quotation from participating marketplace vendors
Related Documents 5305-00-281-4531 5+ Documents (More...)
Photo 1/4 NSN 5305-00-281-4531 (Identification) 2/4 NSN 5305-00-281-4531 (Identification) 3/4 NSN
SC1004 SETSCREW 4 EA NS Request Quotation Updated Every Day 5305-00-281-4531 RQST NE Updated Every Day
Restrictions 5305-00-281-4531
5305-00-281-4531 is a Setscrew that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5305-00-281-4531
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5305-00-281-4531
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5305-00-281-4531
- Part Number
- Manufacturer
- Status
- SC1004
- Manufacturer
- 01843 - Ambac International Corporation (Active)
- Primary Buy
- Primary Buy
- 7002872
- 19207 - U S Army Tank Automotive Command (Active)
- Primary Buy
- Primary Buy
- SC1004CA
- 24956 - United Technologies Corp (Active)
- Primary Buy
- Primary Buy
- SC1004CA
- 01843 - Ambac International Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5305-00-281-4531
- Characteristic
- Specifications
- FIIG
- Specifications
- A003B0
- Fastener Length [AASB]
- 0.188 Inches Nominal
- Head Height [AASU]
- 0.124 Inches Nominal
- Head Style [AASK]
- Hexagon
- Material Document And Classification [MDCL]
- Qq-S-637 Fed Spec Single Material Response Overall
- Material [MATT]
- Steel Comp 1213 Overall
- Nominal Thread Diameter [AHYM]
- 0.164 Inches
- Internal Drive Style [ABQZ]
- Slot
- Point Style [ABQJ]
- Flat
- Width Between Flats [AATB]
- 0.600 Inches Nominal
- Surface Treatment [SFTT]
- Cadmium Overall Or Zinc Overall
- Thread Direction [AAJF]
- Right-Hand
- Thread Length [AASA]
- 0.188 Inches Minimum
- Thread Class [AAJD]
- 2A
- Thread Quantity Per Inch [CMLP]
- 32
- Thread Series Designator [THSD]
- Unc
Similar Supply Items to 5305-00-281-4531
Freight Information 5305-00-281-4531
5305-00-281-4531 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 093486. A Sub NMFC of Z. It has a NMFC Description of BOLTS,NUTS OR SCREWS, NOI (SUB 3). 5305-00-281-4531 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 48950 which rates the freight between FCL and LCL. 5305-00-281-4531 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5305-00-281-4531 is not classified as a special type of cargo when transported by water. 5305-00-281-4531 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5305-00-281-4531
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
