5305-00-269-3218
Hexagon Head Cap Screw
5305002693218 002693218 NASM90725 FF-S-85 179849 50P01005-2627 M2002BE M1239 SP-59 PIECE 30 Q15-066250 MS90725-68 6-1-1936-33-97 NASM90725-68 145-3410923-132 B10-45363 50A1446 C10-45363 70009-68 251408 412-3184 5305-269-3218
An externally threaded fastener designed for insertion into holes in assembled parts, for mating with a preformed internal thread and for tightening or releasing by torquing the head. The threaded and unthreaded portions are both of the same nominal diameter of 0.190 inch (5 mm) or larger. Head dimensions and sizes of threaded and unthreaded portions shall conform to internationally recognized fastener standards. The thread length being the controlled dimension, the grip length is not specified. A locking feature may be incorporated in the design of the head or threads. The head is not designed to be held or driven with an inserted driver or by the thumb and fingers. Excludes BOLT,MACHINE; BOLT,EXTERNALLY RELIEVED BODY; BOLT,INTERNAL WRENCHING; and SCREW,CAP,SOCKET HEAD. View more Hexagon Head Cap Screw
Managed by United States
NSN Created on 1 Jan 1963
Data Last Changed
November 2023
November 2023
NATO Update Count
82
82
NATO Data Quality
Marketplace 5305-00-269-3218
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
MS90725-68 SCREW,CAP,HEXAGON HEAD 4 EA NS
FFS85 SCREW,CAP,HEXAGON HEAD 2 EA NS
FF-S-85 SCREW,CAP,HEXAGON HEAD 37 EA NS
Updated Every Day 5305-00-269-3218 RQST NE
Updated Every Day 5305-00-269-3218 RQST
Updated Every Day 5305-00-269-3218 RQST NE
Related Documents 5305-00-269-3218 5+ Documents (More...)
NASM90725 FF-S-85 179849 50P01005-2627 M2002BE M1239 SP-59 PIECE 30 MS90725-68 Q15-066250 6-1-1936-33
-97 NASM90725-68 145-3410923-132 B10-45363 50A1446 C10-45363 70009-68 251408 412-3184 5305-269-3218 An
MS90725-68 SCREW,CAP,HEXAGON HEAD 9 EA NS Request Quotation Subscribe to View Vendor Details... 5305-
-97 NASM90725-68 145-3410923-132 B10-45363 50A1446 C10-45363 70009-68 251408 412-3184 5305-269-3218 An
MS90725-68 SCREW,CAP,HEXAGON HEAD 9 EA NS Request Quotation Subscribe to View Vendor Details... 5305-
MS90725-68 SCREW,CAP,HEXAGON HEAD 310 EA NS Request Quotation Subscribe to View Vendor Details...
MS90725-68 SCREW,CAP,HEXAGON HEAD 9 EA NS Request Quotation Subscribe to View Vendor Details...
M1239 SCREW,CAP,HEXAGON HEAD 53 EA NS Request Quotation Subscribe to View Vendor Details...
MS90725-68 SCREW,CAP,HEXAGON HEAD 9 EA NS Request Quotation Subscribe to View Vendor Details...
M1239 SCREW,CAP,HEXAGON HEAD 53 EA NS Request Quotation Subscribe to View Vendor Details...
MS90725-68 SCREW,CAP,HEXAGON HEAD 310 EA NS Request Quotation Subscribe to View Vendor Details...
MS90725-68 SCREW,CAP,HEXAGON HEAD 9 EA NS Request Quotation Subscribe to View Vendor Details...
M1239 SCREW,CAP,HEXAGON HEAD 53 EA NS Request Quotation Subscribe to View Vendor Details...
MS90725-68 SCREW,CAP,HEXAGON HEAD 9 EA NS Request Quotation Subscribe to View Vendor Details...
M1239 SCREW,CAP,HEXAGON HEAD 53 EA NS Request Quotation Subscribe to View Vendor Details...
MS90725-68 SCREW,CAP,HEXAGON HEAD 310 EA NS Request Quotation Subscribe to View Vendor Details...
MS90725-68 SCREW,CAP,HEXAGON HEAD 9 EA NS Request Quotation Subscribe to View Vendor Details...
M1239 SCREW,CAP,HEXAGON HEAD 53 EA NS Request Quotation Subscribe to View Vendor Details...
MS90725-68 SCREW,CAP,HEXAGON HEAD 9 EA NS Request Quotation Subscribe to View Vendor Details...
M1239 SCREW,CAP,HEXAGON HEAD 53 EA NS Request Quotation Subscribe to View Vendor Details...
MS90725-68 SCREW,CAP,HEXAGON HEAD 310 EA NS Request Quotation Subscribe to View Vendor Details...
MS90725-68 SCREW,CAP,HEXAGON HEAD 9 EA NS Request Quotation Subscribe to View Vendor Details...
M1239 SCREW,CAP,HEXAGON HEAD 53 EA NS Request Quotation Subscribe to View Vendor Details...
MS90725-68 SCREW,CAP,HEXAGON HEAD 9 EA NS Request Quotation Subscribe to View Vendor Details...
M1239 SCREW,CAP,HEXAGON HEAD 53 EA NS Request Quotation Subscribe to View Vendor Details...
Restrictions 5305-00-269-3218
5305-00-269-3218 is a Hexagon Head Cap Screw that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5305-00-269-3218
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5305-00-269-3218
- US Army (A919)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- A187
- Supplementary Receivers:
- AJCTCLBFBDAZ
- US Coast Guard (C918)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- C004
- US Air Force (FXGI)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- FXKZ
- NASA (G06X)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- G06I
- NASA (G10X)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- G10I
- NASA (G15X)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- G15I
- NASA (G16X)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- G16I
- NASA (G170)
- Effective Date:
- 1 Apr 1991
- NASA (G37X)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- G37I
- NASA (G42X)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- G42I
- NASA (G65X)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- G65I
- NASA (G72X)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- G72I
- NASA (G76X)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- G76I
- NASA (G77X)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- G77I
- NASA (G81X)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- G81I
- NASA (G860)
- Effective Date:
- 1 Apr 1991
- NASA (G880)
- Effective Date:
- 1 Apr 1991
- NASA (G930)
- Effective Date:
- 1 Apr 1991
- US Marine Corps (MC47)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- MC10
- US Navy (N9BZ)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- NIZD
- Supplementary Collaborators:
- GTKEJNJBHD
- MOE Rule:
- S911
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- S006
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Finland (WF01)
- Effective Date:
- 1 Feb 2016
- Lithuania (WI01)
- Effective Date:
- 1 Feb 2001
- Poland (WP01)
- Effective Date:
- 1 Jul 2006
- Brazil (YA01)
- Effective Date:
- 1 Dec 2001
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Kuwait (YK01)
- Effective Date:
- 1 Feb 2015
- Morocco (YP01)
- Effective Date:
- 1 Nov 2008
- Malaysia (YW01)
- Effective Date:
- 1 Mar 1997
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Belgium (ZB01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- France (ZF01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- United Kingdom (ZK01)
- Effective Date:
- 1 Apr 1991
- Netherlands (ZN01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Apr 1991
- Denmark (ZS01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Aug 1993
- NATO Maintenance and Supply Agency (ZX01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5305-00-269-3218
- Part Number
- Manufacturer
- Status
- NASM90725
- Manufacturer
- 80205 - National Aerospace Standards (Active)
- Incomplete Reference
- Incomplete Reference
- Q15-066250
- 20977 - Mechanical Tool And Engineering Co (Active)
- Primary Buy
- Primary Buy
- MS90725-68
- 80205 - National Aerospace Standards (Active)
- Primary Buy
- Primary Buy
- FF-S-85
- 81348 - Federal Specifications Promulgated (Active)
- Incomplete Standard
- Incomplete Standard
- M2002BE
- 0138N - Rosenbauer International Ag (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- 6-1-1936-33-97
- 81337 - W1d1 Natick Soldier Center (Active)
- Secondary Buy
- Secondary Buy
- NASM90725-68
- 96906 - Military Standards (Active)
- Secondary Buy
- Secondary Buy
- 145-3410923-132
- 51563 - Rohr, Inc. (Active)
- Secondary Buy
- Secondary Buy
- B10-45363
- 88907 - Brunswick Corp (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 50A1446
- 81240 - White Farm Equipment Co (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- C10-45363
- 88907 - Brunswick Corp (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 70009-68
- 95097 - Little Giant Crane And Shovel Inc (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 251408
- H0001 - Daf Trucks N.V. (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 5305-269-3218
- SCY13 - E.C.A Etablissement (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 5305002693218
- SCY13 - E.C.A Etablissement (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- MS90725-68
- 96906 - Military Standards (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 6-1-1936-33-97
- 72869 - Eidal International Corporation (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 5305002693218
- A00AM - E.C.A Etablissement Central Des (Active)
- NATO Reference
- NATO Reference
- 412-3184
- A486G - Nimikkeistokeskus Ncb Finland (Active)
- NATO Reference
- NATO Reference
- 5305-269-3218
- A00AM - E.C.A Etablissement Central Des (Active)
- NATO Reference
- NATO Reference
- 179849
- D9182 - Zf Industrieantriebe Witten Gmbh (Active)
- Advisory Reference
- Advisory Reference
- 50P01005-2627
- D9182 - Zf Industrieantriebe Witten Gmbh (Active)
- Advisory Reference
- Advisory Reference
- M2002BE
- D9182 - Zf Industrieantriebe Witten Gmbh (Active)
- Advisory Reference
- Advisory Reference
- M1239
- 11568 - Gardner Denver Inc. (Active)
- Advisory Reference
- Advisory Reference
- 50P01005-2627
- 01425 - Louis Allis Co The (Replaced)
- Advisory Reference
- Advisory Reference
- SP-59 PIECE 30
- 06289 - Beach-Russ Company (Obsolete)
- Advisory Reference
- Advisory Reference
Datasheet 5305-00-269-3218
- Characteristic
- Specifications
- FIIG
- Specifications
- A003B0
- Fastener Length [AASB]
- 2.500 Inches Nominal
- Hardness Rating [CQFM]
- 23.0 Rockwell C Minimum Overall And 32.0 Rockwell C Maximum Overall
- Head Height [AASU]
- 0.226 Inches Minimum And 0.243 Inches Maximum
- Head Style [AASK]
- Hexagon
- Material Document And Classification [MDCL]
- Sae Gr 5 Assn Std Single Material Response Overall
- Material [MATT]
- Steel Overall
- Minimum Tensile Strength [CQBC]
- 120000 Pounds Per Square Inch
- Minimum Yield Strength [CQHQ]
- 85000 Pounds Per Square Inch
- Nominal Thread Diameter [AHYM]
- 0.375 Inches
- Nondefinitive Spec/Std Data [ZZZT]
- 2 Type And 10P Style
- Width Between Flats [AATB]
- 0.551 Inches Minimum And 0.562 Inches Maximum
- Surface Treatment Document And Classification [STDC]
- Qq-P-416,Ty 2 Cl 2 Fed Spec Single Treatment Response Overall
- Surface Treatment [SFTT]
- Cadmium Overall And Chromate Overall
- Thread Class [AAJD]
- 2A
- Thread Direction [AAJF]
- Right-Hand
- Thread Length [AASA]
- 1.000 Inches Minimum And 1.188 Inches Maximum
- Thread Quantity Per Inch [CMLP]
- 16
- Thread Series Designator [THSD]
- Unc
Weapon Systems (WSDC) 5305-00-269-3218
DLA Procurement Analysis 5305-00-269-3218
- Last Stock Position:
- 1135 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5305-00-269-3218
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Department of the Army (DA)
- EA
- Subscribe
- EA
- Dec 2021
- Department of the Air Force (DF)
- EA
- Subscribe
- EA
- Oct 2021
- US Marine Corps (DM)
- EA
- Subscribe
- EA
- May 2021
- US Marine Corps (DM)
- EA
- Subscribe
- EA
- Oct 2019
- Department of the Air Force (DF)
- EA
- Subscribe
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- US Marine Corps (DM)
- M
- 0
- Reversal Of Phrase Code Z 5305-00-018-1128
- 0
- US Marine Corps (DM)
- M
- 0
- Reversal Of Phrase Code Z 5305-00-021-7025
- 0
- US Marine Corps (DM)
- M
- 0
- Reversal Of Phrase Code Z 5305-00-206-1615
- 0
- US Marine Corps (DM)
- M
- 0
- Reversal Of Phrase Code Z 5306-00-153-8623
- 0
- US Marine Corps (DM)
- M
- 4
- Reversal Of Phrase Code A 5306-00-705-9570
- 4
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- SX
- SICA RESIDUAL MMAC-OC-ALC
- Price Validation Code:
- V
- The current standard price has been validated.
The item has been analyzed in conjunction with the Zero Overpricing Program and is in the accepted price range.
The item was procured under open competition and under the competitive arena the price is considered fair and reasonable.
ZOP or Standard price challenges are permissible but must be supported by adequate justification.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
- Special Material Content:
- 9
- Non-Hazardous or Non-Sensitive Item
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- B2
- Material Identification:
- K
- Reserved
- Operational Test:
- No Special Procedures
NATO Stock Numbers Related to 5305-00-269-3218
5305-23-110-7871 5305-15-072-2385 5305-32-080-7488 5305-15-058-0111 5305-15-005-3078 5305-15-007-8618 5305-15-004-1506 5305-32-083-8831 5305-99-404-5225 5305-15-072-1910 5305-21-614-1302 5305-12-182-3224 5305-21-866-4147 5305-33-003-4049 5305-12-387-7596 5305-12-386-5375 5305-22-625-5152 5305-72-000-0039
Freight Information 5305-00-269-3218
5305-00-269-3218 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 093486. A Sub NMFC of Z. It has a NMFC Description of BOLTS,NUTS OR SCREWS, NOI (SUB 3). 5305-00-269-3218 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 48950 which rates the freight between FCL and LCL. 5305-00-269-3218 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5305-00-269-3218 is not classified as a special type of cargo when transported by water. 5305-00-269-3218 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5305-00-269-3218
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
Procurement History 5305-00-269-3218 4 Records
Contracting Technical Data File (CTDF) 5305-00-269-3218 October 2020
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
