5305-00-068-2771
Socket Head Cap Screw
5305000682771 000682771 05008-0048 5008-48
An externally threaded fastener whose threaded portion is of one nominal diameter. The head has an internal socket or multiple spline for use with an inserted driver. A locking feature may be incorporated in the design of the head or threads. Excludes items with bevel (conical) heads. See BOLT, INTERNAL WRENCHING. Excludes SCREW, SHOULDER; and SCREW, MACHINE. View more Socket Head Cap Screw
May 2023
15
Marketplace 5305-00-068-2771
Request a Quotation from participating marketplace vendors
Related Documents 5305-00-068-2771 5+ Documents (More...)
Photo 1/7 5305-00-068-2771 Photo 2/7 5305-00-068-2771 Photo 3/7 5305-00-068-2771 Photo 4/7 5305
-00-068-2771 Photo 5/7 NSN 5305-00-068-2771 (Identification) 6/7 NSN 5305-00-068-2771 (Identification
Restrictions 5305-00-068-2771
5305-00-068-2771 is a Socket Head Cap Screw that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5305-00-068-2771
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5305-00-068-2771
- France (ZF)
- France (ZF01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW)
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 5305-00-068-2771
- Part Number
- Manufacturer
- Status
- 05008-0048
- Manufacturer
- 26344 - New Haven Mfg Corp (Obsolete)
- Original Design
- Original Design
- 5008-48
- 09038 - Bee Mac Inc (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5305-00-068-2771
- Characteristic
- Specifications
- FIIG
- Specifications
- A003B0
- Thread Series Designator [THSD]
- Unc
- Nominal Thread Diameter [AHYM]
- 0.125 Inches
- Thread Quantity Per Inch [CMLP]
- 40
- Thread Class [AAJD]
- 2A
- Thread Direction [AAJF]
- Right-Hand
- Thread Length [AASA]
- 0.375 Inches Minimum
- Fastener Length [AASB]
- 0.375 Inches Nominal
- Material [MATT]
- Steel Corrosion Resisting Overall
- Material Document And Classification [MDCL]
- Fed Std 66 Aisi 303 Or Sae 30303 Fed Std Single Material Response Overall
- Surface Treatment [SFTT]
- Passivate Overall
- Head Style [AASK]
- Flat Chamfer
- Head Diameter [AASL]
- 0.205 Inches Nominal
- Head Height [AASU]
- 0.125 Inches Nominal
- Internal Drive Style [ABQZ]
- Hexagon
- Width Across Flats [ASDB]
- 0.094 Inches Nominal
Similar Supply Items to 5305-00-068-2771
Freight Information 5305-00-068-2771
5305-00-068-2771 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 093486. A Sub NMFC of Z. It has a NMFC Description of BOLTS,NUTS OR SCREWS, NOI (SUB 3). 5305-00-068-2771 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 48950 which rates the freight between FCL and LCL. 5305-00-068-2771 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5305-00-068-2771 is not classified as a special type of cargo when transported by water. 5305-00-068-2771 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
