5305-00-058-9362
Setscrew
5305000589362 000589362 28706-98C-3P4 MS51977-19
An externally threaded device whose threaded portion is of one nominal diameter with or without a head and having a cup, cone, or other type of machined point designed to prevent or restrict relative movement of parts and designed to be driven with either a wrench or inserted driver. A locking feature may be incorporated in the design of the head or threads. View more Setscrew
November 2023
22
Marketplace 5305-00-058-9362
Request a Quotation from participating marketplace vendors
Related Documents 5305-00-058-9362 5+ Documents (More...)
Photo 1/4 NSN 5305-00-058-9362 (Identification) 2/4 NSN 5305-00-058-9362 (Identification) 3/4 NSN
MS51977-19 SETSCREW 500 EA NS Request Quotation Updated Every Day 5305-00-058-9362 RQST NE Updated Every
Restrictions 5305-00-058-9362
5305-00-058-9362 is a Setscrew that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5305-00-058-9362
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5305-00-058-9362
- US Army (A919)
- Effective Date:
- 1 Jun 2005
- Former MOE Rule:
- A187
- Supplementary Receivers:
- AJCL
- US Air Force (FXGI)
- Effective Date:
- 1 Jun 2005
- Former MOE Rule:
- FXKZ
- US Navy (N9BZ)
- Effective Date:
- 1 Jun 2005
- Former MOE Rule:
- N9ZD
- Supplementary Collaborators:
- KE
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- NATO Maintenance and Supply Agency (ZX01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5305-00-058-9362
- Part Number
- Manufacturer
- Status
- MS51977-19
- Manufacturer
- 80205 - National Aerospace Standards (Active)
- Primary Buy
- Primary Buy
- 28706-98C-3P4
- 56878 - Sps Technologies, Llc (Active)
- Secondary Buy
- Secondary Buy
- MS51977-19
- 96906 - Military Standards (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5305-00-058-9362
- Characteristic
- Specifications
- FIIG
- Specifications
- A003B0
- Fastener Length [AASB]
- 0.188 Inches Nominal
- Hardness Rating [CQFM]
- 45.0 Rockwell C Minimum Overall And 53.0 Rockwell C Maximum Overall
- Head Style [AASK]
- Headless (Setscrew)
- Material [MATT]
- Steel Comp 4037 Overall Or Steel Comp 4137 Overall Or Steel Comp 4140 Overall Or Steel Comp 8630 Overall Or Steel Comp 8740 Overall
- Nominal Thread Diameter [AHYM]
- 0.138 Inches
- End Item Identification [AGAV]
- W/S:Filter Unit, Gas Particulate, M56; Collective Protective Equipment Cbr, M10; Helicopter, Green Giant H-3; Radar, Firefinder, An/Tpq-36 And An/Tpq-37; Aircraft, (Ac-130H, Mc-130H, Ec-130E, Hc-130); Aircraft, Tomcat F-14; Aircraft, Starlifter C-141; Tacsatcom, An/Tsc-85 And An/Tsc-93; Aircraft, Galaxy C-5; Aiorcraft, Orion P-3
- Internal Drive Style [ABQZ]
- Hexagon
- Material Document And Classification [MDCL]
- 66 Fed Std All Material Responses Overall
- Point Style [ABQJ]
- Half Dog
- Width Across Flats [ASDB]
- 0.062 Inches Nominal
- Surface Treatment Document And Classification [STDC]
- Qq-P-416 Type 2 Class 3 Fed Spec All Treatment Responses Overall
- Surface Treatment [SFTT]
- Cadmium Overall And Chromate Overall
- Thread Length [AASA]
- 0.188 Inches Maximum
- Thread Class [AAJD]
- 3A
- Thread Direction [AAJF]
- Right-Hand
- Thread Quantity Per Inch [CMLP]
- 32
- Thread Series Designator [THSD]
- Unc
