5210-01-551-9992
Thin Steel Square
5210015519992 015519992 50281 55-4 1/2
A measuring tool consisting of a onepiece, precision-ground steel body and tongue forming a 90 degree angle. It is graduated on the inside edge of the tongue (short leg) and the outside edge of the body (long leg). View more Thin Steel Square
May 2023
1
Marketplace 5210-01-551-9992
Request a Quotation from participating marketplace vendors
50281 RQST NE
55-4 1/2 RQST NE
Updated Every Day Updated Every Day
Updated Every Day Related Documents 5210-01-551-9992 5+ Documents (More...)
NE Updated Every Day Search Global Test Supply 55-4 1/2 RQST NE Updated Every Day 5210-01-551-9992 RQST
NE Updated Every Day 5210-01-551-9992 RQST Updated Every Day 5210-01-551-9992 RQST NE Related Documents
3511-130-50281 A grouping of two or more physically connected or related electrical an/or electronic
59/fsc-5999/fr 5999-14-403-7781 Circuit Card Assembly 5999144037781144037781 3511 130 502813511-130-50281
enable JavaScript in your web browser . 6260-66-077-6241Kerosene Lantern6260660776241 66077624112-50281
21-888-8477 Wood Screw 5305218888477 218888477,50281 5999144037781144037781 3511 130 502813511-130-50281
/fsg-59/fsc-5940/us
ITEM 23D-50281 An item consisting of insulating material, which is specifically BUY NE FedMall Updated
ITEM 3 FS-41183 5-017-0222 D-50281 ITEM 2 A switch which is actuated by changes in pressure of any gas
Thin Steel Square 5210015519992 015519992 which is actuated by changes in pressure of any gas https
day Upgrade your Account Upgrade 6110-01-435-9786Motor Starter6110014359786 0143597865-017-0220 D-50281
Restrictions 5210-01-551-9992
5210-01-551-9992 is a Thin Steel Square that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5210-01-551-9992
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5210-01-551-9992
- Canada (ZC01)
- Effective Date:
- 1 Jun 2007
Approved Sources 5210-01-551-9992
- Part Number
- Manufacturer
- Status
- 50281
- Manufacturer
- 57163 - L.S. Starrett Company (The) (Active)
- Primary Buy
- Primary Buy
- 55-4 1/2
- 57163 - L.S. Starrett Company (The) (Active)
- Secondary Buy
- Secondary Buy
Datasheet 5210-01-551-9992
- Characteristic
- Specifications
- FIIG
- Specifications
- A23900
- Material [MATT]
- Steel
- Special Features [FEAT]
- The Blade Of The Starrtt 55 Square Is Beveled On Both Edges; Bevel Thickness Is 0.015-0.020 Inch; Material Aisi-01 Steel; Hardness Beam 57-63 Rockwell C, Blade 53-59 Rockwell C; Finish Grain Rubbed Steel; Blade To Base Squareness 0.0001 Inch; Beam Flatness Is To Shut Out Light; Lateral Squareness 0.008 Inch Max; Length Of Blade 4.5 Inch From The Inner Edge Of The Beam To The End Of The Blade; Length Of Beam 3.5 Inch
- Part Name Assigned By Controlling Agency [CXCY]
- Master Precision Square With Beveled Edges
Similar Supply Items to 5210-01-551-9992
Freight Information 5210-01-551-9992
5210-01-551-9992 has freight characteristics managed by the Department of the Air Force.. 5210-01-551-9992 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
