5210-01-399-9372
Thickness Gage Blade
5210013999372 013999372 J0015L 3R017 0015L
An item made of tempered steel, usually strip of leaf in shape, 12 inches (304.8 mm) or less in length, ground to and normally marked with its specific thickness. The blade may have a hole in one end, which allows for insertion in a thickness gage used either singly or with a readily attachable handle for checking or setting valve tappets, piston clearance, ring gear and pinion play, guided missile antenna radome and guided missile test stand cradle clearance, and the like. Excludes bulk thickness gage stock. View more Thickness Gage Blade
November 2023
10
Marketplace 5210-01-399-9372
Request a Quotation from participating marketplace vendors
Related Documents 5210-01-399-9372 5+ Documents (More...)
Every Day 0015L RQST NE Updated Every Day 3R017 RQST NE Updated Every Day 5210-01-399-9372 RQST NE Updated
Every Day 5210-01-399-9372 RQST Updated Every Day 5210-01-399-9372 RQST NE Related Documents 5210-01
your web browser . 5210-21-638-0164Thickness Gage https//www.nsnlookup.com /fsg-52/fsc-5210/us 5210-01-399-9372
Thickness Gage Blade 5210013999372 013999372 Upgrade your Account Upgrade 5210-01-399-9372Thickness
6115 Headless Shoulder Pin 5315012586115 012586115 3957Synchronkoerper6605121803957 121803957 29 318-0015L
.6211.001.18 29318 https//www.nsnlookup.com /fsg-59/fsc-5995/uk 5995-99-543-2273 Special 29 318-0015L
Restrictions 5210-01-399-9372
5210-01-399-9372 is a Thickness Gage Blade that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
End Users 5210-01-399-9372
- NASA (G752)
- Effective Date:
- 1 Oct 2010
Approved Sources 5210-01-399-9372
- Part Number
- Manufacturer
- Status
- J0015L
- Manufacturer
- 1CV05 - The Stanley Works (Active)
- Primary Buy
- Primary Buy
- 3R017
- 25795 - W.W. Grainger, Inc. (Active)
- Secondary Buy
- Secondary Buy
- 0015L
- 1CV05 - The Stanley Works (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5210-01-399-9372
- Characteristic
- Specifications
- Measurement System [BDLS]
- Specifications
- English
- Thickness [THKS]
- 0.0015 Inches
- Length [ABRY]
- 12.000 Inches Nominal
- Shape [SHPE]
- Straight
- Width [ABGL]
- 0.500 Inches Nominal
- End Hole [CPQQ]
- Included
- End Shape And Location [AXPT]
- Round Both Ends
- Holder [AETA]
- Not Included
Management Data 5210-01-399-9372
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Sep 2007
- Department of the Army (DA)
- EA
- Subscribe
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Army (DA)
- A
- V
- Discontinued W/O Replacement
- V
Army
- Materiel Category and Inventory Manager:
- E
- General Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Similar Supply Items to 5210-01-399-9372
Freight Information 5210-01-399-9372
5210-01-399-9372 has freight characteristics.. 5210-01-399-9372 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
