5210-01-399-9332
Thickness Gage
5210013999332 013999332 J00MM25 FRS 00MM25 3R015 00MM25
One or more tempered steel blades (leaves) ground to and marked with their respective thickness and mounted in a holder or encased within a frame or case into which the leaves fold. It is used for checking narrow slots or gaging the clearance between fitted parts. Excludes BLADE, THICKNESS GAGE. See also GAGE, GAP SETTING. View more Thickness Gage
Managed by United States
NSN Created on 7 Dec 1994
Data Last Changed
August 2023
August 2023
NATO Update Count
14
14
NATO Data Quality
Marketplace 5210-01-399-9332
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 5210-01-399-9332 3+ Documents (More...)
https//www.nsnlookup.com
/fsg-52/fsc-5210/us
/fsg-52/fsc-5210/us
5210-01-399-9332 Thickness Gage 5210013999332 013999332
J00MM25 FRS 00MM25 3R015 00MM25 One or more tempered steel blades (leaves) ground to and marked with
GAGE,THICKNESS RQST NS Request Quotation Updated Every Day J00MM25 RQST NE Updated Every Day FRS
00MM25 RQST NE Updated Every Day 00MM25 RQST NE Updated Every Day 3R015 RQST NE Updated Every Day 5210
GAGE,THICKNESS RQST NS Request Quotation Updated Every Day J00MM25 RQST NE Updated Every Day FRS
00MM25 RQST NE Updated Every Day 00MM25 RQST NE Updated Every Day 3R015 RQST NE Updated Every Day 5210
https//www.nsnlookup.com
/fsg-52/fsc-5210/us
/fsg-52/fsc-5210/us
5210-01-604-3726 Thickness Gage 5210016043726 016043726
for $1 a day Upgrade your Account Upgrade 5210-01-604-3726Thickness Gage5210016043726 016043726 FRS 00MM25
Thickness Gage 5210013999332 013999332 day Upgrade your Account Upgrade 5210-01-399-9332Thickness
Gage5210013999332 013999332 J00MM25 FRS 00MM25 9332 GAGE,THICKNESS RQST NS Request Quotation Updated
Thickness Gage 5210013999332 013999332 day Upgrade your Account Upgrade 5210-01-399-9332Thickness
Gage5210013999332 013999332 J00MM25 FRS 00MM25 9332 GAGE,THICKNESS RQST NS Request Quotation Updated
Restrictions 5210-01-399-9332
5210-01-399-9332 is a Thickness Gage that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5210-01-399-9332
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5210-01-399-9332
- US Army (A192)
- Effective Date:
- 1 Jan 1995
- Supplementary Receivers:
- AZBF
- US Coast Guard (C014)
- Effective Date:
- 1 Jan 1995
- US Air Force (FGGS)
- Effective Date:
- 1 Jan 1995
- NASA (G751)
- Effective Date:
- 1 Dec 1994
- US Marine Corps (MC14)
- Effective Date:
- 1 Jan 1995
- US Navy (N9QG)
- Effective Date:
- 1 Jan 2014
- Supplementary Collaborators:
- GG
- Republic of Korea (ZH01)
- Effective Date:
- 1 Jun 2012
Approved Sources 5210-01-399-9332
- Part Number
- Manufacturer
- Status
- J00MM25
- Manufacturer
- 1CV05 - The Stanley Works (Active)
- Primary Buy
- Primary Buy
- FRS 00MM25
- 55719 - Idsc Holdings Llc (Active)
- Primary Buy
- Primary Buy
- 3R015
- 25795 - W.W. Grainger, Inc. (Active)
- Secondary Buy
- Secondary Buy
- 00MM25
- 1CV05 - The Stanley Works (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5210-01-399-9332
- Characteristic
- Specifications
- FIIG
- Specifications
- T299-K
- Blade Group Quantity [CNLG]
- 1
- Measurement System [BDLS]
- Metric
- Blade Shape [AJMH]
- Straight
- Blade Quantity [AJLB]
- 25
- Blade Length [AEAE]
- 3.312 Inches Nominal
- Blade Tip Width [CMZF]
- 0.500 Inches Nominal
- Blade Thickness [CPMW]
- 0.04 Millimeters 1St Blade
- Blade Thickness [CPMW]
- 0.05 Millimeters 2Nd Blade
- Blade Thickness [CPMW]
- 0.06 Millimeters 3Rd Blade
- Blade Thickness [CPMW]
- 0.07 Millimeters 4Th Blade
- Blade Thickness [CPMW]
- 0.08 Millimeters 5Th Blade
- Blade Thickness [CPMW]
- 0.09 Millimeters 6Th Blade
- Blade Thickness [CPMW]
- 0.10 Millimeters 7Th Blade
- Blade Thickness [CPMW]
- 0.15 Millimeters 8Th Blade
- Blade Thickness [CPMW]
- 0.20 Millimeters 9Th Blade
- Blade Thickness [CPMW]
- 0.25 Millimeters 10Th Blade
- Blade Thickness [CPMW]
- 0.30 Millimeters 11Th Blade
- Blade Thickness [CPMW]
- 0.35 Millimeters 12Th Blade
- Blade Thickness [CPMW]
- 0.40 Millimeters 13Th Blade
- Blade Thickness [CPMW]
- 0.45 Millimeters 14Th Blade
- Blade Thickness [CPMW]
- 0.50 Millimeters 15Th Blade
- Blade Thickness [CPMW]
- 0.55 Millimeters 16Th Blade
- Blade Thickness [CPMW]
- 0.60 Millimeters 17Th Blade
- Blade Thickness [CPMW]
- 0.65 Millimeters 18Th Blade
- Blade Thickness [CPMW]
- 0.70 Millimeters 19Th Blade
- Blade Thickness [CPMW]
- 0.75 Millimeters 20Th Blade
- Blade Thickness [CPMW]
- 0.80 Millimeters 21St Blade
- Blade Thickness [CPMW]
- 0.85 Millimeters 22Nd Blade
- Blade Thickness [CPMW]
- 0.90 Millimeters 23Rd Blade
- Blade Thickness [CPMW]
- 0.95 Millimeters 24Th Blade
- Blade Thickness [CPMW]
- 1.00 Millimeters 25Th Blade
Management Data 5210-01-399-9332
Army
- Materiel Category and Inventory Manager:
- E
- General Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9Q
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- 02
- Operational Test:
- No Special Procedures
Similar Supply Items to 5210-01-399-9332
Freight Information 5210-01-399-9332
5210-01-399-9332 has freight characteristics.. 5210-01-399-9332 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
