5210-01-368-4560
Thickness Gage
5210013684560 013684560 226T 31309
One or more tempered steel blades (leaves) ground to and marked with their respective thickness and mounted in a holder or encased within a frame or case into which the leaves fold. It is used for checking narrow slots or gaging the clearance between fitted parts. Excludes BLADE, THICKNESS GAGE. See also GAGE, GAP SETTING. View more Thickness Gage
Managed by United States
NSN Created on 1 Dec 1992
Data Last Changed
November 2023
November 2023
NATO Update Count
18
18
NATO Data Quality
Marketplace 5210-01-368-4560
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 5210-01-368-4560 5+ Documents (More...)
226T 31309 One or more tempered steel blades (leaves) ground to and marked with their respective thickness
226T GAGE,THICKNESS 9 EA NS Request Quotation Updated Every Day 5210-01-368-4560 RQST NE Updated Every
Day 5210-01-368-4560 RQST Updated Every Day 5210-01-368-4560 RQST NE Related Documents 5210-01-368-4560
226T GAGE,THICKNESS 9 EA NS Request Quotation Updated Every Day 5210-01-368-4560 RQST NE Updated Every
Day 5210-01-368-4560 RQST Updated Every Day 5210-01-368-4560 RQST NE Related Documents 5210-01-368-4560
to enable JavaScript in your web browser . 5950-17-102-7868Power Transformer5950171027868 171027868 226T
your web browser . 5120-21-855-3145Hand Blind Riveter5120218553145 218553145 HP2 RG-1 TT5 CK100-04 226T
to enable JavaScript in your web browser . 5950-21-894-9219Power Transformer5950218949219 218949219 226T
your web browser . 5120-21-855-3145Hand Blind Riveter5120218553145 218553145 HP2 RG-1 TT5 CK100-04 226T
to enable JavaScript in your web browser . 5950-21-894-9219Power Transformer5950218949219 218949219 226T
to enable JavaScript in your web browser . 5950-21-894-9219Power Transformer5950218949219 218949219 226T
to enable JavaScript in your web browser . 5950-17-102-7868Power Transformer5950171027868 171027868 226T
your web browser . 5120-21-855-3145Hand Blind Riveter5120218553145 218553145 HP2 RG-1 TT5 CK100-04 226T
to enable JavaScript in your web browser . 5950-17-102-7868Power Transformer5950171027868 171027868 226T
your web browser . 5120-21-855-3145Hand Blind Riveter5120218553145 218553145 HP2 RG-1 TT5 CK100-04 226T
your Account Upgrade 5935-01-044-8816Cable Clamp To Connector Adapter5935010448816 010448816 G8627-226T
G5503-226T An item specifically designed to be placed around that portion of a CONNECTOR, RECEPTABLE
G5503-226T ADAPTER,CABLE CLAMP TO CONNECTOR RQST NS Request Quotation FedMall Updated Every 15 Minutes
G5503-226T An item specifically designed to be placed around that portion of a CONNECTOR, RECEPTABLE
G5503-226T ADAPTER,CABLE CLAMP TO CONNECTOR RQST NS Request Quotation FedMall Updated Every 15 Minutes
Account Upgrade 5998-01-451-7819Circuit Card Assembly5998014517819 014517819 48377 44830/163 44830/226T
fsg-59/fsc-5998/us 5998-01-451-7819 Circuit Card Assembly 5998014517819014517819 4837744830/16344830/226T
Maintenance Kit4921145667106 145667106 2-48377 https//www.nsnlookup.com /fsg-52/fsc-5210/us 5210-01-368-4560
fsg-59/fsc-5998/us 5998-01-451-7819 Circuit Card Assembly 5998014517819014517819 4837744830/16344830/226T
Maintenance Kit4921145667106 145667106 2-48377 https//www.nsnlookup.com /fsg-52/fsc-5210/us 5210-01-368-4560
Restrictions 5210-01-368-4560
5210-01-368-4560 is a Thickness Gage that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
End Users 5210-01-368-4560
- NASA (G752)
- Effective Date:
- 1 Jul 2005
Approved Sources 5210-01-368-4560
- Part Number
- Manufacturer
- Status
- 226T
- Manufacturer
- 3JKA4 - General Tools Manufacturing Co., (Active)
- Primary Buy
- Primary Buy
- 31309
- 3JKA4 - General Tools Manufacturing Co., (Active)
- Secondary Buy
- Secondary Buy
- 226T
- 73792 - General Hardware Mfg Co Inc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5210-01-368-4560
- Characteristic
- Specifications
- Blade Group Quantity [CNLG]
- Specifications
- 1
- Measurement System [BDLS]
- English
- Blade Shape [AJMH]
- Tapered
- Blade Quantity [AJLB]
- 26
- Blade Length [AEAE]
- 3.000 Inches Nominal
- Blade Tip Width [CMZF]
- 0.250 Inches Nominal
- Blade Thickness [CPMW]
- 0.0015 Inches 1St Blade
- Blade Thickness [CPMW]
- 0.0020 Inches 2Nd Blade
- Blade Thickness [CPMW]
- 0.0025 Inches 3Rd Blade
- Blade Thickness [CPMW]
- 0.0030 Inches 4Th Blade
- Blade Thickness [CPMW]
- 0.0040 Inches 5Th Blade
- Blade Thickness [CPMW]
- 0.0050 Inches 6Th Blade
- Blade Thickness [CPMW]
- 0.0060 Inches 7Th Blade
- Blade Thickness [CPMW]
- 0.0070 Inches 8Th Blade
- Blade Thickness [CPMW]
- 0.0080 Inches 9Th Blade
- Blade Thickness [CPMW]
- 0.0090 Inches 10Th Blade
- Blade Thickness [CPMW]
- 0.0100 Inches 11Th Blade
- Blade Thickness [CPMW]
- 0.0110 Inches 12Th Blade
- Blade Thickness [CPMW]
- 0.0120 Inches 13Th Blade
- Blade Thickness [CPMW]
- 0.0130 Inches 14Th Blade
- Blade Thickness [CPMW]
- 0.0140 Inches 15Th Blade
- Blade Thickness [CPMW]
- 0.0150 Inches 16Th Blade
- Blade Thickness [CPMW]
- 0.0160 Inches 17Th Blade
- Blade Thickness [CPMW]
- 0.0170 Inches 18Th Blade
- Blade Thickness [CPMW]
- 0.0180 Inches 19Th Blade
- Blade Thickness [CPMW]
- 0.0190 Inches 20Th Blade
- Blade Thickness [CPMW]
- 0.0200 Inches 21St Blade
- Blade Thickness [CPMW]
- 0.0210 Inches 22Nd Blade
- Blade Thickness [CPMW]
- 0.0220 Inches 23Rd Blade
- Blade Thickness [CPMW]
- 0.0230 Inches 24Th Blade
- Blade Thickness [CPMW]
- 0.0240 Inches 25Th Blade
- Blade Thickness [CPMW]
- 0.0250 Inches 26Th Blade
- Blade Lock [CNLH]
- Included
Management Data 5210-01-368-4560
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Jun 2014
- US Marine Corps (DM)
- EA
- Subscribe
- EA
- Jan 2003
- Department of the Navy (DN)
- EA
- Subscribe
- EA
- Dec 2000
- Department of the Army (DA)
- EA
- Subscribe
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Navy (DN)
- N
- V
- Discontinued Without Replacement
- V
Army
- Materiel Category and Inventory Manager:
- E
- General Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- D
- Durable item.An item of Army property coded with an ARC of D in the AMDF. Durable items do not require property book accountability after issue from the stock record account but do require hand receipt control when issued to the user. Commercial and fabricated items similar to items coded D in the AMDF are considered durable items.
Navy
- Cognizance:
- 9Q
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Echelon Management:
- 54
- Operational Test:
- No Special Procedures
Similar Supply Items to 5210-01-368-4560
Freight Information 5210-01-368-4560
5210-01-368-4560 has freight characteristics.. 5210-01-368-4560 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
