5210-01-130-8881
Outside Micrometer Caliper
5210011308881 011308881 J-26900-1 159-211
A precision measuring instrument with a micrometer screw attachment used for making exact external linear measurements of thickness, outside diameters, or distances over two parallel planes. It consists of a U-frame and a micrometer, the spindle of which is aligned with an opposite anvil. It may incldue a dial indicator, digital display, and/or a push-button mechanism which activates a retractable anvil to assure uniformity of contact pressure, and permits use as a visual comparator. Graduations may be in inches and/or millimeters. View more Outside Micrometer Caliper
May 2023
9
Marketplace 5210-01-130-8881
Request a Quotation from participating marketplace vendors
Related Documents 5210-01-130-8881 2+ Documents (More...)
CALIPER,MICROMETER,OUTSIDE RQST NS Request Quotation Updated Every Day 5210-01-130-8881 RQST NE
Updated Every Day 5210-01-130-8881 RQST Updated Every Day 5210-01-130-8881 RQST NE Related Documents
Restrictions 5210-01-130-8881
5210-01-130-8881 is a Outside Micrometer Caliper that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5210-01-130-8881
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5210-01-130-8881
- US Army (A192)
- Effective Date:
- 1 Apr 1991
- NASA (G751)
- Effective Date:
- 1 Apr 1991
- US Navy (N9QG)
- Effective Date:
- 1 Apr 1991
- Supplementary Collaborators:
- HD
- Poland (WP01)
- Effective Date:
- 1 Jan 2004
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Jul 1995
- Turkey (ZW01)
- Effective Date:
- 1 Dec 2005
Approved Sources 5210-01-130-8881
- Part Number
- Manufacturer
- Status
- J-26900-1
- Manufacturer
- 33287 - Bosch Automotive Service Solutions (Active)
- Primary Buy
- Primary Buy
- 159-211
- 0YN60 - Mti/Mitutoyo Corp (Active)
- Secondary Buy
- Secondary Buy
Datasheet 5210-01-130-8881
- Characteristic
- Specifications
- FIIG
- Specifications
- T299-F
- Container Type [AJKF]
- Case
- Gaging Range [BSFC]
- +0.000/+1.000 Inches
- Graduation Unit [CPTY]
- Ten-Thousandths Of An Inch
- Indicator Graduation Unit [CXJP]
- 0.01 Millimeter
- Indicator Type [AMKD]
- Digital Readout
- Locknut [BDSH]
- Included
- Pushbutton Pressure Control [CNJX]
- Not Included
- Ratchet Stop [CNJT]
- Not Included
- Special Features [FEAT]
- Reads Metric And English; 0.0001 In. Graduations On Friction Thimble
Management Data 5210-01-130-8881
Army
- Materiel Category and Inventory Manager:
- E
- General Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- D
- Durable item.An item of Army property coded with an ARC of D in the AMDF. Durable items do not require property book accountability after issue from the stock record account but do require hand receipt control when issued to the user. Commercial and fabricated items similar to items coded D in the AMDF are considered durable items.
Navy
- Cognizance:
- 9Q
Similar Supply Items to 5210-01-130-8881
Freight Information 5210-01-130-8881
5210-01-130-8881 has freight characteristics managed by the Food and Drug Administration (FDA).It has a National Motor Freight Classification (NMFC) of 058030. A Sub NMFC of X. It has a NMFC Description of MICROMETERS IN BOXES. 5210-01-130-8881 is rated as class 150 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 33070 which rates the freight between FCL and LCL. 5210-01-130-8881 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 653 for ocean manifesting and military sealift. 5210-01-130-8881 is not classified as a special type of cargo when transported by water. 5210-01-130-8881 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
