5210-01-126-3273
Dial Indicator
5210011263273 011263273 657BZ 52746
A mechanism for amplifying and measuring the displacement of a movable contact point, thereby measuring a dimension or variation from a standard dimension. It consists essentially of a case with means for mounting the indicator, a spindle carrying the contact point, an amplifying mechanism, a pointer and a graduated dial. May include accessories and/or attachments. Excludes INDICATOR, SCALE. See also GAGE, DEPTH, DIAL INDICATING. View more Dial Indicator
September 2025
4
Marketplace 5210-01-126-3273
Request a Quotation from participating marketplace vendors
Related Documents 5210-01-126-3273 5+ Documents (More...)
Search Global Test Supply 52746 RQST NE Updated Every Day 5210-01-126-3273 RQST NE Updated Every Day
a movable contact point, thereby Search Global Test Supply 52746 RQST NE Updated Every Day 5210-01-126
/fsg-58/fsc-5845/ca
Dial Indicator 5210011263273 011263273,657BZ 3273Dial Indicator5210011263273 011263273657BZ52746
58452104028992104028995845-21-040-2899 is a Dial Indicator Similar Supply Items to 5845-21-040-2899 5210-01-203-8661 5210-01-126-3273
01-126-3273 Dial Indicator 5210011263273 011263273,657BZ -545-2506 Part NumberManufacturerStatusA1-52746
https//www.nsnlookup.com /fsg-52/fsc-5210/us 5210-01-126-3273 Dial Indicator 5210011263273 011263273,657BZ
5340-14-520-1434 Utility Access Door 5340145201434 145201434 Fixed Capacitor5910015272295 01527229520-52746
6150-01-619-6439 Electrical Special Purpose Cable Assembly -545-2506 Part NumberManufacturerStatusA1-52746
Dial Indicator 5210011263273 011263273,657BZ $1 a day Upgrade your Account Upgrade 5210-01-126-
3273Dial Indicator5210011263273 011263273 657BZ 52746 INDICATOR,DIAL 2 EA NS Request Quotation Subscribe
Restrictions 5210-01-126-3273
5210-01-126-3273 is a Dial Indicator that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5210-01-126-3273
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5210-01-126-3273
- Canada (ZC)
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5210-01-126-3273
- Part Number
- Manufacturer
- Status
- 657BZ
- Manufacturer
- 57163 - L.S. Starrett Company (The) (Active)
- Primary Buy
- Primary Buy
- 52746
- 57163 - L.S. Starrett Company (The) (Active)
- Secondary Buy
- Secondary Buy
Datasheet 5210-01-126-3273
- Characteristic
- Specifications
- FIIG
- Specifications
- T299-Z
- Measurement Capacity [CPWG]
- 0.030 Inches
- Graduation Unit [ANBJ]
- 0.00100 Inches
- Dial Marking [ASSQ]
- 0-15-0
- Dial Setting Type [CPQX]
- Adjustable
- Contact Point Location [CPQY]
- Back
- Mounting Style [ADER]
- Body Clamp
- Cushioned Movement Feature [CPRC]
- Not Included
- Lifting Lever [CPRD]
- Not Included
- Tell-Tale Hand [CPMK]
- Not Included
- Accessory Components And Quantity [AKYD]
- Base,Magnetic,P/N 657P,1,Swivel Post Assy,P/N 657F,1;Swivel Post Adapter Bushing,P/N 657R,1;Case,Includes Dial Test Indicator,P/N 711Fs
Similar Supply Items to 5210-01-126-3273
Freight Information 5210-01-126-3273
5210-01-126-3273 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 121570. A Sub NMFC of X. It has a NMFC Description of GAGES AIR LIQUID LEVEL PRESSURE. 5210-01-126-3273 is rated as class 100 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 61770 which rates the freight between FCL and LCL. 5210-01-126-3273 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72B for ocean manifesting and military sealift. 5210-01-126-3273 is not classified as a special type of cargo when transported by water. 5210-01-126-3273 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
