5210-00-935-5942
Measuring Tape
5210009355942 009355942 140283-00 C213CX
A narrow strip of flexible material graduated with markings to indicate a specific type of measure such as arithmetic, geometric, metric, or the like. All tapes are used principally in measuring distances and dimensions too long to be measured by a ruler, are usually enclosed into a case with accommodations for rewinding and may or may not have a ring at one end. Includes dressmaker tapes to heavy-duty types sometimes called surveyor's chains, usually mounted in reels with holding handles. View more Measuring Tape
May 2023
13
Marketplace 5210-00-935-5942
Request a Quotation from participating marketplace vendors
Related Documents 5210-00-935-5942 5+ Documents (More...)
/fsg-52/fsc-5210/us
United States (US) 4. 5210-00-935-5942 Marketplace Restrictions Approved Sources Datasheet Management
RQST NE Updated Every Day 5210-00-935-5942 RQST Updated Every Day 5210-00-935-5942 RQST NE Related Documents
Measuring Tape 5210009355942 009355942 Upgrade for $1 a day Upgrade your Account Upgrade 5210-00
-935-5942Measuring Tape5210009355942 009355942 140283 Restrictions 5330-14-478-1625 DEMIL: | DEMILI :
/fsg-83/fsc-8315/dk
/fsg-83/fsc-8315/fr
Restrictions 5210-00-935-5942
5210-00-935-5942 is a Measuring Tape that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5210-00-935-5942
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5210-00-935-5942
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Sep 2009
Approved Sources 5210-00-935-5942
- Part Number
- Manufacturer
- Status
- 140283-00
- Manufacturer
- 97424 - Ametek Inc (Active)
- Primary Buy
- Primary Buy
- C213CX
- 37163 - Cooper Industries Inc Lufkin/Cooper (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5210-00-935-5942
- Characteristic
- Specifications
- FIIG
- Specifications
- T299-E
- Design Type [APGF]
- General Purpose Distance Measuring
- End Type [APTD]
- Butt
- Material [MATT]
- Steel
- Measuring Capacity [CMWL]
- 600 Inches
- National Bureau Of Standards Certification [BTHJ]
- Not Provided
- Inclosure Type [AKNA]
- Case
- Plumb Bob [CNJN]
- Not Included
- Reading Direction [CMWC]
- Left To Right
- Special Features [FEAT]
- Round Vinyl Covered Steel Case; Foldaway Rewind Handle
- Width [ABGL]
- 0.375 Inches Nominal
- Winding Method [AQRE]
- Hand Crank
- Standard Graduation Unit [CMWK]
- Inches
- Tape Smallest Graduation Unit [CMWM]
- 1/10 In.
Similar Supply Items to 5210-00-935-5942
Freight Information 5210-00-935-5942
5210-00-935-5942 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 186440. A Sub NMFC of X. It has a NMFC Description of TOOLS:TAPE MEASURES IN BXS. 5210-00-935-5942 is rated as class 85 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 91000 which rates the freight between FCL and LCL. 5210-00-935-5942 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 732 for ocean manifesting and military sealift. 5210-00-935-5942 is not classified as a special type of cargo when transported by water. 5210-00-935-5942 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
