5210-00-246-2303
Thickness Gage
5210002462303 002462303 467 52464 5013 GGG-G-17 TY8CL1 8067337 GGG-G-17 7901635
One or more tempered steel blades (leaves) ground to and marked with their respective thickness and mounted in a holder or encased within a frame or case into which the leaves fold. It is used for checking narrow slots or gaging the clearance between fitted parts. Excludes BLADE, THICKNESS GAGE. See also GAGE, GAP SETTING. View more Thickness Gage
August 2023
36
Marketplace 5210-00-246-2303
Request a Quotation from participating marketplace vendors
467 RQST NE
52464 RQST NE
Updated Every Day Updated Every Day
Updated Every Day Related Documents 5210-00-246-2303 5+ Documents (More...)
/fsg-52/fsc-5210/us 5210-00-246-2303 Thickness Gage 5210002462303 002462303,467 467524645013GGG-G-17
Thickness Gage 5210002211986 002211986,FG-31 GGG-G-17 TY8CL1 20S https//www.nsnlookup.com /fsg-52/fsc
www.nsnlookup.com /fsg-52/fsc-5210/us 5210-00-804-2660 Thickness Gage 5210008042660 008042660,5012 GGG-G-17
https//www.nsnlookup.com /fsg-52/fsc-5210/us 5210-00-246-2303 Thickness Gage 5210002462303 002462303,467
ground to and marked /fsg-52/fsc-5210/us 5210-00-249-9132 Thickness Gage 5210002499132 002499132 GGG-G-17
https//www.nsnlookup.com /fsg-52/fsc-5210/us 5210-00-246-2303 Thickness Gage 5210002462303 002462303,467
/fsg-52/fsc-5210/us
TY8CL1 20S One or more tempered steel blades (leaves) ground to and marked with their respective GGG-G-17
Gage5210002462303 002462303 467 52464 5013 GGG-G-17 TY8CL1 20S One or more tempered steel blades (leaves
Thickness Gage 5210002462303 002462303,467 Photo 1/2 5210-00-246-2303 Photo 2/2 - - 1.
RQST NE Updated Every Day 5210-00-246-2303 RQST Updated Every Day 5210-00-246-2303 RQST NE Related Documents
Restrictions 5210-00-246-2303
5210-00-246-2303 is a Thickness Gage that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5210-00-246-2303
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5210-00-246-2303
- US Army (A192)
- Effective Date:
- 1 Apr 1991
- Supplementary Receivers:
- AZ
- US Air Force (FGGS)
- Effective Date:
- 1 Apr 1991
- NASA (G281)
- Effective Date:
- 1 Apr 1991
- NASA (G751)
- Effective Date:
- 1 Apr 1991
- NASA (G861)
- Effective Date:
- 1 Apr 1991
- US Marine Corps (MC14)
- Effective Date:
- 1 Jul 1993
- US Navy (N9QG)
- Effective Date:
- 1 Apr 1991
- Supplementary Collaborators:
- GTJFHD
- Brazil (YA01)
- Effective Date:
- 1 Aug 2000
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Belgium (ZB01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Jan 1997
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 5210-00-246-2303
- Part Number
- Manufacturer
- Status
- 467
- Manufacturer
- 57163 - L.S. Starrett Company (The) (Active)
- Primary Buy
- Primary Buy
- 52464
- 57163 - L.S. Starrett Company (The) (Active)
- Secondary Buy
- Secondary Buy
- 5013
- 08871 - Products Engineering Corporation (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- GGG-G-17 TY8CL1
- 80244 - General Services Administration (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 8067337
- 72915 - General Motors Corp (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- GGG-G-17
- 81348 - Federal Specifications Promulgated (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 7901635
- 19200 - Combat Capabilities Development (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5210-00-246-2303
- Characteristic
- Specifications
- FIIG
- Specifications
- T299-K
- Blade Group Quantity [CNLG]
- 1
- Measurement System [BDLS]
- English
- Blade Shape [AJMH]
- Straight
- Blade Quantity [AJLB]
- 13
- Blade Length [AEAE]
- 4.500 Inches Nominal
- Blade Tip Width [CMZF]
- 0.500 Inches Nominal
- Blade Thickness [CPMW]
- 0.0015 Inches 1St Blade
- Blade Thickness [CPMW]
- 0.0020 Inches 2Nd Blade
- Blade Thickness [CPMW]
- 0.0030 Inches 3Rd Blade
- Blade Thickness [CPMW]
- 0.0040 Inches 4Th Blade
- Blade Thickness [CPMW]
- 0.0060 Inches 5Th Blade
- Blade Thickness [CPMW]
- 0.0080 Inches 6Th Blade
- Blade Thickness [CPMW]
- 0.0100 Inches 7Th Blade
- Blade Thickness [CPMW]
- 0.0200 Inches 8Th Blade
- Blade Thickness [CPMW]
- 0.0300 Inches 9Th Blade
- Blade Thickness [CPMW]
- 0.0400 Inches 10Th Blade
- Blade Thickness [CPMW]
- 0.0750 Inches 11Th Blade
- Blade Thickness [CPMW]
- 0.1000 Inches 12Th Blade
- Blade Thickness [CPMW]
- 0.2000 Inches 13Th Blade
- Blade Lock [CNLH]
- Not Included
DLA Procurement Analysis 5210-00-246-2303
Management Data 5210-00-246-2303
Army
- Materiel Category and Inventory Manager:
- E
- General Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- D
- Durable item.An item of Army property coded with an ARC of D in the AMDF. Durable items do not require property book accountability after issue from the stock record account but do require hand receipt control when issued to the user. Commercial and fabricated items similar to items coded D in the AMDF are considered durable items.
Navy
- Cognizance:
- 9Q
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- 02
- Operational Test:
- 3
- Calibration Required
- Physical Category:
- 1
- Bin
Similar Supply Items to 5210-00-246-2303
Freight Information 5210-00-246-2303
5210-00-246-2303 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 186620. A Sub NMFC of Z. It has a NMFC Description of TOOLS, NOI HAND OTHER THAN POWER. 5210-00-246-2303 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 91810 which rates the freight between FCL and LCL. 5210-00-246-2303 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 732 for ocean manifesting and military sealift. 5210-00-246-2303 is not classified as a special type of cargo when transported by water. 5210-00-246-2303 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
