5210-00-127-7955
Dial Indicator
5210001277955 001277955 B8I 380009-1 12504BJ 81-141J 53400 J1-20111 J1-B50-250 5210PL0816920
A mechanism for amplifying and measuring the displacement of a movable contact point, thereby measuring a dimension or variation from a standard dimension. It consists essentially of a case with means for mounting the indicator, a spindle carrying the contact point, an amplifying mechanism, a pointer and a graduated dial. May include accessories and/or attachments. Excludes INDICATOR, SCALE. See also GAGE, DEPTH, DIAL INDICATING. View more Dial Indicator
August 2023
35
Marketplace 5210-00-127-7955
Request a Quotation from participating marketplace vendors
81-141J RQST NE
53400 RQST NE
Updated Every Day Updated Every Day
Updated Every Day Related Documents 5210-00-127-7955 5+ Documents (More...)
Photo 1/5 5210-00-127-7955 Photo 2/5 5210-00-127-7955 Photo 3/5 NSN 5210-00-127-7955 (Identification
Global Test Supply 53400 RQST NE Updated Every Day 5210-00-127-7955 RQST NE Updated Every Day 5210-00
/fsg-52/fsc-5210/us
Dial Indicator 5210001277955 001277955,B8I Documents 5210-00-127-7955 5+ Documents ( More... )
AssyUOMTechnical DocumentQuantative ExpressionDepartment of the Navy (DN)NZDiscontinued-Use 5210-00-127-7955
/fsg-52/fsc-5210/us
Updated Every 15 Minutes 5210-00-555-8731 BUY NE https//www.nsnlookup.com /fsg-52/fsc-5210/us 5210-00-127-7955
Dial Indicator 5210001277955 001277955,B8I 7955Dial Indicator5210001277955 001277955B8I380009-1
Dial Indicator 5210001277955 001277955,B8I the Navy (DN)NZDiscontinued-Use 5210-00-127-7955 https
/fsg-52/fsc-5210/us
81-141J Dial Indicator, 0 to 0.25" range, 0 to 50 to 0 STK NE $153.63 Distributor Buy Now Updated Every
Day Search Global Test Supply 81-141J RQST NE Updated Every Day 5210-01-397-3009 RQST NE Updated Every
Restrictions 5210-00-127-7955
5210-00-127-7955 is a Dial Indicator that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5210-00-127-7955
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5210-00-127-7955
- US Army (A192)
- Effective Date:
- 1 Apr 1991
- US Coast Guard (C014)
- Effective Date:
- 1 Apr 1991
- US Air Force (FGGS)
- Effective Date:
- 1 Apr 1991
- NASA (G751)
- Effective Date:
- 1 Apr 1991
- NASA (G881)
- Effective Date:
- 1 Apr 1991
- US Marine Corps (MC14)
- Effective Date:
- 1 Dec 2000
- US Navy (N9QG)
- Effective Date:
- 1 Apr 1991
- Supplementary Collaborators:
- GTKEHD
- Poland (WP01)
- Effective Date:
- 1 Jun 2007
- Brazil (YA01)
- Effective Date:
- 1 Jan 2011
- Israel (YD01)
- Effective Date:
- 1 Aug 2016
- Singapore (YJ01)
- Effective Date:
- 1 Dec 2010
- Republic of Korea (ZH01)
- Effective Date:
- 1 Jan 1994
- Netherlands (ZN01)
- Effective Date:
- 1 Nov 2000
- Greece (ZU01)
- Effective Date:
- 1 Jun 2011
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
- NATO Maintenance and Supply Agency (ZX01)
- Effective Date:
- 1 Jan 2014
Approved Sources 5210-00-127-7955
- Part Number
- Manufacturer
- Status
- B8I
- Manufacturer
- 21938 - Mahr Inc (Active)
- Incomplete Reference
- Incomplete Reference
- 380009-1
- 75324 - Kilgore Flares Company Llc (Active)
- Primary Buy
- Primary Buy
- 12504BJ
- 05392 - Chicago Dial Indicator Co (Active)
- Primary Buy
- Primary Buy
- 81-141J
- 57163 - L.S. Starrett Company (The) (Active)
- Primary Buy
- Primary Buy
- 53400
- 57163 - L.S. Starrett Company (The) (Active)
- Secondary Buy
- Secondary Buy
- J1-20111
- 56745 - Standard Gage Co Inc (Active)
- Secondary Buy
- Secondary Buy
- J1-B50-250
- 05392 - Chicago Dial Indicator Co (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 380009-1
- 93712 - Alliant Defense Electronics Systems (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 5210PL0816920
- 9009H - Jednolity Indeks Materialowy - (Active)
- NATO Reference
- NATO Reference
Datasheet 5210-00-127-7955
- Characteristic
- Specifications
- FIIG
- Specifications
- T299-Z
- Measurement Capacity [CPWG]
- 0.250 Inches
- Graduation Unit [ANBJ]
- 0.00100 Inches
- Dial Marking [ASSQ]
- 0-50-0
- Dial Type [ATGR]
- Balanced
- Overall Diameter [ADAV]
- 1.688 Inches Nominal
- Dial Setting Type [CPQX]
- Fixed
- Contact Point Location [CPQY]
- Stem
- Mounting Style [ADER]
- Lug On Center
- Contact Point Action Type [CPQZ]
- Plunger
- Contact Point Style Designator [CPRB]
- Regular
- Bearing Type [BYDT]
- Jewel
- Cushioned Movement Feature [CPRC]
- Not Included
- Lifting Lever [CPRD]
- Not Included
- Tell-Tale Hand [CPMK]
- Not Included
Management Data 5210-00-127-7955
Army
- Materiel Category and Inventory Manager:
- E
- General Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- D
- Durable item.An item of Army property coded with an ARC of D in the AMDF. Durable items do not require property book accountability after issue from the stock record account but do require hand receipt control when issued to the user. Commercial and fabricated items similar to items coded D in the AMDF are considered durable items.
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9Q
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- 02
- Operational Test:
- 3
- Calibration Required
- Physical Category:
- 1
- Bin
Similar Supply Items to 5210-00-127-7955
Freight Information 5210-00-127-7955
5210-00-127-7955 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 121570. A Sub NMFC of X. It has a NMFC Description of GAGES AIR LIQUID LEVEL PRESSURE. 5210-00-127-7955 is rated as class 100 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 61770 which rates the freight between FCL and LCL. 5210-00-127-7955 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72B for ocean manifesting and military sealift. 5210-00-127-7955 is not classified as a special type of cargo when transported by water. 5210-00-127-7955 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
