5136-00-224-1507
Rethreading Die
5136002241507 002241507 5136-00-224-1507 24185 31329 A-A-413 GGG-D-296 7273 C65631 GGG-D-296 TY3SEB
A tool used exclusively for recutting or dressing over bruised, battered, crossed or rusty threads on bolts, axles and the like. It may be either a solid nut type, hinged clamp type or finger type. In use, the solid nut type is used with a wrench, the hinged clamp type is hand held, the finger type is used with a fixed cross pin through same or may have a shank with a square drive for use with a wrench. Excludes CHASER, THREAD, HAND; DIE AND COLLET; DIE, THREAD CUTTING and RESTORER, THREAD. View more Rethreading Die
November 2023
10
Marketplace 5136-00-224-1507
Request a Quotation from participating marketplace vendors
Related Documents 5136-00-224-1507 5+ Documents (More...)
Minutes 5136-00-224-1507 BUY NE Updated Every Day 5136-00-224-1507 RQST NE Updated Every Day 5136-00
Day 5136-00-224-1507 RQST NE Updated Every Day 5136-00 7249 GGG-D-296 TY3SEB https//www.nsnlookup.com
Rethreading Die 5136002241507 002241507 GGG-D-296 7273 C65631 GGG-D TY3SEB A tool used exclusively
Rethreading Die 5136002241507 002241507 GGG-D-296 7273 C65631 GGG-D-296 TY3SEB A tool used exclusively
C65631 GGG-D-296 TY3SEB A tool used exclusively for recutting or dressing over bruised Rethreading https
//www.nsnlookup.com /fsg-51/fsc-5136/us 5136-00-224-1507 Rethreading Die 5136002241507 002241507 GGG-D
C65631 GGG-D-296 TY3SEB A tool used exclusively for https//www.nsnlookup.com /fsg-51/fsc-5136/us 5136
C65631 GGG-D-296 TY3SEB A tool used exclusively for recutting or dressing over bruised 5136 GGG-D-296
A tool used exclusively for recutting or dressing over bruised, battered 7273 C65631 GGG-D-296 TY3SEB
TY3SEB A tool used exclusively for recutting or dressing over bruised, battered, 7273 C65631 GGG-D
Restrictions 5136-00-224-1507
5136-00-224-1507 is a Rethreading Die that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5136-00-224-1507
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5136-00-224-1507
- US Army (A192)
- Effective Date:
- 1 Apr 1991
- NASA (G751)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 5136-00-224-1507
- Part Number
- Manufacturer
- Status
- 5136-00-224-1507
- Manufacturer
- 80244 - General Services Administration (Active)
- Primary Buy
- Primary Buy
- 7273
- 78525 - Stanley Tools Div Of Stanley Works (Active)
- Primary Buy
- Primary Buy
- 24185
- 60NQ9 - Greenfield Industries Inc (Active)
- Secondary Buy
- Secondary Buy
- 31329
- 067J8 - Morse Cutting Tools (Active)
- Secondary Buy
- Secondary Buy
- C65631
- 60NQ9 - Greenfield Industries Inc (Active)
- Secondary Buy
- Secondary Buy
- 24185
- 1NEX4 - Kennametal Inc. (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- A-A-413
- 58536 - Federal Commercial Item Description (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- GGG-D-296
- 81348 - Federal Specifications Promulgated (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 7273
- 1JU00 - Irwin Industrial Tool Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- C65631
- 1NEX4 - Kennametal Inc. (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 7273
- 5M2Q1 - Irwin Industrial Tool Company (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- GGG-D-296 TY3SEB
- 80244 - General Services Administration (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5136-00-224-1507
- Characteristic
- Specifications
- FIIG
- Specifications
- A13600
- Material And Location [ANNQ]
- Tool Steel Overall
- Width Across Flats [AAZK]
- 2.375 Inches Nominal
- Style Designator [STYL]
- Solid Hexagon Nut
- Thickness [ABNM]
- 1.000 Inches Nominal
- Thread Direction [AAJF]
- Right-Hand
- Thread Pitch Diameters [AAJE]
- +1.3096/+1.3209 Inches
- Thread Size And Series/Type Designator [THDS]
- 1.375-12 Unf
Management Data 5136-00-224-1507
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Feb 2020
- Department of the Army (DA)
- EA
- Subscribe
- EA
Army
- Materiel Category and Inventory Manager:
- E
- General Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Similar Supply Items to 5136-00-224-1507
Freight Information 5136-00-224-1507
5136-00-224-1507 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 186620. A Sub NMFC of Z. It has a NMFC Description of TOOLS, NOI HAND OTHER THAN POWER. 5136-00-224-1507 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 91810 which rates the freight between FCL and LCL. 5136-00-224-1507 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 732 for ocean manifesting and military sealift. 5136-00-224-1507 is not classified as a special type of cargo when transported by water. 5136-00-224-1507 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
