5136-00-189-3128
Rethreading Die
5136001893128 001893128 5136-00-189-3128 2573A46 24191 377 1-1/2-12 UNF 31331 C65633 GGG-D-296 7275 GGG-D-296 TY3SEB A-A-413
A tool used exclusively for recutting or dressing over bruised, battered, crossed or rusty threads on bolts, axles and the like. It may be either a solid nut type, hinged clamp type or finger type. In use, the solid nut type is used with a wrench, the hinged clamp type is hand held, the finger type is used with a fixed cross pin through same or may have a shank with a square drive for use with a wrench. Excludes CHASER, THREAD, HAND; DIE AND COLLET; DIE, THREAD CUTTING and RESTORER, THREAD. View more Rethreading Die
November 2023
18
Marketplace 5136-00-189-3128
Request a Quotation from participating marketplace vendors
Related Documents 5136-00-189-3128 5+ Documents (More...)
Details... 31331 DIE,RETHREADING 23 EA NS Request Quotation Subscribe to View Vendor Details... 7275
BUY NE Updated Every Day 2573A46 RQST NE Updated Every Day 5136-00-189-3128 RQST NE Updated Every Day
Documents 5136-01-118-4065 1+ Documents ( More https//www.nsnlookup.com /fsg-51/fsc-5136/us 5136-00-189-3128
Rethreading Die 5136001893128 001893128 51360018931280018931287275GGG-D-296 holding device https
-296 TY3SEB A tool used exclusively for recutting or dressing over bruised, battered 7273 C65631 GGG-D-296
TY3SEB A tool used exclusively for recutting 0018931097736GGG-D-296 https/ 7273 C65631 GGG-D-296
TY3SEB A tool used exclusively for recutting or dressing over bruised, battered 7273 C65631 GGG-D-296
Rethreading Die 5136001893128 001893128 7275 GGG-D-296 TY3SEBA-A-413 A tool used exclusively for
GGG-D-296 TY3SEB A tool used exclusively for recutting or dressing over bruised, battered TY3SEB
/fsg-51/fsc-5136/us 5136-00-197-9571 Rethreading Die 5136001979571 001979571 A-A-413 GGG-D-296 TY3SEB
Restrictions 5136-00-189-3128
5136-00-189-3128 is a Rethreading Die that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5136-00-189-3128
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5136-00-189-3128
- US Army (A192)
- Effective Date:
- 1 Apr 1991
- US Air Force (FGGS)
- Effective Date:
- 1 Apr 1991
- NASA (G751)
- Effective Date:
- 1 Apr 1991
- NASA (G901)
- Effective Date:
- 1 Apr 1991
- US Navy (N9QG)
- Effective Date:
- 1 Apr 1991
- Supplementary Collaborators:
- GTHXHD
- Brazil (YA01)
- Effective Date:
- 1 Mar 2003
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Argentina (YF01)
- Effective Date:
- 1 Sep 2015
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 5136-00-189-3128
- Part Number
- Manufacturer
- Status
- 5136-00-189-3128
- Manufacturer
- 80244 - General Services Administration (Active)
- Primary Buy
- Primary Buy
- 7275
- 78525 - Stanley Tools Div Of Stanley Works (Active)
- Primary Buy
- Primary Buy
- 2573A46
- 39428 - Mcmaster-Carr Supply Co (Active)
- Secondary Buy
- Secondary Buy
- 24191
- 60NQ9 - Greenfield Industries Inc (Active)
- Secondary Buy
- Secondary Buy
- 377 1-1/2-12 UNF
- 60NQ9 - Greenfield Industries Inc (Active)
- Secondary Buy
- Secondary Buy
- 31331
- 067J8 - Morse Cutting Tools (Active)
- Secondary Buy
- Secondary Buy
- C65633
- 1NEX4 - Kennametal Inc. (Active)
- Secondary Buy
- Secondary Buy
- GGG-D-296
- 81348 - Federal Specifications Promulgated (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 7275
- 1JU00 - Irwin Industrial Tool Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- GGG-D-296 TY3SEB
- 80244 - General Services Administration (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 7275
- 5M2Q1 - Irwin Industrial Tool Company (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 24191
- 1NEX4 - Kennametal Inc. (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- A-A-413
- 58536 - Federal Commercial Item Description (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5136-00-189-3128
- Characteristic
- Specifications
- FIIG
- Specifications
- A13600
- Material And Location [ANNQ]
- Tool Steel Overall
- Width Across Flats [AAZK]
- 2.562 Inches Nominal
- Style Designator [STYL]
- Solid Hexagon Nut
- Thickness [ABNM]
- 1.000 Inches Nominal
- Thread Direction [AAJF]
- Right-Hand
- Thread Pitch Diameters [AAJE]
- +1.4344/+1.4459 Inches
- Thread Size And Series/Type Designator [THDS]
- 1.500-12 Unf
Management Data 5136-00-189-3128
Army
- Materiel Category and Inventory Manager:
- E
- General Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- D
- Durable item.An item of Army property coded with an ARC of D in the AMDF. Durable items do not require property book accountability after issue from the stock record account but do require hand receipt control when issued to the user. Commercial and fabricated items similar to items coded D in the AMDF are considered durable items.
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9Q
NATO Stock Numbers Related to 5136-00-189-3128
Freight Information 5136-00-189-3128
5136-00-189-3128 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 186620. A Sub NMFC of Z. It has a NMFC Description of TOOLS, NOI HAND OTHER THAN POWER. 5136-00-189-3128 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 91810 which rates the freight between FCL and LCL. 5136-00-189-3128 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 732 for ocean manifesting and military sealift. 5136-00-189-3128 is not classified as a special type of cargo when transported by water. 5136-00-189-3128 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
