5133-01-600-8643
Multi-Step Drill
5133016008643 016008643 YA1MTA 16101 UNIBIT 1MT
A conical shape cutting tool with a single or double spiral flute design for drilling or enlarging a progressively larger hole in thin sections of metal, plastic or wood. View more Multi-Step Drill
May 2023
11
Marketplace 5133-01-600-8643
Request a Quotation from participating marketplace vendors
Related Documents 5133-01-600-8643 5+ Documents (More...)
7467 Multi-Step Drill 10239RNCC: 3 | RNVC: 9 | DAC: 4 1 Aug 2012 5133-01-144-5335 Multi-Step Drill UNIBIT
Restrictions 5133-01-600-8643
5133-01-600-8643 is a Multi-Step Drill that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
End Users 5133-01-600-8643
- Australia (ZA01)
- Effective Date:
- 1 Jul 2015
- Denmark (ZS01)
- Effective Date:
- 1 Dec 2011
Approved Sources 5133-01-600-8643
- Part Number
- Manufacturer
- Status
- YA1MTA
- Manufacturer
- 55719 - Idsc Holdings Llc (Active)
- Primary Buy
- Primary Buy
- 16101
- 5M2Q1 - Irwin Industrial Tool Company (Obsolete)
- Original Design
- Original Design
- UNIBIT
- 5M2Q1 - Irwin Industrial Tool Company (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 1MT
- 1JU00 - Irwin Industrial Tool Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 1MT
- 5M2Q1 - Irwin Industrial Tool Company (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 16101
- 1JU00 - Irwin Industrial Tool Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- UNIBIT
- 1JU00 - Irwin Industrial Tool Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5133-01-600-8643
- Characteristic
- Specifications
- FIIG
- Specifications
- A576N0
- Drive Shank Type [BPMX]
- Male Straight Hexagon
- Cutting Diameter Range [AKZM]
- +4.0 To 12.0 Millimeters
- Features Provided [CBBL]
- Self-Starting
- Flute Quantity [ALAR]
- 1
- Material [MATT]
- Steel,High Speed Overall
- Shank Width Across Wrench Flats [AGHB]
- 0.250 Inches Nominal
- Overall Length [ABHP]
- 3.250 Inches Nominal
- Step Quantity [ATPC]
- 9
- Surface Treatment [SFTT]
- Titanium Nitride
NATO Stock Numbers Related to 5133-01-600-8643
Freight Information 5133-01-600-8643
5133-01-600-8643 has freight characteristics.. 5133-01-600-8643 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
