5133-01-017-8306

Wood Boring Spade Bit

5133010178306 010178306 88815 88 15/16

A manual or power driven boring tool with a flat body provided with a sharp center point to serve as a guide, a shearing edge to cut the fibers around the edge of the hole and a broad chisel edge to pare and remove the center. View more Wood Boring Spade Bit

5133-01-017-8306 BIT,SPADE,WOOD BORING 5133010178306 010178306

Managed by United States
NSN Created on 14 Mar 1976
Data Last Changed
May 2023
NATO Update Count
12
NATO Data Quality
5133-01-017-8306 BIT,SPADE,WOOD BORING 5133010178306 010178306 1/3
5133-01-017-8306 Photo 1/3
AAZF Style 90 for 5133-01-017-8306 2/3
NSN 5133-01-017-8306 (Identification) 2/3
AKZH Style 14 for 5133-01-017-8306 3/3
NSN 5133-01-017-8306 (Identification) 3/3

5133-01-017-8306 Stock and Availability Marketplace 5133-01-017-8306

Need Help?
Request a Quotation from participating marketplace vendors

5133-01-017-8306 Related Documents Related Documents 5133-01-017-8306 5+ Documents (More...)

88815 88 15/16 A manual or power driven boring tool with a flat body provided with a sharp center point
Photo 1/3 NSN 5133-01-017-8306 (Identification) 2/3 NSN 5133-01-017-8306 (Identification) 3/3 -
WOOD BORING 10 EA NS Request Quotation Updated Every Day 5133-01-017-8306 RQST NE Updated Every Day 5133
how to enable JavaScript in your web browser . 1005-15-008-9858Breechblock1005150089858 150089858 88815
https//www.nsnlookup.com /fsg-51/fsc-5133/us 5133-01-017-8306 Wood Boring Spade Bit 5133010178306 010178306
$1 a day Upgrade your Account Upgrade 5133-01-017-8306Wood Boring Spade Bit5133010178306 010178306 88815
in your web browser . 5315-99-419-8943Headless Grooved Pin5315994198943 994198943 GP2 DEFSTAN53-83 88815
//www.nsnlookup.com /fsg-10/fsc-1005/it 1005-15-008-9858 Breechblock 1005150089858 150089858,88815 88815
DEFSTAN53-83 K0851 - Ministry Of Defence, Directorate Of (Active) NATO Reference RNCC 6 RNVC 9 DAC 9 88815
in your web browser . 5315-99-419-8949Headless Grooved Pin5315994198949 994198949 GP5 DEFSTAN53-83 88815
DEFSTAN53-83 K0851 - Ministry Of Defence, Directorate Of (Active) NATO Reference 88815 DEFSTAN53-83
K0851 - Ministry Of Defence, Directorate Of (Active) NATO Reference RNCC 6 RNVC 9 DAC 9 88815 https//
in your web browser . 5315-99-419-8921Headless Grooved Pin5315994198921 994198921 GP5 DEFSTAN53-83 88815
Wood Boring Spade Bit 5133010178306 010178306 Headless Grooved Pin 5315994198921994198921 in your
web browser . 5315-99-419-8921Headless Grooved Pin5315994198921 994198921GP5DEFSTAN53-83 88815 DEFSTAN53

5133-01-017-8306 Demil Restrictions 5133-01-017-8306

DEMIL: A | DEMILI: 1 | CRITICALITY: X | HMIC: N | PMIC: A | EDC: | ADPEC:

5133-01-017-8306 is a Wood Boring Spade Bit that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.

5133-01-017-8306 HTS and ScheduleB Import and Export 5133-01-017-8306

5133-01-017-8306 End Users End Users 5133-01-017-8306

Canada (ZC01)
Effective Date:
1 Nov 2007

5133-01-017-8306 Manufacturers Approved Sources 5133-01-017-8306

5133-01-017-8306 Technical Data Datasheet 5133-01-017-8306

Characteristic
Specifications
FIIG
A188A0
Cutting End Style [AKZH]
Flat Head Machine W/Brad Point
Hardness Rating [CQFM]
40.0 Rockwell C Minimum And 53.0 Rockwell C Maximum
Nominal Cutting Diameter [AKZL]
0.9375 Inches
Material [MATT]
Steel Overall
Shank Style [AAZF]
Hexagon W/Shoulder
Overall Length [ABHP]
6.000 Inches Nominal
Width Across Flats [ASDB]
0.250 Inches Nominal

5133-01-017-8306 Similar Items Similar Supply Items to 5133-01-017-8306

5133-01-017-8306 Freight Data Freight Information 5133-01-017-8306

5133-01-017-8306 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 186630. A Sub NMFC of X. It has a NMFC Description of TOOLS:NOI O/T PLSTC IN BBLS/BXS. 5133-01-017-8306 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. 5133-01-017-8306 is rated as class 70 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 91810 which rates the freight between FCL and LCL. 5133-01-017-8306 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 732 for ocean manifesting and military sealift. 5133-01-017-8306 is not classified as a special type of cargo when transported by water. 5133-01-017-8306 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
