5133-00-596-1022
Auger Bit
5133005961022 005961022 GGG-B-383 47409
A manual or power driven boring tool with a double twist solid center or a single twist hollow or solid center body of one nominal diameter. It is formed into a cutter head at one end, and a shank at the other end. The double twist body type must have either a screw point or a brad point. Excludes BIT, PLUG; and BIT, EXPANSIVE. See also BIT, HOLLOW CHISEL. View more Auger Bit
May 2023
8
Marketplace 5133-00-596-1022
Request a Quotation from participating marketplace vendors
Related Documents 5133-00-596-1022 5+ Documents (More...)
Photo 1/4 5133-00-596-1022 Photo 2/4 NSN 5133-00-596-1022 (Identification) 3/4 NSN 5133-00-596-
GGG-B-383 BIT,AUGER 8 EA NS Request Quotation Subscribe to View Vendor Details... 47409 BIT,AUGER 10
/1/4-374-SP374-SPA-47409 A valve permitting flow in one direction only.
/1/4-374-SP374-SPA-47409 A valve https//www.nsnlookup.com /fsg-43/fsc-4320/uk 4320-99-544-2541 Inlet
TY1CLG A spurless boring tool with a cutter head having a scoring rib on opposite GGG-B-383 TY1CLG
GGG-B-383 TY1CLG A spurless boring tool with a cutter head having a scoring rib on opposite sides
GGG-B-383 TY1CLI A manual or power driven boring tool with a double twist solid center or a single
GGG-B-383 BIT,AUGER 8 EA NS Request Quotation Updated Every Day 5133-00-273-2784 RQST NE Updated Every
GGG-B-383 BIT,FORSTNER 8 EA NS Request Quotation Updated Every Day 5133-00-142-4977 RQST NE Updated Every
383GGG-B-383 TY1CLG A spurless boring tool with a -142-4969 Forstner Bit 5133001424969 001424969 GGG-B-383
Restrictions 5133-00-596-1022
5133-00-596-1022 is a Auger Bit that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5133-00-596-1022
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5133-00-596-1022
- US Army (A192)
- Effective Date:
- 1 Apr 1991
- NASA (G751)
- Effective Date:
- 1 Apr 1991
- US Marine Corps (MC14)
- Effective Date:
- 1 Apr 1991
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
Approved Sources 5133-00-596-1022
- Part Number
- Manufacturer
- Status
- 47409
- Manufacturer
- 78525 - Stanley Tools Div Of Stanley Works (Active)
- Primary Buy
- Primary Buy
- GGG-B-383
- 81348 - Federal Specifications Promulgated (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 47409
- 1JU00 - Irwin Industrial Tool Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 47409
- 5M2Q1 - Irwin Industrial Tool Company (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5133-00-596-1022
- Characteristic
- Specifications
- FIIG
- Specifications
- A188A0
- Cutting End Style [AKZH]
- Hollow Center Single Twist W/O Point
- Hardness Rating [CQFM]
- 40.0 Rockwell C Minimum And 53.0 Rockwell C Maximum
- Nominal Cutting Diameter [AKZL]
- 0.5625 Inches
- Material [MATT]
- Steel Overall
- Shank Square Width [ALAJ]
- 0.437 Inches Nominal
- Shank Style [AAZF]
- Straight Square Tang
- Overall Length [ABHP]
- 16.250 Inches Nominal
- Twist Length [AKZY]
- 12.000 Inches Minimum
Management Data 5133-00-596-1022
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Feb 2020
- Department of the Army (DA)
- EA
- Subscribe
- 6
- EA
Army
- Materiel Category and Inventory Manager:
- E
- General Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- 02
- Operational Test:
- No Special Procedures
NATO Stock Numbers Related to 5133-00-596-1022
Freight Information 5133-00-596-1022
5133-00-596-1022 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 186620. A Sub NMFC of Z. It has a NMFC Description of TOOLS, NOI HAND OTHER THAN POWER. 5133-00-596-1022 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 91810 which rates the freight between FCL and LCL. 5133-00-596-1022 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 732 for ocean manifesting and military sealift. 5133-00-596-1022 is not classified as a special type of cargo when transported by water. 5133-00-596-1022 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
