5133-00-293-2901
Auger Bit
5133002932901 002932901 5133-00-293-2901 04486714 GGG-B-383 GGG-B-383 TY1CLA 43604
A manual or power driven boring tool with a double twist solid center or a single twist hollow or solid center body of one nominal diameter. It is formed into a cutter head at one end, and a shank at the other end. The double twist body type must have either a screw point or a brad point. Excludes BIT, PLUG; and BIT, EXPANSIVE. See also BIT, HOLLOW CHISEL. View more Auger Bit
May 2023
33
Marketplace 5133-00-293-2901
Request a Quotation from participating marketplace vendors
Related Documents 5133-00-293-2901 5+ Documents (More...)
View Vendor Details... 5133-00-293-2901 BIT,AUGER 5 EA NS Request Quotation GGG-B-383 BIT,AUGER 8 EA
43604 BIT,AUGER 10 EA NS Request Quotation Subscribe to View Vendor Details... 5133-00-293-2901 BIT,AUGER
View Vendor Details... 43604 BIT,AUGER 18 EA NS Request Quotation 5133-00-293-2901 BIT,AUGER 5 EA NS
Restrictions Approved Sources Datasheet Management https//www.nsnlookup.com /fsg-51/fsc-5133/us 5133-00-293-2901
Auger Bit 5133002932901 002932901 View Vendor Details... 5133-00-293-2901 BIT,AUGER https//www.nsnlookup.com
TY1CLA A manual or power driven boring tool with a double twist solid center or a single GGG-B-383
GGG-B-383 TY1CLA A manual or power driven boring tool with a double twist solid center or a single
GGG-B-383 TY1CLA A manual or power driven boring tool with a double twist solid center or a single
GGG-B-383 TY1CLA A manual or power driven boring tool with a double twist solid center or a single
Restrictions 5133-00-293-2901
5133-00-293-2901 is a Auger Bit that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5133-00-293-2901
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5133-00-293-2901
- US Army (A192)
- Effective Date:
- 1 Apr 1991
- Supplementary Receivers:
- AMCLBFAZ
- US Coast Guard (C014)
- Effective Date:
- 1 Apr 1991
- US Air Force (FGGS)
- Effective Date:
- 1 Apr 1991
- Supplementary Receivers:
- TT
- NASA (G061)
- Effective Date:
- 1 Apr 1991
- NASA (G161)
- Effective Date:
- 1 Apr 1991
- NASA (G721)
- Effective Date:
- 1 Apr 1991
- NASA (G751)
- Effective Date:
- 1 Apr 1991
- NASA (G811)
- Effective Date:
- 1 Apr 1991
- NASA (G901)
- Effective Date:
- 1 Apr 1991
- US Marine Corps (MC14)
- Effective Date:
- 1 Apr 1991
- US Navy (N9QG)
- Effective Date:
- 1 Aug 1998
- Former MOE Rule:
- NIQG
- Supplementary Collaborators:
- GTJNHD
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Poland (WP01)
- Effective Date:
- 1 Feb 2005
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Belgium (ZB01)
- Effective Date:
- 1 Apr 1991
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- France (ZF01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 5133-00-293-2901
- Part Number
- Manufacturer
- Status
- 5133-00-293-2901
- Manufacturer
- 80244 - General Services Administration (Active)
- Primary Buy
- Primary Buy
- 43604
- 78525 - Stanley Tools Div Of Stanley Works (Active)
- Primary Buy
- Primary Buy
- 04486714
- ZD484 - J. Blackwood & Son Pty Ltd (Active)
- Secondary Buy
- Secondary Buy
- GGG-B-383
- 81348 - Federal Specifications Promulgated (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- GGG-B-383 TY1CLA
- 80244 - General Services Administration (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 43604
- 5M2Q1 - Irwin Industrial Tool Company (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 43604
- 1JU00 - Irwin Industrial Tool Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5133-00-293-2901
- Characteristic
- Specifications
- FIIG
- Specifications
- A188A0
- Cutting End Style [AKZH]
- Solid Center Single Twist W/Screw Point
- Hardness Rating [CQFM]
- 40.0 Rockwell C Minimum And 53.0 Rockwell C Maximum
- Nominal Cutting Diameter [AKZL]
- 0.2500 Inches
- Material [MATT]
- Steel Overall
- Shank Large End Square Width [ALAF]
- 0.312 Inches Nominal
- Shank Small End Square Width [ALAH]
- 0.188 Inches Nominal
- Shank Style [AAZF]
- Taper-Square
- Overall Length [ABHP]
- 7.500 Inches Nominal
- Twist Length [AKZY]
- 3.375 Inches Nominal
Management Data 5133-00-293-2901
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- May 2019
- Department of the Air Force (DF)
- EA
- Subscribe
- 6
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- US Marine Corps (DM)
- M
- 0
- Reversal Of Phrase Code Z 5133-00-233-8124
- 0
Army
- Materiel Category and Inventory Manager:
- E
- General Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9Q
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- 02
- Operational Test:
- No Special Procedures
Similar Supply Items to 5133-00-293-2901
Freight Information 5133-00-293-2901
5133-00-293-2901 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 186620. A Sub NMFC of Z. It has a NMFC Description of TOOLS, NOI HAND OTHER THAN POWER. 5133-00-293-2901 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 91810 which rates the freight between FCL and LCL. 5133-00-293-2901 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 732 for ocean manifesting and military sealift. 5133-00-293-2901 is not classified as a special type of cargo when transported by water. 5133-00-293-2901 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
