5130-01-594-8416
Electric Impact Wrench
5130015948416 015948416 2663-22
An electric-powered hand-held rotary tool, which converts continuous rotary motion to rotary impacting motion at a given torque, for use in tightening and loosening fasteners, such as bolts, nuts, screws, and the like. The item may contain screwdriver bit(s), socket(s) and/or chuck(s). Excludes NUT RUNNER AND SCREWDRIVER, ELECTRIC. View more Electric Impact Wrench
May 2023
2
Marketplace 5130-01-594-8416
Request a Quotation from participating marketplace vendors
Related Documents 5130-01-594-8416 1+ Documents (More...)
Every Day 5130-01-594-8416 RQST NE Related Documents 5130-01-594-8416 1+ Documents ( More... ) https
//www.nsnlookup.com /fsg-51/fsc-5130/us 5130-01-594-8416 RQST NE Updated Every Day 5130-01-594-8416 RQST
Restrictions 5130-01-594-8416
5130-01-594-8416 is a Electric Impact Wrench that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5130-01-594-8416
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5130-01-594-8416
- Canada (ZC01)
- Effective Date:
- 1 Apr 2011
Approved Sources 5130-01-594-8416
- Part Number
- Manufacturer
- Status
- 2663-22
- Manufacturer
- 40817 - Milwaukee Electric Tool Corp (Active)
- Primary Buy
- Primary Buy
Datasheet 5130-01-594-8416
- Characteristic
- Specifications
- FIIG
- Specifications
- A541T0
- Current Type [ACDC]
- Dc
- Voltage Rating [AMSE]
- 18.0 Volts Nominal
- Torque Capacity [AJCG]
- 450.0 Foot-Pounds Nominal
- Speed Adjustments [ABBB]
- Variable Speed
- No Load Speed In Rpm [BRZT]
- 1900.0 Maximum
- Drive End Type [BRZR]
- Male Spindle
- Drive End Shape [BRZS]
- Square
- Handle Style [ALMP]
- Pistol Grip Handle
- Overall Length [ABHP]
- 8.875 Inches Nominal
- Drive For Which Designed [BRZX]
- Straight
- Part Name Assigned By Controlling Agency [CXCY]
- M18 Cordless 1/2 Inch High Torque Impact Wrench
Similar Supply Items to 5130-01-594-8416
Freight Information 5130-01-594-8416
5130-01-594-8416 has freight characteristics managed by the Department of the Air Force.. 5130-01-594-8416 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
