5130-01-548-0123
Portable Electric Router
5130015480123 015480123 PR20EVSNK
An electric powered, hand-held rotary tool which cuts by means of a router bit. It is used with a template and/or cutter guide in cutting away unwanted material in stair routing, inlaying, light shaping work and the like. It is equipped with a pattern follower and/or attachment and may or may not be furnished with router bit(s). View more Portable Electric Router
May 2023
1
Marketplace 5130-01-548-0123
Request a Quotation from participating marketplace vendors
Related Documents 5130-01-548-0123 1+ Documents (More...)
/fsg-51/fsc-5130/us
Electric Router 5130015480123 Every Day 5130-01-548-0123 RQST Updated Every Day 5130-01-548-0123 RQST
RQST Updated Every Day 5130-01-548-0123 RQST NE Restrictions 5130-01-548- Restrictions 5130-01-
Restrictions 5130-01-548-0123
5130-01-548-0123 is a Portable Electric Router that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5130-01-548-0123
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5130-01-548-0123
- Canada (ZC01)
- Effective Date:
- 1 Feb 2007
Approved Sources 5130-01-548-0123
- Part Number
- Manufacturer
- Status
- PR20EVSNK
- Manufacturer
- 53867 - Robert Bosch Llc (Active)
- Primary Buy
- Primary Buy
Datasheet 5130-01-548-0123
- Characteristic
- Specifications
- FIIG
- Specifications
- A541U0
- Accessory Components And Quantity [AKYD]
- Pr20evs Router 1, Fixed Base 1, Straight Edge Guide 1, Roller Guide 1, Offset Base With Roller Guide 1, Tilt Base 1, Drop-Forged Wrench 1 And Carrying Case 1
- Alternating Current Rating In Amps [ACUS]
- 5.7
- Current Type [ACDC]
- Ac
- Features Provided [CBBL]
- Spindle Lock
- Horsepower Rating [ANCY]
- 1.000
- No Load Speed In Rpm [BRZT]
- 16000.0 Minimum And 35000.0 Maximum
- Plunge Depth Capacity [AKUS]
- 1.1875 Inches Nominal
- Overall Height [ABKW]
- 7.500 Inches Nominal
- Part Name Assigned By Controlling Agency [CXCY]
- Colt Variable Speed Palm Router Kit
- Special Features [FEAT]
- Collet Capacity 0.25 Inch; Base Opening 1.5625; Shipping Weight 10.00 Lbs
Management Data 5130-01-548-0123
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Feb 2020
- General Services Administration (TG)
- EA
- Subscribe
- EA
Similar Supply Items to 5130-01-548-0123
Freight Information 5130-01-548-0123
5130-01-548-0123 has freight characteristics managed by Canada.. 5130-01-548-0123 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
