5130-01-500-9510
Electric Impact Wrench
5130015009510 015009510 9070-20 6KX37
An electric-powered hand-held rotary tool, which converts continuous rotary motion to rotary impacting motion at a given torque, for use in tightening and loosening fasteners, such as bolts, nuts, screws, and the like. The item may contain screwdriver bit(s), socket(s) and/or chuck(s). Excludes NUT RUNNER AND SCREWDRIVER, ELECTRIC. View more Electric Impact Wrench
May 2023
8
Marketplace 5130-01-500-9510
Request a Quotation from participating marketplace vendors
Related Documents 5130-01-500-9510 2+ Documents (More...)
Photo 1/3 5130-01-500-9510 Photo 2/3 NSN 5130-01-500-9510 (Identification) 3/3 - - - 1.
Day 5130-01-500-9510 RQST NE Updated Every Day 5130-01-500-9510 RQST Updated Every Day 5130-01-500-9510
Restrictions 5130-01-500-9510
5130-01-500-9510 is a Electric Impact Wrench that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5130-01-500-9510
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5130-01-500-9510
- US Army (A192)
- Effective Date:
- 1 Sep 2002
- Supplementary Receivers:
- BF
- NASA (G751)
- Effective Date:
- 1 Sep 2002
- US Navy (N9QG)
- Effective Date:
- 1 Jan 2014
- Supplementary Collaborators:
- GG
- Canada (ZC01)
- Effective Date:
- 1 May 2009
Approved Sources 5130-01-500-9510
- Part Number
- Manufacturer
- Status
- 9070-20
- Manufacturer
- 40817 - Milwaukee Electric Tool Corp (Active)
- Primary Buy
- Primary Buy
- 6KX37
- 25795 - W.W. Grainger, Inc. (Active)
- Secondary Buy
- Secondary Buy
Datasheet 5130-01-500-9510
- Characteristic
- Specifications
- FIIG
- Specifications
- A541T0
- Drive End Shape [BRZS]
- Square
- Drive End Type [BRZR]
- Male Spindle
- Drive For Which Designed [BRZX]
- Straight
- Alternating Current Rating In Amps [ACUS]
- 7.0
- Current Type [ACDC]
- Ac Or Dc
- Features Provided [CBBL]
- Reversible
- Frequency Rating [ACZB]
- 60.0 Hertz Nominal
- Handle Style [ALMP]
- Pistol Grip Handle
- No Load Speed In Rpm [BRZT]
- 1800.0 Nominal
- Impact Blows Per Minute [AKUL]
- 2600.0
- Size [BGBD]
- 0.500 Inches Nominal
- Overall Length [ABHP]
- 11.625 Inches Nominal
- Phase [FAAZ]
- Single
- Special Features [FEAT]
- Detent Pin Retainer
- Torque Capacity [AJCG]
- 300.0 Foot-Pounds Maximum
- Voltage Rating [AMSE]
- 120.0 Volts Nominal
Management Data 5130-01-500-9510
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Feb 2020
- Department of the Navy (DN)
- EA
- Subscribe
- EA
Army
- Materiel Category and Inventory Manager:
- E
- General Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- D
- Durable item.An item of Army property coded with an ARC of D in the AMDF. Durable items do not require property book accountability after issue from the stock record account but do require hand receipt control when issued to the user. Commercial and fabricated items similar to items coded D in the AMDF are considered durable items.
Navy
- Cognizance:
- 9Q
Similar Supply Items to 5130-01-500-9510
Freight Information 5130-01-500-9510
5130-01-500-9510 has freight characteristics.. 5130-01-500-9510 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
