5130-01-451-7643
Electric Portable Circular Saw
5130014517643 014517643 DW384 DW384 DEWALT
An electric driven saw which cuts by means of a revolving circular saw blade or abrasive saw wheel. It is furnished with circular saw blade(s) or abrasive saw wheel(s). View more Electric Portable Circular Saw
Managed by United States
NSN Created on 31 Dec 1997
Data Last Changed
May 2023
May 2023
NATO Update Count
16
16
NATO Data Quality
Marketplace 5130-01-451-7643
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 5130-01-451-7643 2+ Documents (More...)
DW384 DW384 DEWALT An electric driven saw which cuts by means of a revolving circular saw blade or abrasive
DW384 SAW,CIRCULAR,PORTABLE,ELECTRIC 10 EA NS Request Quotation Subscribe to View Vendor Details... 5130
Updated Every Day 5130-01-451-7643 RQST NE Updated Every Day 5130-01-451-7643 RQST Updated Every Day
DW384 SAW,CIRCULAR,PORTABLE,ELECTRIC 10 EA NS Request Quotation Subscribe to View Vendor Details... 5130
Updated Every Day 5130-01-451-7643 RQST NE Updated Every Day 5130-01-451-7643 RQST Updated Every Day
Upgrade your Account Upgrade 5130-01-547-6505Electric Portable Circular Saw5130015476505 015476505 DW384
DW384 SAW,CIRCULAR,PORTABLE,ELECTRIC 10 EA NS Request Quotation Updated Every Day DW384 RQST NE Updated
SAW,CIRCULAR,PORTABLE,ELECTRIC 10 EA NS Request Quotation Updated Every Day DW384 RQST NE Updated Every
DW384 SAW,CIRCULAR,PORTABLE,ELECTRIC 10 EA NS Request Quotation Updated Every Day DW384 RQST NE Updated
SAW,CIRCULAR,PORTABLE,ELECTRIC 10 EA NS Request Quotation Updated Every Day DW384 RQST NE Updated Every
Restrictions 5130-01-451-7643
5130-01-451-7643 is a Electric Portable Circular Saw that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5130-01-451-7643
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5130-01-451-7643
- US Army (A192)
- Effective Date:
- 1 Mar 1998
- US Air Force (FGGS)
- Effective Date:
- 1 Mar 1998
- NASA (G751)
- Effective Date:
- 1 Mar 1998
- US Marine Corps (MC14)
- Effective Date:
- 1 Mar 1998
- US Navy (N9QG)
- Effective Date:
- 1 Mar 1998
- Supplementary Collaborators:
- GT
- Canada (ZC01)
- Effective Date:
- 1 Aug 2012
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 2003
Approved Sources 5130-01-451-7643
- Part Number
- Manufacturer
- Status
- DW384
- Manufacturer
- 7CGP8 - Dewalt Industrial Tool Co (Active)
- Primary Buy
- Primary Buy
- DW384 DEWALT
- 00NS2 - Kipper Tool Company (Active)
- Secondary Buy
- Secondary Buy
- DW384
- 07429 - Black And Decker Us Inc (Active)
- Secondary Buy
- Secondary Buy
Datasheet 5130-01-451-7643
- Characteristic
- Specifications
- FIIG
- Specifications
- T294-Z
- Accessory Components And Quantity [AKYD]
- Carbide Blade And Blade Wrench
- Alternating Current Rating In Amps [ACUS]
- 15.0
- Blade Diameter [BBPJ]
- 8.250 Inches Nominal
- Carrying Case [AFJU]
- Not Provided
- Current Type [ACDC]
- Ac
- Features Provided [CBBL]
- Electric Brake And Spindle Lock
- Frequency Rating [ACZB]
- 60.0 Hertz Nominal
- Motor Armature Axis Position [BZZW]
- Parallel To Saw Blade Spindle Axis
- Rotational Speed Rating In Rpm [AMZE]
- 5800.0
- Phase [FAAZ]
- Single
- Special Features [FEAT]
- Top Handle; 2-1/4 In. Cut Depth At 45 Deg; Aluminum Shoe; 50 Deg Bevel Capacity
- Vertical Cut Depth [BZZX]
- 2.938 Inches
- Voltage Rating [AMSE]
- 120.0 Volts Nominal
Management Data 5130-01-451-7643
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- May 2021
- Department of the Navy (DN)
- EA
- Subscribe
- EA
- Feb 2020
- US Marine Corps (DM)
- EA
- Subscribe
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Army (DA)
- A
- Z
- Discontinued-Use 5130-01-572-7913
- Z
- Department of the Navy (DN)
- N
- Z
- Discontinued-Use 5130-01-572-7913
- Z
Army
- Materiel Category and Inventory Manager:
- E
- General Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- D
- Durable item.An item of Army property coded with an ARC of D in the AMDF. Durable items do not require property book accountability after issue from the stock record account but do require hand receipt control when issued to the user. Commercial and fabricated items similar to items coded D in the AMDF are considered durable items.
Navy
- Cognizance:
- 9Q
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- 02
- Operational Test:
- No Special Procedures
Similar Supply Items to 5130-01-451-7643
Freight Information 5130-01-451-7643
5130-01-451-7643 has freight characteristics.. 5130-01-451-7643 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
