5130-00-892-2103
Socket Wrench Adapter
5130008922103 008922103 B107.2 J07655 B107.2 TY5 STP 07655 GGG-W-660 07655 GGG-W-660 TY3
A rigid adapter less than four inches (101.6 mm) long used to connect sockets to handles, power tools, or to other attachments which are not designed for direct mating to each other. See also RATCHET ATTACHMENT, SOCKET WRENCH; UNIVERSAL JOINT, SOCKET WRENCH ATTACHMENT; EXTENSION, SOCKET WRENCH; and ADAPTER-EXTENSION, SOCKET WRENCH; Excludes ADAPTER, SOCKET, CROWFOOT SOCKET WRENCH HEAD; SOCKET, WRENCH, REFRIGERATION VALVE STEM; and HOLDER, SCREWDRIVER BIT, FEMALE SQUARE DRIVE. View more Socket Wrench Adapter
May 2023
16
Marketplace 5130-00-892-2103
Request a Quotation from participating marketplace vendors
Related Documents 5130-00-892-2103 5+ Documents (More...)
,SOCKET WRENCH RQST NS Request Quotation Updated Every Day J07655 RQST NE Updated Every Day 07655 RQST
005416728 B107.2 TY5GGG-W- EX506 GGG-W-660 TY3 https//www.nsnlookup.com https//www.nsnlookup.com /fsg
Socket Wrench Adapter 5130008922103 008922103 J07655 B107.2 TY5 STP 07655 GGG-W-660 07655 GGG-W
TY5 EX506 /fsg-51/fsc -5130/us 5130-00 at one end B107.2 TY5 EX506 https GGG-W-660 TY3 https//www.nsnlookup.com
Details... 07655 ADAPTER TY5 EX506 https GGG-W-660 https//www.nsnlookup.com /fsg-51/fsc- https//www.nsnlookup.com
Socket Wrench Adapter 5130008922103 008922103 J07655B107.2 TY5 STP 07655 GGG-W-660 07655 GGG-W-
a day Upgrade your Account Upgrade 5130-01-590-1938Socket Wrench Socket5130015901938 015901938STP 07655
Socket Wrench Adapter 5130008922103 008922103 Account Upgrade 5130-00-892-2103Socket Wrench Adapter5130008922103
Managed by United Kingdom NSN Created on 25 Apr 1991 Data Last Changed January 2023 NATO 07655 558-2
-07655 Details... 07655 ADAPTER TY5 EX506 https GGG-W-660 https//www.nsnlookup.com /fsg-51 07655 558
Restrictions 5130-00-892-2103
5130-00-892-2103 is a Socket Wrench Adapter that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5130-00-892-2103
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5130-00-892-2103
- US Army (A192)
- Effective Date:
- 1 Apr 1991
- Supplementary Receivers:
- AZBD
- NASA (G751)
- Effective Date:
- 1 Apr 1991
- US Marine Corps (MC14)
- Effective Date:
- 1 Apr 1991
- US Navy (N9QG)
- Effective Date:
- 1 Jan 2014
- Supplementary Collaborators:
- GG
- Republic of Korea (ZH01)
- Effective Date:
- 1 May 2003
Approved Sources 5130-00-892-2103
- Part Number
- Manufacturer
- Status
- B107.2
- Manufacturer
- 05047 - The American Society Of Mechanical (Active)
- Incomplete Reference
- Incomplete Reference
- J07655
- 1CV05 - The Stanley Works (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- B107.2 TY5
- 80244 - General Services Administration (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- STP 07655
- 00NS2 - Kipper Tool Company (Active)
- Secondary Buy
- Secondary Buy
- GGG-W-660
- 81348 - Federal Specifications Promulgated (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 07655
- 1CV05 - The Stanley Works (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- GGG-W-660 TY3
- 80244 - General Services Administration (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5130-00-892-2103
- Characteristic
- Specifications
- FIIG
- Specifications
- A102A0
- Material [MATT]
- Steel Overall
- Surface Treatment [SFTT]
- Oxide Overall
- Style Designator [STYL]
- External-Internal
- Overall Length [ABHP]
- 1.906 Inches Maximum
- Outside Diameter [ABKV]
- 1.375 Inches Maximum
- Drive Surface Size [ATNC]
- 0.500 Inches Nominal First End
- Drive Surface Size [ATNC]
- 0.625 Inches Nominal Second End
- Drive End Shape [CTCT]
- Square First End Internal
- Drive End Shape [CTCT]
- Square Second End External
- Features Provided [CBBL]
- Power Tool
- Specification/Standard Data [ZZZK]
- 05047-Asme B107.2 Professional/Industrial Association Standard
- Nondefinitive Spec/Std Data [ZZZT]
- 5 Type
Management Data 5130-00-892-2103
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Jan 2023
- Department of the Navy (DN)
- EA
- Subscribe
- 6
- EA
- Dec 2020
- Department of the Navy (DN)
- EA
- Subscribe
- 6
- EA
- Feb 2020
- Department of the Army (DA)
- EA
- Subscribe
- 6
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- US Marine Corps (DM)
- M
- 4
- Reversal Of Phrase Code A 5130-01-590-1938
- 4
Army
- Materiel Category and Inventory Manager:
- E
- General Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9Q
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 2
- Non-Critical Repair Part
- Echelon Management:
- 02
- Operational Test:
- No Special Procedures
NATO Stock Numbers Related to 5130-00-892-2103
Freight Information 5130-00-892-2103
5130-00-892-2103 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 186620. A Sub NMFC of Z. It has a NMFC Description of TOOLS, NOI HAND OTHER THAN POWER. 5130-00-892-2103 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 91810 which rates the freight between FCL and LCL. 5130-00-892-2103 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 732 for ocean manifesting and military sealift. 5130-00-892-2103 is not classified as a special type of cargo when transported by water. 5130-00-892-2103 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
