5130-00-684-0923
Socket Wrench Socket
5130006840923 006840923 B107.2 B107.2 TY1CL1 IM923 2BF707 B107.2 CL1STA GGG-W-660 TY1CL1STA GGG-W-660
An item having an internal drive at one end made to fit into the external drive end of a socket wrench handle, torque wrench, or power driven tool. The opposite end consists of various internal wrench shapes such as hexagon or square. It may include an integral universal joint. View more Socket Wrench Socket
August 2025
23
Marketplace 5130-00-684-0923
Request a Quotation from participating marketplace vendors
Related Documents 5130-00-684-0923 5+ Documents (More...)
B107.2 SOCKET,SOCKET WRENCH 2 EA NS Request Quotation Subscribe to View Vendor Details... 2BF707 SOCKET
PF140A B107.2 CL1STAGGG-W IM923 https//www.nsnlookup.com WRENCH, B107.2 CL1STA 5550A420 53097 GGG-W-
/fsg-51/fsc-5130/us 5130-00-684-0923 Socket Wrench Socket 5130006840923 006840923 B107.2 TY1CL1 IM923
2BF707 B107.2 CL1STA GGG-W-660 TY1CL1STA GGG-W-660 An item having an internal drive www.nsnlookup.com
Socket Wrench Socket 5130006840923 006840923 your Account Upgrade 5130-00-684-0923Socket Wrench
Socket5130006840923 006840923 B107.2 B107.2 TY1CL1 IM923 Vendor Details... 5130-00-684-0923 SOCKET,SOCKET
day Upgrade your Account Upgrade 5130-21-840-0314Socket Wrench Socket5130218400314 218400314 10046 IM923
Socket Wrench Socket 5130006840923 006840923 your Account Upgrade 5130-00-684-0923Socket Wrench
sizes of WRENCH, B107.2 CL1STA 5550A420 53097 GGG-W-660 TY1CL1STA https//www.nsnlookup.com /fsg-51/fsc
-5130/us 5130-00-234-1902 Socket Wrench Socket 5130002341902 002341902 B107.2 TY1CL1 IM765 B107.2 CL1STAGGG-W
Restrictions 5130-00-684-0923
5130-00-684-0923 is a Socket Wrench Socket that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5130-00-684-0923
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5130-00-684-0923
- US Army (A192)
- Effective Date:
- 1 Apr 1991
- Supplementary Receivers:
- AZBFBD
- US Air Force (FGGS)
- Effective Date:
- 1 Apr 1991
- NASA (G751)
- Effective Date:
- 1 Apr 1991
- Israel (YD01)
- Effective Date:
- 1 Aug 2016
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 2002
- Denmark (ZS01)
- Effective Date:
- 1 Oct 1997
- Greece (ZU01)
- Effective Date:
- 1 Apr 2008
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 5130-00-684-0923
- Part Number
- Manufacturer
- Status
- B107.2
- Manufacturer
- 05047 - The American Society Of Mechanical (Active)
- Incomplete Reference
- Incomplete Reference
- B107.2 TY1CL1
- 80244 - General Services Administration (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- IM923
- 55719 - Idsc Holdings Llc (Active)
- Secondary Buy
- Secondary Buy
- 2BF707
- 75Q65 - Oshkosh Defense Llc (Active)
- Secondary Buy
- Secondary Buy
- 2BF707
- 45152 - Oshkosh Corp (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- B107.2 CL1STA
- 80244 - General Services Administration (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- GGG-W-660 TY1CL1STA
- 80244 - General Services Administration (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- GGG-W-660
- 81348 - Federal Specifications Promulgated (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5130-00-684-0923
- Characteristic
- Specifications
- FIIG
- Specifications
- A102A0
- Drive End Outside Diameter [AHMK]
- 2.365 Inches Minimum And 4.072 Inches Maximum
- Drive End Shape [CTCT]
- Square Single End Internal
- Drive Surface Size [ATNC]
- 1.000 Inches Nominal Single End
- Features Provided [CBBL]
- Power Tool
- Material [MATT]
- Steel Overall
- Nondefinitive Spec/Std Data [ZZZT]
- 1 Type And 1 Class
- Overall Length [ABHP]
- 4.500 Inches Maximum
- Wrenching End Outside Diameter [AHMJ]
- 3.990 Inches Minimum And 4.072 Inches Maximum
- Wrenching Surface Shape [CRWY]
- 6 Point Single End Internal
- Wrenching Surface Size [AJBR]
- 2.875 Inches Nominal Single End
- Wrenching End Opening Depth [AJAP]
- 1.567 Inches Minimum
- Specification/Standard Data [ZZZK]
- 05047-Asme B107.2 Professional/Industrial Association Standard
- Style Designator [STYL]
- Internal-Internal
- Surface Treatment [SFTT]
- Oxide Overall
Management Data 5130-00-684-0923
Army
- Materiel Category and Inventory Manager:
- E
- General Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- D
- Durable item.An item of Army property coded with an ARC of D in the AMDF. Durable items do not require property book accountability after issue from the stock record account but do require hand receipt control when issued to the user. Commercial and fabricated items similar to items coded D in the AMDF are considered durable items.
Navy
- Cognizance:
- 9Q
Similar Supply Items to 5130-00-684-0923
Freight Information 5130-00-684-0923
5130-00-684-0923 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 186620. A Sub NMFC of Z. It has a NMFC Description of TOOLS, NOI HAND OTHER THAN POWER. 5130-00-684-0923 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 91810 which rates the freight between FCL and LCL. 5130-00-684-0923 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 732 for ocean manifesting and military sealift. 5130-00-684-0923 is not classified as a special type of cargo when transported by water. 5130-00-684-0923 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
