5120-01-621-0817
Combination Box And Open End Wrench
5120016210817 016210817 J1214MASD 1ALM8 1214MASD
A nonadjustable wrench having a box wrenching feature on one end and an open end wrenching feature on the other end. Excludes WRENCH, BOX and WRENCH, OPEN END. View more Combination Box And Open End Wrench
May 2023
7
Marketplace 5120-01-621-0817
Request a Quotation from participating marketplace vendors
Related Documents 5120-01-621-0817 4+ Documents (More...)
Photo 1/3 5120-01-621-0817 Photo 2/3 NSN 5120-01-621-0817 (Identification) 3/3 - - - 1.
Updated Every Day 1214MASD RQST NE Updated Every Day 1ALM8 RQST NE Updated Every Day 5120-01-621-0817
Marketplace Restrictions Approved Sources Datasheet Management BUY NE FedMall Updated Every Day J1214MASD
End Wrench your Account Upgrade 5120-01-621-0817Combination Box And Open End Wrench5120016210817 016210817
Restrictions 5120-01-621-0817
5120-01-621-0817 is a Combination Box And Open End Wrench that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-01-621-0817
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-01-621-0817
- US Army (A192)
- Effective Date:
- 1 Jun 2015
- Supplementary Receivers:
- AZ
- NASA (G751)
- Effective Date:
- 1 Jun 2015
- US Marine Corps (MC14)
- Effective Date:
- 1 Jul 2015
- Republic of Korea (ZH01)
- Effective Date:
- 1 Aug 2013
Approved Sources 5120-01-621-0817
- Part Number
- Manufacturer
- Status
- J1214MASD
- Manufacturer
- 1CV05 - The Stanley Works (Active)
- Primary Buy
- Primary Buy
- 1ALM8
- 25795 - W.W. Grainger, Inc. (Active)
- Secondary Buy
- Secondary Buy
- 1214MASD
- 1CV05 - The Stanley Works (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5120-01-621-0817
- Characteristic
- Specifications
- FIIG
- Specifications
- A527Y0
- Material [MATT]
- Steel Overall
- Surface Treatment [SFTT]
- Chromium Overall
- Style Designator [STYL]
- Offset
- Overall Length [ABHP]
- 7.906 Inches Nominal
- Head Angle [CRCS]
- 15.0 Degrees Nominal
- Wrenching End Offset Angle [CSPX]
- 15.0 Degrees Nominal
- Wrenching Surface Size [AJBR]
- 14.0 Millimeters Nominal Both Ends
- Wrenching Surface Shape [CRWY]
- Oval First End Internal
- Wrenching Surface Shape [CRWY]
- 12 Point Second End Internal
- Special Features [FEAT]
- Satin Finish; Anti-Slip Design Open End Wrench Head
Management Data 5120-01-621-0817
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Feb 2020
- Department of the Army (DA)
- EA
- Subscribe
- EA
Army
- Materiel Category and Inventory Manager:
- E
- General Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- D
- Durable item.An item of Army property coded with an ARC of D in the AMDF. Durable items do not require property book accountability after issue from the stock record account but do require hand receipt control when issued to the user. Commercial and fabricated items similar to items coded D in the AMDF are considered durable items.
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 2
- Non-Critical Repair Part
- Echelon Management:
- 02
- Operational Test:
- No Special Procedures
- Physical Category:
- 1
- Bin
Similar Supply Items to 5120-01-621-0817
Freight Information 5120-01-621-0817
5120-01-621-0817 has freight characteristics managed by the Republic of Korea.. 5120-01-621-0817 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
