5120-01-621-0778
Socket Wrench Attachment Universal Joint
5120016210778 016210778 J4770A 2KGL4 4770A
A connection for socket wrenches and handles. Consists of an internal drive on one end and an external drive on the opposite end, of the same size, connected by a cross pin device to permit swivel up to 90 degrees (1.6 radians). View more Socket Wrench Attachment Universal Joint
May 2023
8
Marketplace 5120-01-621-0778
Request a Quotation from participating marketplace vendors
Related Documents 5120-01-621-0778 5+ Documents (More...)
Photo 1/3 5120-01-621-0778 Photo 2/3 NSN 5120-01-621-0778 (Identification) 3/3 - - - 1.
Every Day 4770A RQST NE Updated Every Day 2KGL4 RQST NE Updated Every Day 5120-01-621-0778 RQST NE Updated
Every Day 5120-01-589-8857 RQST NE Restrictions https//www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-621-0778
Socket Wrench Attachment Universal Joint Updated Every Day 5120-01-621-0778 RQST NE Updated https
vendors Request FedMall Updated Every 15 Minutes 5120-01-652-0403 BUY NE FedMall Updated Every Day J4770A
//www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-652-0403 Socket Wrench Attachment Universal Joint J4770A
www.nsnlookup.com /fsg-59/fsc-5975/us 5975-01-102-4829 Electrical Equipment Mounting Base 011024829 MT-4770A
www.nsnlookup.com /fsg-59/fsc-5975/us 5975-01-102-4829 https//www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-621-0778
Restrictions 5120-01-621-0778
5120-01-621-0778 is a Socket Wrench Attachment Universal Joint that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-01-621-0778
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-01-621-0778
- US Army (A192)
- Effective Date:
- 1 Jan 2014
- Supplementary Receivers:
- CT
- NASA (G751)
- Effective Date:
- 1 Jan 2014
- Canada (ZC01)
- Effective Date:
- 1 Oct 2014
- Republic of Korea (ZH01)
- Effective Date:
- 1 Aug 2013
Approved Sources 5120-01-621-0778
- Part Number
- Manufacturer
- Status
- J4770A
- Manufacturer
- 1CV05 - The Stanley Works (Active)
- Primary Buy
- Primary Buy
- 2KGL4
- 25795 - W.W. Grainger, Inc. (Active)
- Secondary Buy
- Secondary Buy
- J4770A
- Z19N0 - The Trustee For Henchman Unit Trust (Active)
- Secondary Buy
- Secondary Buy
- 4770A
- 1CV05 - The Stanley Works (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- J4770A
- ZAE87 - Henchman Products Pty Ltd (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5120-01-621-0778
- Characteristic
- Specifications
- FIIG
- Specifications
- A102A0
- Material [MATT]
- Steel Overall
- Surface Treatment [SFTT]
- Chromium Overall
- Style Designator [STYL]
- External-Internal
- Overall Length [ABHP]
- 1.344 Inches Nominal
- Outside Diameter [ABKV]
- 0.547 Inches Nominal
- Drive Surface Size [ATNC]
- 0.250 Inches Nominal Both Ends
- Drive End Shape [CTCT]
- Square First End Internal
- Drive End Shape [CTCT]
- Square Second End External
- Features Provided [CBBL]
- Manual Tool
Management Data 5120-01-621-0778
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Feb 2020
- Department of the Army (DA)
- EA
- Subscribe
- EA
Army
- Materiel Category and Inventory Manager:
- E
- General Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Similar Supply Items to 5120-01-621-0778
Freight Information 5120-01-621-0778
5120-01-621-0778 has freight characteristics managed by the Republic of Korea.. 5120-01-621-0778 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
