5120-01-620-6784

Socket Wrench Socket

5120016206784 016206784 AS954 AS954 TY1CL1STB J5330 1AN18 STP 5330G 5330

An item having an internal drive at one end made to fit into the external drive end of a socket wrench handle, torque wrench, or power driven tool. The opposite end consists of various internal wrench shapes such as hexagon or square. It may include an integral universal joint. View more Socket Wrench Socket

5120-01-620-6784 SOCKET,SOCKET WRENCH 5120016206784 016206784

Managed by United States
NSN Created on 5 Aug 2013
Data Last Changed
June 2023
NATO Update Count
15
NATO Data Quality
5120-01-620-6784 SOCKET,SOCKET WRENCH 5120016206784 016206784 1/2
5120-01-620-6784 Photo 1/2
STYL Style 168 for 5120-01-620-6784 2/2
NSN 5120-01-620-6784 (Identification) 2/2

5120-01-620-6784 Stock and Availability Marketplace 5120-01-620-6784

Need Help?
Request a Quotation from participating marketplace vendors
MSC Updated Every Day
J5330 RQST NE MSC
MSC Updated Every Day
5330 RQST NE MSC
Grainger Updated Every Day
1AN18 RQST NE Grainger
eBay Updated Every Day
5120-01-620-6784 RQST NE eBay
eBay Updated Every Day
5120-01-620-6784 RQST eBay
Amazon Updated Every Day
5120-01-620-6784 RQST NE Amazon

5120-01-620-6784 Related Documents Related Documents 5120-01-620-6784 5+ Documents (More...)

https//www.nsnlookup.com
/fsg-51/fsc-5120/us
5120-01-620-6784 Socket Wrench Socket 5120016206784 016206784
AS954 AS954 TY1CL1STB J5330 1AN18 STP 5330G 5330 An item having an internal drive at one end made to
Every Day 5330 RQST NE Updated Every Day 1AN18 RQST NE Updated Every Day 5120-01-620-6784 RQST NE Updated
Socket5120016206784 016206784AS954AS954 TY1CL1STBJ53301AN18STP 5330G Socket 5120009357445 009357445 AS954
https//www.nsnlookup.com
/fsg-51/fsc-5120/us
5120-01-589-8660 Socket Wrench Socket 5120015898660 015898660
$1 a day Upgrade your Account Upgrade 5120-01-589-8660Socket Wrench Socket5120015898660 015898660 STP 5330G
Socket Wrench Socket 5120016206784 016206784 Upgrade 5120-01-620-6784Socket Wrench Socket5120016206784
016206784 AS954 AS954 TY1CL1STB J5330 1AN18 STP 5330G Socket 5120009357445 009357445 AS954 TY1CL1STB
https//www.nsnlookup.com
/fsg-51/fsc-5120/us
5120-01-399-9567 Socket Wrench Socket 5120013999567 013999567
AS954 TY1CL1STB J5016 1AK32 5016 An item having an internal drive at one end made to fit into the external
Socket Wrench Socket 5120016206784 016206784 AS954 TY1CL1STB J5330 1AN18 STP 5330G 5330 An item
www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-651-0547 Socket Wrench Socket 5120016510547 016510547 AS954
https//www.nsnlookup.com
/fsg-51/fsc-5120/us
5120-01-398-9274 Socket Wrench Socket 5120013989274 013989274
AS954 TY1CL1STB 00944446000 44446 AS955 AS955 TY1CL1STC 9-44446 An item having an internal drive at
TY1CL1STC9-44446 An item having an internal drive TY1CL2 AS955 TY1CL1STC B107.5M A group of SOCKET, AS954
Socket Wrench Socket 5120016206784 016206784 AS954 TY1CL1STB J5330 1AN18 STP 5330G 5330 An item
https//www.nsnlookup.com
/fsg-51/fsc-5120/us
5120-01-398-8014 Socket Wrench Socket 5120013988014 013988014
AS954 TY1CL1STB 00947522000 47522 9-47522 An item having an internal drive at one end made to fit into
https//www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-620-6784 Socket Wrench Socket 5120016206784 016206784
AS954 TY1CL1STB J5330 1AN18 STP 5330G 5330 An item having an internal drive at one end made to fit into

5120-01-620-6784 Demil Restrictions 5120-01-620-6784

DEMIL: A | DEMILI: 1 | CRITICALITY: X | HMIC: N | PMIC: A | EDC: | ADPEC:

5120-01-620-6784 is a Socket Wrench Socket that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.

5120-01-620-6784 HTS and ScheduleB Import and Export 5120-01-620-6784

Schedule B
Subscribe to View Schedule B
HTS Code
Subscribe to View HTS Code

5120-01-620-6784 End Users End Users 5120-01-620-6784

US Army (A192)
Effective Date:
1 Aug 2013
AMC 0 AMSC 0 IMC Z IMCACTY CT
US Coast Guard (C014)
Effective Date:
1 Apr 2015
AMC 0 AMSC 0
NASA (G751)
Effective Date:
1 Aug 2013
AMC 0 AMSC 0
US Marine Corps (MC14)
Effective Date:
1 Apr 2015
AMC 0 AMSC 0 IMC Z IMCACTY PA
US Navy (N9QG)
Effective Date:
1 Apr 2015
Supplementary Collaborators:
HD
AMC 0 AMSC 0 IMC Z IMCACTY GH
Canada (ZC01)
Effective Date:
1 Nov 2014

5120-01-620-6784 Manufacturers Approved Sources 5120-01-620-6784

Part Number
Manufacturer
Status
AS954
0U583 - Sae International (Active)
Incomplete Reference
RNCC 3 RNVC 1 DAC 4
J5330
1CV05 - The Stanley Works (Active)
Primary Buy
RNCC 3 RNVC 2 DAC 4
AS954 TY1CL1STB
80244 - General Services Administration (Active)
Incomplete Secondary Reference
RNCC 5 RNVC 1 DAC 4
1AN18
25795 - W.W. Grainger, Inc. (Active)
Secondary Buy
RNCC 5 RNVC 2 DAC 4
STP 5330G
00NS2 - Kipper Tool Company (Active)
Secondary Buy
RNCC 5 RNVC 2 DAC 4
J5330
Z19N0 - The Trustee For Henchman Unit Trust (Active)
Secondary Buy
RNCC 5 RNVC 2 DAC 3
5330
1CV05 - The Stanley Works (Active)
Canceled/Obsolete
RNCC 5 RNVC 9 DAC 4
J5330
ZAE87 - Henchman Products Pty Ltd (Replaced)
Canceled/Obsolete
RNCC 5 RNVC 9 DAC 3

5120-01-620-6784 Technical Data Datasheet 5120-01-620-6784

Characteristic
Specifications
FIIG
A102A0
Material [MATT]
Steel Overall
Surface Treatment [SFTT]
Chromium Overall
Style Designator [STYL]
Internal-Internal
Overall Length [ABHP]
3.250 Inches Nominal
Wrenching End Outside Diameter [AHMJ]
1.250 Inches Nominal
Drive End Outside Diameter [AHMK]
1.250 Inches Nominal
Wrenching End Opening Depth [AJAP]
1.219 Inches Nominal
Wrenching Surface Size [AJBR]
0.938 Inches Nominal Single End
Wrenching Surface Shape [CRWY]
12 Point Single End Internal
Drive Surface Size [ATNC]
0.500 Inches Nominal Single End
Drive End Shape [CTCT]
Square Single End Internal
Features Provided [CBBL]
Manual Tool
Special Features [FEAT]
Deep Length

5120-01-620-6784 Management Data Management Data 5120-01-620-6784

Subscribe
View Prices
Effective Date
Organization
Unit of Issue
Unit Price
Qty Unit Pack
Jan 2023
Department of the Army (DA)
EA
Subscribe
Aug 2019
Department of the Army (DA)
EA
Subscribe

Army Army

Materiel Category and Inventory Manager:
E
General Supplies (DLA/GSA Items)
Appropriation and Budget Activity:
2
Stock Fund Secondary Items
Management Inventory Segment:
2
Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
Weapons System / End Item / Homogeneous Group:
00
DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
Accounting Requirements:
X
Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.

Marine Corps Marine Corps

Stores Account:
1
Stock Fund Account Item
Echelon Management:
02
Operational Test:
No Special Procedures

5120-01-620-6784 Related Items NATO Stock Numbers Related to 5120-01-620-6784

5120-14-210-9852 5120-12-364-6803 5120-98-205-9462 5120-33-155-9422 5120-15-113-2845 5120-37-504-7952 5130-21-808-0702 5120-33-110-6240 5120-27-047-5375 5120-14-484-6515 5120-99-786-2481 5120-14-200-9336 5120-14-548-5093 5120-14-530-5337 5120-14-442-2003 5120-34-041-3160 5120-14-525-4363 5120-99-755-3201

5120-01-620-6784 Freight Data Freight Information 5120-01-620-6784

5120-01-620-6784 has freight characteristics.. 5120-01-620-6784 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
