5120-01-617-2709
Combination Box And Open End Wrench
5120016172709 016172709 25-109
A nonadjustable wrench having a box wrenching feature on one end and an open end wrenching feature on the other end. Excludes WRENCH, BOX and WRENCH, OPEN END. View more Combination Box And Open End Wrench
May 2023
6
Marketplace 5120-01-617-2709
Request a Quotation from participating marketplace vendors
Related Documents 5120-01-617-2709 5+ Documents (More...)
Every Day 5120-01-617-2709 RQST NE Updated Every Day 5120-01-617-2709 RQST Updated Every Day 5120-01
/fsg-51/fsc-5120/us 5120-01-617-2709 Combination Box And Open End Wrench,25-109 Photo 1/4 5120-01-617
Restrictions 5120-01-617-2709
5120-01-617-2709 is a Combination Box And Open End Wrench that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-01-617-2709
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-01-617-2709
- Denmark (ZS01)
- Effective Date:
- 1 Mar 2013
Approved Sources 5120-01-617-2709
- Part Number
- Manufacturer
- Status
- 25-109
- Manufacturer
- 636D0 - Apex Tool Group, Llc (Active)
- Primary Buy
- Primary Buy
- 25-109
- 03914 - Armstrong Bros Tool Co (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5120-01-617-2709
- Characteristic
- Specifications
- FIIG
- Specifications
- A527Y0
- Material [MATT]
- Steel Overall
- Surface Treatment [SFTT]
- Chromium Overall
- Style Designator [STYL]
- Offset
- Overall Length [ABHP]
- 4.360 Inches Nominal
- Head Angle [CRCS]
- 15.0 Degrees Nominal
- Wrenching End Offset Angle [CSPX]
- 15.0 Degrees Nominal
- Wrenching Surface Size [AJBR]
- 0.281 Inches Nominal Both Ends
- Wrenching Surface Shape [CRWY]
- Oval First End Internal
- Wrenching Surface Shape [CRWY]
- 12 Point Second End Internal
- Features Provided [CBBL]
- Full Polish
- Special Features [FEAT]
- Regular Length
Similar Supply Items to 5120-01-617-2709
Freight Information 5120-01-617-2709
5120-01-617-2709 has freight characteristics.. 5120-01-617-2709 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
